Summary of Contents for DigiTech Mistral3
- Page 1 Quadruple Countdown Timer plus Clock & Beep by DIGITECH 1v01 english...
- Page 2 DIGITECH S.r.l. Via Muggia, 6 34018 - S.Dorligo della Valle (TS) - ITALY Tel.: +39/040/280 990 Fax: +39/040/833 0561 E-mail: info@digitechtiming.com @ aprile 2007...
-
Page 3: Table Of Contents
english INDEX 1 General information Display..........1 Input . - Page 4 english 4 Training function Selecting the Training function ......19 Adjusting the clock and the type of reading ....19 Operation .
-
Page 5: General Information
english General information 1 General information is an instrument incorporating a 24 hours programmable centesimal “main clock”, and 4 centesimal countdowns that can work with different operating modes. The whole unit is operated by high precision time base. One special feature of countdowns is that they can be joined to each other or they can be interfaced to the main clock. -
Page 6: Turning On The Instrument
General information english Clock and CD Chronometer Operating ( cou ntdown) display status mode HOURS M INUTES SECO ND S 1/1 00 OR M EN T. X PIRED ESC. TYPE - SEL ECTED J OIN | LAP pl us C &... -
Page 7: Parameter Change
english General information Parameter change In order to modify the display and seconds freezing parameters for the automatic activation of the seconds timer, press the button as they are being displayed for 2 seconds. The instrument enters “programming parameters” and lights up the sign SET. -
Page 8: Backlighting
General information english Backlighting In order to use the chronometer in places where light is insufficient, or at night, you can enable the display backlighting. During normal operation and not when setting, press the continuously, to toggle between the three available backlighting options: Always Backlighting remains always on. -
Page 9: Low Battery
english General information Low battery When the battery life drops below 10%, the blinking symbol is displayed on the screen. When the “low battery” warning light is turned on, to reduce consumption, the backlighting is automatically limited to “on demand” mode At this point, before the equipment turns off, the residual life goes from 10 to 15 hours (with backlighting on demand) to over 30 hours (with backlighting always off). - Page 10 General information english...
-
Page 11: Main Clock
english Main clock 2 Main clock At start up, the switches to “Main clock" and the function is displayed by the caption “CL” in the “Type Selected” zone of the display. This function enables a high-precision hundredth-resolution clock that can be programmed throughout the 24 hours. -
Page 12: Exit With Synchronization Of Seconds
Main clock english Exit with synchronization of seconds The seconds in the clock cannot be programmed but they can be reset anytime by operating the external line. Therefore, upon striking of the full minute of the “sample clock” , you will need to set in action the external push-button with the greater precision possible. - Page 13 english Main clock The time of the clock “is frozen”, showing hundredths and SPLIT is displayed on the screen. The counter is automatically restored after the pre-programmed period of seconds (if different than “no”) or it can be restored manually, by pressing again the key.
- Page 14 Main clock english...
-
Page 15: The Countdowns
english The countdowns 3 The countdowns The four countdowns of are very versatile and easy to use. More specifically, they can be “linked” together or the main watch, to manage also races with linked sectors. Selection & programming of countdowns In order to select a specific countdown, just press the relevant CD x “selection key". -
Page 16: Loop
The countdowns english Loop As in Timer mode, after setting the duration and starting the timer, every tine you press the key or use the remote control, the error vs. the zero is displayed and it restarts immediately, recharging the programmed duration. -
Page 17: Timer Split
english The countdowns After the zero, counting up continues (without the “minus” sign), showing a delay compared to the time set. Timer split After the A countdown has started, by pressing or using the external remote control, the countdown is split. The time including hundredths is frozen on the display, preceded by “-”... -
Page 18: Beep Mode (B X )
The countdowns english Press to exit and confirm the programming. By using the “Main clock”, the chronometer calculates and displays the residual time to the programmed time. Please not that since it is not necessary to start the CD, you can edit its setting at any time, without loosing your data . -
Page 19: Loop Mode ( L X )
english The countdowns Loop mode ( L x ) This operating mode is similar to the Timer mode, with the difference that if you use the external remote control or press the key, in addition to displaying the error vs. the 0, the countdown will restart and automatically reset the programmed duration. -
Page 20: How To Join Two Countdowns ( Join )
The countdowns english How to join two countdowns ( Join ) In some cases you may find yourself in races where some races are linked to each other. As an example, a series of timed trials joined one to the other, that is where the actual end of the first one is considered as the start of the next one and so on, or a timed trial starting from the actual passing on a time check. -
Page 21: Operation
english The countdowns Operation When two countdowns are joined, if you split the time on the first CD (by pressing or using the external button connected to the remote control line), what happens is: 1: counting on the currently enabled CD is split. 2: The counting on the next CD is reset (if already working it is restarted from the value it had been set to). - Page 22 The countdowns english...
-
Page 23: Training Function
english Training function 4 Training function This special function changes the into a “regular ” hundredths chronometer. If combined with our SENTINEL pressure gauge, it becomes a great training system, with the same features: 1: The input line is timed at 2 seconds, to detect the passage of the rear wheels. -
Page 24: Operation
Training function english Otherwise, if synchronization is required, just press to return to the group of seconds and follow the exit with synchronization procedure. Operation After programming the clock and having decided the type of reading, every time you operate the external line, the chronometer “freezes” on the display and saves the reading time (including hundredths), increasing the reading count. -
Page 25: Characteristics
english Characteristics 5 Characteristics Inputs and outputs Audio output In the lower part of a ø 3,5 millimeter stereo jack is provided for the connection to an additional loudspeaker or to an headset. The output level is fixed. External push-button input has an external input that allows you to connect thePB5/JG-A push-button, included in the supply, that duplicates the functionality of the... -
Page 26: Technical Data
Characteristics english Technical data Technology: 16 bit, CMOS-LSI microprocessor. Dimensions and weight: 210 x 100 x 45 millimeter, 400 g, batteries inclu- ded. Display: LCD custom multiplexor 4 phases Power supply: 4 internal batteries 1.5 Volt, type AA Life: Greater than 300 hours, using alkaline batteries. Output: Loudspeaker or headset 2 x 32 Ohm. -
Page 27: Warranty
24 months from the date of purchase. Should during such period arise any such fault, Digitech S.r.l. shall repair or replace the equipment at no charge. Only carriage costs shall be payable by the customer. - Page 28 Warranty english...
-
Page 29: Conformity
Conformity 7 Conformity DECLARATION OF CONFORMITY pursuant to EN45014 and to ISO / IEC Guide 22 Manufacturer’s name: DIGITECH S.r.l. Manufacturer’s address: Via Muggia, 6 - 34018 San Dorligo della Valle (TS) - Italy declares that the product Type of product:...
