Chapter3 Button Functions

All the operations to the Electronic Sphygmomanometer are through the buttons. The names of
the buttons are above them. They are:
【 【 【 【 ON/OFF】 】 】 】
【 【 【 【 START/STOP】 】 】 】
When measuring, press to cancel the measurement and deflate the cuff.
The three buttons correspond with the hint in the LCD screen downside,
pressing any button will carry on corresponding function, eg:【MENU】 【ENTER】 【LIST】 etc.
Up and down buttons respectively carry on the functions of moving the cursor up and
down, changing the parameters and switching the status.

Chapter4 External Interfaces

Note
Please hold the air plug to remove the NIBP cuff.
The right side of the instrument is USB socket and AC adapter socket.
① USB socket
② AC adapter socket
Medical Test Supply
Hold the button to start or close the device.
Press to inflate the cuff and start a blood pressure measurement.
① Cuff Socket
left side
right side
