Leo blood pressure monitor with software
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PROFESSIONAL MEDICAL PRODUCTS
MISURATORE DI PRESSIONE LEO CON SOFTWARE
LEO BLOOD PRESSURE MONITOR
WITH SOFTWARE
TENSIOMÈTRE LEO AVEC LOGICIEL
DE LEO MEDIDOR DE PRESIÓN
CON SOFTWARE
MEDIDOR DA TENSÃO LEO COM SOFTWARE
32902 / CONTEC08A
CONTEC MEDICAL SYSTEMS CO., LTD
No.112 Qinhuang West Street, Economic & Technical Development Zone,
Qinhuangdao, Hebei Province, PEOPLE'S REPUBLIC OF CHINA
Made in China
Shanghai International Holding Corp. GmbH (Europe)
Eiffestrasse 80, 20537 Hamburg, Germany
Importato da / Imported by / Importé par / Importado por / Importado por:
Gima S.p.A.
Via Marconi, 1 - 20060 Gessate (MI) Italy
gima@gimaitaly.com - export@gimaitaly.com
www.gimaitaly.com
0123
