Page 3
Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4
Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 9
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifications, consult Power Safety Warning your service representative or local power company.
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 15
Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 16
Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Preface Contents Notice .................I Keyboard ................1-8 FCC Statement ..............III Function/Hot Key Indicators .........1-9 FCC RF Radiation Exposure Statement: ......IV System Map: Front & Left Views ........1-10 Instructions for Care and Operation ....... VI System Map: Right & Rear Views ......1-11 Power Safety ..............
Page 20
Preface Power Management Module Driver Installation ..........4-1 Driver Installation ............4-2 Overview ................3-1 Updating/Reinstalling Individual Drivers ......4-4 The Power Sources ............3-2 User Account Control ............4-4 AC/DC Adapter .............3-2 Windows Security Message ...........4-4 Battery ................3-2 New Hardware Found ............4-5 Turning On the Computer ..........3-3 Driver Installation Procedure .........4-5 Power Plans ..............3-4 Video ................4-5...
Page 21
Preface Non-Fatal Errors ............5-3 Upgrading The Computer The Setup Utility ............5-4 Overview ................6-1 Entering Setup ...............5-4 When Not to Upgrade ............6-2 Setup Screens ..............5-5 Removing the Battery ............6-3 Main Menu ..............5-6 Upgrading the Hard Disk Drive ........6-4 System Time & Date (Main Menu) .......5-6 Upgrading the Optical (CD/DVD) Device ....6-7 SATA Port 1/2 (Main Menu) .........5-7 Upgrading the System Memory (RAM) ......6-9...
Page 22
Preface Bluetooth & WLAN Combo Settings ......7-29 Configuring an External Display using the ATI CCC .. B-6 Bluetooth Networking Setup ........7-32 ATI CCC - Switching Display Modes ......B-7 Bluetooth & WLAN Combo Module Configuration ...7-33 Configuring an External Display in Win 7 ....B-9 Standard Bluetooth Configuration in Windows 7 ..7-36 Theater Mode ..............
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7 operating system ...
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open Built-In PC Camera Wireless Device (Optional) Operation Aboard Aircraft Power Button Hot Key Buttons The use of any portable elec- LED Status tronic transmission devices Indicators (see aboard aircraft is usually pro- Table 1 - 2, on...
Quick Start Guide LED Indicators Icon Color Description The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Scroll Lock Activated (to activate Green press Fn & Scr Lk) Green Caps Lock Activated Green Number Lock Activated Orange...
Quick Start Guide Hot Key Buttons These buttons give instant access to the default Internet browser and e-mail program, and allow you to toggle the Silent Mode on/off with one quick button press. Hot Key Function Toggle *Silent Mode (for power saving) Activate the Default Internet Program Activate the Default E-Mail Browser (Note that in Windows 7 without Outlook/Outlook Express installed this button has no function.
Quick Start Guide Keyboard The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See Table 1 - 4, on page 1 - 9 for full function key combination details.
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Keys Function Keys...
Quick Start Guide System Map: Front & Left Views Figure 1 - 4 Front & Left Views LED Power Indica- tors (see Table 1 - 1, on page 1 - DC-In Jack External Monitor Port RJ-45 LAN Jack HDMI-Out Port 2 * USB 2.0 Ports ...
Quick Start Guide System Map: Right & Rear Views Figure 1 - 5 Right & Rear Views Microphone-In Jack Headphone-Out Jack USB 2.0 Port Optical Device Drive Bay (for CD/ DVD Device) Security Lock Slot Battery CD/DVD Emergency Eject If you need to manually eject a CD/DVD (e.g.
Quick Start Guide System Map: Bottom View Figure 1 - 6 Bottom View Battery Component Bay Battery Information Cover Always completely dis- Vent/Fan Intake/ charge, then fully charge, a Outlet new battery before using it. Hard Disk Bay Completely discharge and Cover charge the battery at least 3.75G USIM Card...
Page 37
Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Quick Start Guide Video Features You can configure display options from the Display control panel in Windows, and from the ATI Catalyst Con- trol Center as long as the appropriate video driver is installed. For more detailed video information see “ATI Video Driver Controls”...
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 12) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • Multi-In-1 Card Reader • TouchPad and Buttons/Mouse •...
Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives (see “Storage” on page C - 2) with a height of 9.5 mm.
Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 2). The Adjustment optical device is usually labeled “Drive D:”...
Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Features & Components DVD Regional Codes To change the DVD regional codes: Go to the Control Panel Double-click Device Manager (Hardware and Sound), then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialog box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
Features & Components Multi-In-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an ex- ternal mouse your op- Once you have installed the TouchPad driver (see...
Features & Components Gestures and Device Settings The Synaptics Gestures Suite application allows you to use a specific gesture (ac- Show Video tion) on the surface of the TouchPad to perform specific actions to manipulate doc- uments, objects and applications. You can get a clearer view of the gestures in- volved by clicking the...
Page 49
Features & Components Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the TouchPad surface and slide both fingers in the direction required (in a straight con- tinuous motion).
Page 50
Features & Components Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the TouchPad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, from the HD VDeck icon on the desktop or VIA HD Audio Adjustment Deck control panel The sound volume level is set using the volume The volume may also be adjusted by means of the Fn + F5/F6 key combination.
Page 52
Features & Components Expert Mode will allow you to access more advanced configuration menus. Figure 2 - 12 VIA HD Audio Deck (Expert Mode) “HDMI Audio Configuration” on page B - 14 for more information on the au- dio settings for HDMI. 2 - 12 Audio Features...
Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- USB Printer...
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. Wake On LAN AC/DC Adapter If you need your system setup to Wake ON LAN, Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ then see the instructions DC adapter will damage the computer and its components.
Power Management Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 59
Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color...
Power Management Energy Star Power Saving This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Taskbar Icon of inactivity. If you want to enable Energy Star power saving then follow these in- If the taskbar icon does structions: not appear then click the...
Power Management Battery Information Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Wireless Hot Keys • Lower the brightness level of the LCD display. The system will decrease LCD The computer’s wireless brightness slightly to save power when it is not powered by the AC/DC adapter.
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 70
Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
Page 71
Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 72
Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Drivers & Utilities Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the lat- est versions of most available operating systems haven’t built in drivers and utilities.
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc into the DVD drive and click Install Drivers/Op- Drivers Installer menu below.
Page 75
Drivers & Utilities Manual Driver Installation Driver for Windows 7 Page # Click Browse CD/DVD (button) in the Drivers Install- er application and browse to the executable file in the Video Page 4 - 5 appropriate driver folder. Page 4 - 6 TouchPad Page 4 - 6 Windows Update...
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...
Drivers & Utilities New Hardware Found Driver Installation Procedure If you see the message “New Hardware Found” dur- Insert the Device Drivers & Utilities + User’s Manual ing the installation procedure (other than when out- disc into the DVD drive and click Install Drivers (but- lined in the driver install procedure), click Cancel ton).
Drivers & Utilities AMD AHCI Driver If you have enabled AHCI mode in the BIOS (see “SATA Mode Selection (Advanced Menu)” on Windows Update page 5 - 9), and have not installed the AHCI driver at After installing all the drivers make sure you enable Win- system installation, then you should do so now as per dows Update in order to get all the latest security up- the instructions below:...
Drivers & Utilities Windows Experience Index Optional Drivers After the drivers are installed follow this procedure to See the pages indicated for the driver installation pro- ensure an accurate rating from the Windows Experi- cedures for any modules included in your purchase op- ence Index: tion.
Drivers & Utilities Wireless LAN Module 3.75G/HSPA Module See the introduction in “Wireless LAN Module” on See the introduction in “3.75G/HSPA Module” on page 7 - 2, and check the installation procedure. page 7 - 15, and check the installation procedure for the appropriate module.
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
BIOS Utilities The Setup Utility The Phoenix Setup utility tells the system how to configure itself and manage basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds...
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
BIOS Utilities SATA Port 1/2 (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Port 1/2. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable.
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to enable/disable the WLAN Power Setting control. If enabled then the system will remember the last power status of the Wireless LAN module e.g.
BIOS Utilities SATA Mode Selection (Advanced Menu) You can configure SATA (Serial ATA) control to operate in either IDE (native/ compatible) or AHCI (Advanced Host Controller Interface) modes from this menu. The SATA mode should be set to AHCI mode for this system (unless you are sure your hard disk can only operate in IDE mode).
BIOS Utilities Security Menu Security Menu changes make here affect the access to the Setup utility itself, and also access to your ma- chine as it boots up af- ter you turn it on. These settings do not affect your machine or network passwords which will be set in...
BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the PhoenixBIOS Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless you Password Warning choose to set a Password on Boot (see below). Many menu items in the PhoenixBI- If you set a boot pass- OS Setup Utility cannot be modified in user mode.
BIOS Utilities Boot Menu Figure 5 - 5 Boot Menu When you turn the computer on it will look for an operating system (e.g. Windows 7) from the devices listed in this menu, and in this priority order. If it cannot find the operating system on that device, it will try to load it from the next device in the order specified in the Boot priority order.
BIOS Utilities Exit Menu Figure 5 - 6 Exit Menu Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Set- up defaults that will return the Setup to its original state, and erase any previous changes you have made in a previous session.
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latch in the direction of the arrow.
Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 2).
Page 101
Upgrading The Computer Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and loosen screws & Remove the hard disk bay cover Figure 6 - 2 Hard Disk Bay Cover Removal Upgrading the Hard Disk Drive 6 - 5...
Page 102
Upgrading The Computer Grip the tab and slide the hard disk in the direction of arrow Lift the hard disk out of the bay Remove the screw(s) and the adhesive cover Hard Disk Screws & Reverse the process to install a new hard disk drive (do not forget to replace all the Cover screws and covers) The hard disks and cov-...
Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Fan Cable & Cover Locate the component bay cover and remove screws Carefully (a fan and cable are attached to the under side of the cover) lift up Make sure you recon- the bay cover.
Page 104
Upgrading The Computer Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device. Figure 6 - 5 Removing the Optical Device 6 - 8 Upgrading the Optical (CD/DVD) Device...
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- Fan Cable & Cover DIMM) DDRII (DDR2) type memory modules (see “Memory” on page C - 2 details of supported module types).
Page 106
Upgrading The Computer Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - Figure 6 - 7 RAM Module Release Latches The RAM module will pop-up, and you can remove it.
Page 107
Upgrading The Computer Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. The module’s pin alignment will allow it to only fit one way. Make sure the module Cover Pins is seated as far into the slot as it will go.
Modules & Options Chapter 7: Modules & Options Overview Wireless Device Operation Aboard Aircraft This chapter contains information on the following modules, which may come with your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.
Modules & Options Wireless LAN Module If you have included a 802.11b/g/n WLAN module in your purchase option, make Wireless Device sure that the Wireless LAN module is on before installing the driver. Operation Aboard Aircraft Use the Fn + F11 key combination (see “Function/Hot Key Indicators”...
Modules & Options Connecting to a Wireless Network in Windows 7 Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then double-click an access point to con- Network and nect to or click to Open Network and Sharing Center if you do not see a network Sharing Center you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net-...
Page 112
Modules & Options You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 113
Modules & Options Click the taskbar icon to see any currently connected networks. To disconnect from the wireless network you can click the taskbar wireless icon , click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se-...
Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. Wireless Hot Keys To access the Windows Mobility Center: The computer’s wireless function keys will not func- Click Start, and click Control Panel (or point to Settings and click Control...
Modules & Options PC Camera Module Before installing the PC Camera driver, make sure that the optional PC Camera is Latest PC Camera on. Use the Fn + F10 key combination (see “Function/Hot Key Indicators” on Driver Information page 1 - 9) to toggle power to the PC Camera module.
Modules & Options PC Camera Driver Installation 1. Use the Fn + F10 key combination to turn the camera module on. 2. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ PC Camera Screen DVD drive. Refresh 3.
Page 117
Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 118
Modules & Options Figure 7 - 5 Audio Setup for PC Camera Right-click 7 - 10 PC Camera Module...
Page 119
Modules & Options Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Pre-Allocating File Space Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see Set Capture File below).
Page 120
Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 121
Modules & Options Eliminating Screen Flicker If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 122
Modules & Options Zoom (not applicable to all camera modules) The camera program allows you to zoom the camera in and out (note the zoom function is not available in all camera model applications). Run the camera application from the desktop shortcut. Go to Zoom and select Zoom Out/Zoom In.
Modules & Options 3.75G/HSPA Module If you have included an optional 3.75G/HSPA (High Speed Packet Access) module (see “Communication” on page C - 3 for specification details) in your purchase op- tion, you will have the appropriate application (Mobile Partner) provided for your particular module.
Page 124
Modules & Options Turn off the computer, and turn it over and remove the battery (see page Locate the 3.75G USIM card cover and loosen screw , and then remove the Figure 7 - 8 USIM card cover USIM Card Cover Removal ...
Page 125
Modules & Options Lock the SIMLOCK by pushing it in the direction of the arrow in Figure 7 - 10 until it clicks into the lock position. Figure 7 - 10 SIMLOCK Lock 3.75G/HSPA Modules & System Wake Up Note that the 3.75G modules DO NOT sup- port system wake up on...
Page 126
Modules & Options Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see Table 1 - 4, on page 1 - 9) to toggle power to the 3.75G/HSPA module.
Modules & Options Mobile Partner With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Mobile Partner application. The Mobile Partner Wireless Device application allows you to directly access your HSPA internet service from the com- Operation Aboard puter.
Modules & Options Mobile Partner Application You will need to contact your service provider to obtain the exact details of how ex- actly to configure the settings on this page. Mobile Partner Help Profile Management To get help on Mobile Partner configuration Power on the 3.75G/HSPA module using the Fn +...
Page 129
Modules & Options Connecting to the Service Provider Power on the 3.75G/HSPA module using the Fn + key combination. Access the Mobile Partner application from the Start menu (Start > Programs/ All Programs > Mobile Partner), or by double-clicking the Mobile Partner icon on the desktop The software will run and you can select the Profile Name from the menu.
Page 130
Modules & Options When the connection is successful you can move the cursor over the network icon in the taskbar to display the connection information. Figure 7 - 14 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection.
Page 131
Modules & Options To disconnect click the Disconnect icon, or right click the taskbar icon and select Disconnect. Figure 7 - 15 Disconnect 10. The program will disconnect from the service provider. 11. The module will still be on, and you will need to press the Fn + key combination to turn it off.
Page 132
Modules & Options 12. If you click the Mobile Partner close icon a message will be displayed asking you to click OK to confirm the program exit and to terminate the connection. Figure 7 - 16 Exit Prompt 13. Exiting the program terminates the connection, but DOES NOT turn off the 3.75G/ HSPA module, and you will need to press the Fn + key combination to turn off the module (pay careful attention to this aboard aircraft - see...
Modules & Options Text Messaging Service In addition to standard internet services you may also send and receive SMS text messages using the Mobile Partner program, if your service supports SMS. Reading SMS Messages An icon will blink at the bottom of the Mobile Partner interface to notify you of any new messages received.
Modules & Options AMD AHCI Driver If you have enabled AHCI mode in the BIOS (see “SATA Mode Selection (Ad- vanced Menu)” on page 5 - 9), and have not installed the AHCI driver at system in- stallation, then you should do so now as per the instructions below: 1.
Modules & Options Bluetooth Module There are two Bluetooth module options available for this computer. If your pur- Wireless Device chase option includes the Combination Wireless LAN & V3.0 Bluetooth module Operation Aboard then install the driver as instructed overleaf (see “Bluetooth &...
Modules & Options Bluetooth Combo Driver Installation Note this driver is required only for the combo Bluetooth and WLAN module only. High Speed Bluetooth 1. Make sure the module is powered on, then insert the Device Drivers & Util- Data Transfer ities + User’s Manual disc into the CD/DVD drive.
Modules & Options Bluetooth & WLAN Combo Settings This information applies to the combo Bluetooth and WLAN module only. Bluetooth Module & Make sure the Bluetooth module is powered on. Resuming From Sleep Double-click the My Bluetooth application on the desktop (or access it from the Mode Programs/All Programs menu).
Page 138
Modules & Options Click General Settings to change the computer name that other Bluetooth devices will see, and click the tickbox to Allow Bluetooth devices to find this computer Click OK to confirm the settings. Figure 7 - 18 General Settings 7 - 30 Bluetooth Module...
Page 139
Modules & Options Click File Transfer Settings to Enable sharing of my files with other Bluetooth devices. Click OK to confirm the settings. Figure 7 - 19 File Transfer Settings Bluetooth Module 7 - 31...
Modules & Options Bluetooth Networking Setup This information applies to the combo Bluetooth and WLAN module only. Make sure the Bluetooth module is powered on. Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu). Click My Bluetooth Settings (see Figure 7 - 17 on page 7 - 29).
Modules & Options Bluetooth & WLAN Combo Module Configuration This information applies to the combo Bluetooth and WLAN module only. Bluetooth Module & Setup your Bluetooth Device so the Computer Can Find it Resuming From Sleep Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Mode Make the device discoverable (to do this check your device documentation).
Page 142
Modules & Options You will then be presented with a menu of options to select from. Figure 7 - 22 Bluetooth Device Options Click the appropriate button to connect to the device. 7 - 34 Bluetooth Module...
Page 143
Modules & Options You may need to allow the connection from your device, and you will then need to provide a passcode from the device. You can then enter the passcode on the computer and click OK to establish the connection.
Modules & Options Standard Bluetooth Configuration in Windows 7 Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device Make the device discoverable (to do this check your device documentation). Click Start, and click Con- trol Panel and then click To Turn the Bluetooth Module On...
Page 145
Modules & Options To Add a Bluetooth Device Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con-...
Page 146
Modules & Options Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing. Figure 7 - 26 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 147
Modules & Options To Change Settings for the Bluetooth Device Click the taskbar icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 154
Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
Page 156
Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 157
Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 158
Troubleshooting Problem Possible Cause - Solution Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot keys unique to the system’s regular keyboard may not work.
Page 159
Troubleshooting Problem Possible Cause - Solution The PC Camera module cannot be The module is off. Press the Fn + F10 key combination in order to enable the detected. module (see “Function/Hot Key Indicators” on page 1 - 9). Run the BisonCap program to view the camera picture.
Troubleshooting Uninstalling the AMD AHCI Driver Uninstalling the AMD AHCI driver is a two part process. Follow the instructions below if you need to uninstall the diver for any reason. Go to the Windows control panel. Click Device Manager (Hardware and Sound > Devices and Printers). Click the arrow next to IDE ATA/ATAPI controllers to open the sub-menu.
Page 161
Troubleshooting Click Yes to restart the computer. Click Restart Now to restart the computer again. After the computer has restarted return to the Windows control panel. 10. Click Programs and Features (Programs). 11. Click AMDSata and click Uninstall > Yes. 12.
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 163
Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 4 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 164
Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 165
Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 7 - Device Manager - Bluetooth Radio Bluetooth Connection Problems 8 - 17...
Troubleshooting Wake On LAN Setup Wake On LAN is an Ethernet computer networking standard that allows a computer to be turned on or woken up by a network message. If you need to have your computer Wake On LAN you will need to enable Computer Management settings as follows.
Page 167
Troubleshooting Click Advanced (tab). Scroll down to the bottom of the Property menu and select “Wakeup from Shutdown”. Click to select Enabled from the drop-down Value menu. Click OK to close the menu. 10. Close the Computer Management control panel. Figure 8 - 9 - Network Adapter Wake On LAN (Advanced) Wake On LAN Setup 8 - 19...
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
Page 171
Interface (Ports & Jacks) Item Description RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store.
ATI Video Driver Controls Appendix B: ATI Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Video Card ATI Video Driver Installation Options Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - Note that card types, Insert the Device Drivers &...
ATI Video Driver Controls ATI Catalyst® Control Center Adjust the video settings from the ATI Catalyst Control Center. ® ATI Taskbar Icon Open the ATI Catalyst Control Center (see page 13). The ATI Catalyst Control Click Advanced (button). Center can be accessed as A wizard will help you set up the display options, or you can click Advanced above or by double-clicking (button) to go to the ATI Catalyst Control Center (you can change the options...
Page 175
ATI Video Driver Controls The ATI Catalyst® Control Center provides additional video configuration con- trols and tools which allow quick access to features such as display options, 3D Set- tings, color and Help menus etc. Adjust settings from the Graphics and Options Help Menus menus at the top of the control panel.
ATI Video Driver Controls Attaching Other Displays Besides the built-in LCD, you can also use an external monitor/flat panel display as Function Keys your display device. The following are the display options: You can use the Fn + F7 •...
ATI Video Driver Controls Display Modes Single Only one of your displays is used. Duplicate Duplicate simply shows an exact copy of the Main display desktop on the other dis- play(s). This mode will drive multiple displays with exactly the same content, reso- lution, refresh rates and color quality etc.
ATI Video Driver Controls Configuring an External Display using the ATI CCC You can use the ATI Catalyst Control Center to configure any attached displays. Detect Displays Attach your external display to the external monitor port/HDMI-Out port and turn it Click Detect Displays (button) to automati- Open the ATI Catalyst Control Center.
ATI Video Driver Controls ATI CCC - Switching Display Modes Attach your external display to the external monitor port/HDMI-Out port and turn it Open the ATI Catalyst Control Center. Select Desktops & Displays from the Graphics menu in the top left of the screen. Attached displays will appear in the lower part of the screen (click Detect Displays to find any attached displays that do not automatically appear).
Page 180
ATI Video Driver Controls Select Duplicate or Extend from the menu. Click Yes to accept the settings. 10. If you need to change the display mode then disable the external display and configure as outlined here. Figure B - 5 Desktops &...
Page 181
ATI Video Driver Controls Configuring an External Display in Win 7 Attach your external display to the external monitor port/HDMI-Out port and turn it on. “Video Features” on page 1 - Go to the Screen resolution control panel (see Click the Detect button. The computer will then detect any attached displays.
ATI Video Driver Controls Click Apply to save any setting changes. Figure B - 7 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 183
ATI Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your external display to the external monitor port and turn it on.
ATI Video Driver Controls Theater Mode Theater Mode enables you to display video playback in full screen on a secondary monitor. Theater Mode can be configured from the Avivo Video > Theater Mode ™ tab in the Graphics Settings Tree View pane. Figure B - 9 Theater Mode B - 12 Theater Mode...
ATI Video Driver Controls PowerPlay™ PowerPlay in the ATI CCC allows you to set your graphics processor settings for ™ higher performance or longer battery life. Figure B - 10 PowerPlay ™ PowerPlay™ B - 13...
ATI Video Driver Controls HDMI Audio Configuration HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Configure the audio output as per the instructions below. Connect a device with HDMI support to the HDMI-Out port. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound), and click Playback (tab).
Page 187
ATI Video Driver Controls Double-click the connected HDMI device (or right-click and select Properties) to adjust the HDMI settings from the control panel tabs. Click OK to close the control panel (see notes overleaf). Figure B - 12 HDMI Device Properties HDMI Audio Configuration B - 15...
Page 188
ATI Video Driver Controls HDMI Notes • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party...
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Specifications Processor Display Storage AMD® Athlon™ x2 Dual Core 14.0” (35.56cm) 16:9 HD (1366 * 768) Super Multi One Changeable 12.7mm(h) Processor: TFT LCD Optical Device Drive with SATA (CD/DVD) Interface QL62 (2.0GHz) Memory One Changeable 2.5" 9.5 mm (h) HDD 65nm (65 Nanometer) Process with SATA (Serial) Interface Technology, 1MB L2 Cache &...
Specifications Interface Slots Communication Three USB 2.0 Ports Two Mini-Card Slots with PCIe (Slot 1) & 3.75G Module: USB (Slot 2) interface: One External Monitor Port UMTS/HSPDA-based 3.75G Module with USB Mini-Card Interface (Factory Option) One HDMI-Out Port Slot 1 for Half Mini-Card WLAN Module Quad-band GSM/GPRS (850 MHz, 900 One Headphone-Out Jack Slot 2 for 3.75G Mini-Card Module...
Need help?
Do you have a question about the C4505 and is the answer not in the manual?
Questions and answers
