Summary of Contents for Sirius Satellite Radio WH 90-110
- Page 1 To be kept by the user October 2010 Sirius WH 90-110 Wall Mounted Condensing Gas Boilers Installation, Operation & Maintenance Manual Working towards a cleaner future heating specialists...
- Page 2 Dear Customer, We are sure your new boiler will comply with all your requirements. Do not dispose of this booklet as it contains the information, which will help you to run your boiler correctly and efficiently. Do not leave any parts of the packaging (plastic bags, polystyrene, etc.) within children’s reach as they are a potential source of danger.
-
Page 3: Table Of Contents
contents instructions pertaining to tHe user 1. Instructions prior to installation 2. Instructions prior to commissioning 3. Commissioning of the boiler 4. Filling the boiler 5. Turning off the boiler 6. Prolonged standstill of the system. Frost protection 7. Servicing instructions instructions pertaining to tHe installer 8. -
Page 4: Instructions Prior To Installation
1. instructions prior to installation This boiler is designed to heat water at a lower than boiling temperature at atmospheric pressure. The boiler must be connected to a central heating system and/or to a domestic hot water supply system in compliance with its performances and output power. -
Page 5: Commissioning Of The Boiler
3. commissioning of tHe boiler To correctly light the burner proceed as follows: 1) Provide power supply to the boiler; 2) Open the gas cock; 3) Follow the directions given below regarding the adjustments to be made at the boiler control panel. Figure 1 IMportant: the instructions contained in this manual relating to the operation of the hot water... - Page 6 3.1 description of keys () This key can be pressed to set the central heating water output temperature as described in point 3-3. () This key can be pressed to set the hot water temperature as described in point 3-4. (10) central heating mode operating key key can be pressed to activate four boiler central heating operating modes;...
-
Page 7: Setting The Time
3.2 setting tHe time a) Press either of the keys to access the programming function; the display will show the letter P followed by a number (program line); Figure b) Press the keys until the display shows P1, referring to the time to be set; c) Press the keys to set the time;... - Page 8 3.5 setting tHe daily program for operation in central Heating and domestic Hot Water modes 3.5.1 setting the daily times for central heating mode operation - Press either of the keys to access the programming function; a) press these keys until the display shows P11, referring to the program start time; b) press the keys to set the time;...
- Page 9 3.7 table for user-settable parameters parameter parameter description Factory range setting Time of day setting ———- 0…23:59 Minimum central heating temperature setting (°C) 25..80 Start of first daily period of automatic central heating 6:00 00:00…24:00 End of first daily period of automatic central heating 22:00 00:00…24:00 Start of second daily period of automatic central heating...
- Page 10 3.8 fault Warnings and resetting tHe boiler If a fault occurs, a flashing warning code appears on the display. The fault warnings appear on the main display (figure 1 a) together with the symbol (Figure 4). To reset, press the reset button for at least two seconds.
- Page 11 3.9 fault Warnings table Fault Fault description action required code Outdoor temperature sensor failure Call the authorised service centre to check the wiring and/or replace the sensor. (*) NTC output sensor failure Call the authorised service centre to replace the sensor. (*) Hot water NTC sensor failure Call the authorised service centre to replace the sensor.
-
Page 12: Filling The Boiler
4. filling tHe boiler IMportant: Regularly check that the pressure displayed by the pressure gauge is between 1 to 4 bar, with the boiler not operating. In case the pressure is lower open the boiler filling tap. We recommend you open the tap very slowly in order to let off the air. In case pressure drops occur frequently have the boiler checked by a Qualified Service Engineer. -
Page 13: Instructions Pertaining To The Installer
8. general information The following remarks and instructions are addressed to Service Engineers to help them carry out a faultless installation. Instructions regarding lighting and operation of the boiler are contained in the ‘Instructions per- taining to the user’ section. Note that installation, maintenance and operation of the gas appliances must be performed exclusively by qualified personnel in compliance with current standards. -
Page 14: Boiler Installation
products. To avoid damaging metal, plastic and rubber parts, use only neutral cleaners, i.e. non-acid and non alkaline. The recommended products for cleaning are: SENTINEL X300 or X400 and FERNOX heating circuit restore. Please ensure to use this product, proceeding strictly in accordance with the manufactures instructions. Finally fill the system with the correct strength of central heating inhibitor. -
Page 15: Boiler Size
Figure 5B 11. boiler size Figure InstructIons pErtaInInG to thE 91.550.1 - GB/IE InstaLLEr... -
Page 16: Installation Of Flue And Air Ducts
12. installation of flue and air ducts We guarantee ease and flexibility of installation for the boiler thanks to the fittings and fixtures supplied (de- scribed below). The boiler is especially designed for connection to an exhaust flue / air ducting, with either concentric, vertical or horizontal terminal. - Page 17 HORIZONTAL CONCENTRIC FLUES Boiler Flue size number of Bends 90° Wh90 Ø110/160 Wh110 Ø110/160 vERTICAL CONCENTRIC FLUES Boiler Flue size number of Bends 90° Wh90 Ø110/160 Wh110 Ø110/160 CONvENTIONAL FLUE Boiler Flue size number of Bends 90° Wh90 Ø110 19,5 m 19 m 18,5 m 18 m...
- Page 18 Concentric outlet Figure 8 12.1 Horizontal flue terminal Ø 110/160 mm installation options L = refer to table 12.2 vertical flue terminal Ø 110/160 mm installation options This type of installation can be carried out both on a flat or pitched roof by fitting a terminal, an appropriate weathering tile and sleeve, (supplementary fittings supplied as options).
- Page 19 12.5 fan rpm updating depending on flue lengtH (e.g. figure 7) To ensure the correct rated heat output to the maximum and minimum heat input, it is necessary to update the speed (rpm) of the fan, it depends on the length of the flue (par. 12), in accordance with the installation of flue and air pipes as indicated in the tables below.
-
Page 20: Hydraulic System
13. Hydraulic diagram Applications and Installation Details 13.1 Hydraulic system 1 (Pumped heating circuits with remote control QAA73 or Room Thermostat, including hot-water tank, without and with primary loop) (*) optional extra without low loss header Figure 9a with low loss header and primary loop Figure 9b InstructIons pErtaInInG to thE 91.550.1 - GB/IE... - Page 21 • TS: Tank Sensor (QAZ36)* • B3: Room Control Module (QAA73)* • B1: Room Thermostat • B9: Outdoor Temperature Sensor (QAC34) (supplied with the gas boiler) • P1: Heating Pump • PDHW: Hot Water pump • PLP: Primary Pump (only for figure 9b) (*) Available Optional Extra •...
- Page 22 13.2 Hydraulic system 2 (Pumped heating circuits with Room Thermostat and compensated circuit with remote control QAA73, inclu- ding hot-water tank, with primary loop) • TS:Tank Sensor (QAZ36)* • B3: Room Control Module (QAA73)* • B1: Room Thermostat • B9: Temperature Sensor (QAC34) supplied with the gas boiler •...
- Page 23 Applications (pumps, sensor, remote control ...) have to be connected to terminal as follows (see also section 14): APPLICATION TERMINAL BOARD PRIMARY PUMP PLP M1: A – B DHW PUMP PDHW M3: 13 – 14 HEATING PUMP P1 M3: 11 – 12 DHW SENSOR TS M2: 7 –...
-
Page 24: Connecting The Mains Supply
14. connecting tHe mains supply Electrical safety of the appliance is only guaranteed by correct earthing, in compliance with the applicable standards and regulations. Connect the boiler to a 230V earthed power supply by means of the three-pin cable supplied with it make ensure the polarity is correct. - Page 25 14.1 connecting tHe pumps Turn the control box downward to access terminal boards M1 and M3 used for the electrical connections by removing the protective covers (see figure 12). terminals M1 a – b: connection of the primary loop pump for the heating system (PLP) Check the correct size and rating of the pump by referring to its hydraulic resistance table.
- Page 26 14.2 connecting tHe Hot Water tank sensor Remove the resistor from terminals 9-10 of terminal strip M2 (figure 13), and connect the hot water priority NTC sensor, which is supplied as an accessory. The sensing element of the NTC device must be located in the recess provided on the storage tank (figure 13). The temperature and on-off programming of the domestic hot water supply are selected directly from the boiler control panel, as described in this manual under the user instruction headings.
- Page 27 Figure 1 14.3 description of tHe electrical connections to tHe boiler Turn the control box downward to access terminal board M2 used for the electrical connections by removing the protective cover (see figure 13). terminals 1-: connection of SIEMENS model QAA73 room temperature regulator supplied as optional extra. Connection polarity is irrelevant.
- Page 28 14.4 connecting tHe Qaa73 temperature regulator The SIEMENS model QAA73 room temperature regulator, if required (optional extra) must be connected to terminals 1-2 of terminal board M2 in figure 13. The link across terminals 3-4, provided for connection of a room temperature thermostat, must be removed. The settings of the domestic hot water temperature and domestic hot water production schedule must be made using this device.
-
Page 29: Connecting The Outdoor Temperature Sensor
Here follows a list of the most commonly used parameters: Parameter Range Default value Line no. HC1 curve 2.5…40 Selection of central heating circuit temperature curve “kt” HC1 max. output 25…85 Central heating system maximum output temperature Type of building Light, Heavy Light Room compensation... - Page 30 TM = Flow temperature Te = Composite outside temperature Sth = Kt Curve Graph 2 Graph 3 b) With Qaa room temperature regulator: The temperature curve “kt” must be selected by setting parameter 70 “HC1 curve” of the QAA73 room tem- perature control device as described in section 14.4 “QAA73: parameters which can be set by the installation engineer (service)”.
-
Page 31: Gas Valve Adjustment
15. gas valve adjustment Carry out the following operations in the given sequence: 1) Calibration of the maximum heat output. Check that the CO measured on the flue, with the boiler operating at the maximum heat output, is the same as that shown in table 1. Otherwise, turn the regulation screw (V) on the gas valve. - Page 32 IMportant: In the case of conversion from natural gas to propane (LPG), the following operations must be performed before calibrating the gas valve as illustrated previously: • Replace the gas nozzle placed inside the gas valve (flow gas connection). To perform this operation it is necessary to remove the gas valve by undoing the inlet and outlet connections and unscrew the nozzle using round-nose pliers.
-
Page 33: Setting The Boiler Parameters
16. setting tHe boiler parameters The boiler parameters may only be modified by professionally qualified staff proceeding as follows: a) press the , keys on the boiler’s front panel together for about 3 s until the parameter H90 appears on the display;... -
Page 34: Control And Operation Devices
17. control and operation devices The boiler has been designed in full compliance with European reference standards and in particular is equip- ped with the following • overheat thermostat This thermostat interrupts the gas flow to the main burner in case the water contained in the circuit has ove- rheated. -
Page 35: Positioning Of The Ignition And Flame Sensing Electrode
18. positioning of tHe ignition and flame sensing electrode Figure 1 19. cHeck of combustion parameters To measure the performance of combustion products, the forced draught boiler models are equipped with two test points on the tapered coupling specifically designed for this purpose. One of the two test points is connected to the exhaust flue duct to allow measurements of the combustion products and efficiency. -
Page 36: Activating The Chimney-Sweep Function
20. activating tHe cHimney-sWeep function To facilitate measurement of the combustion efficiency and improve the cleanliness of the production products, the flue-sweeper function can be activated by proceeding as described below: 1) Press the (2-3) together until the pointer “ ” appears on the display alongside the symbol (about 3 seconds but no more than 6 seconds). -
Page 37: Boiler Schematic
22. boiler scHematic air/gas diaphragm Figure 0 Legend: Boiler drain point Manometer (water pressure gauge) siphon (condensate) central heating ntc sensor 105°c overheat thermostat Gas valve heat exchanger Flame detector electrode (ionisation probe) Main burner Ignition electrode air/gas mixture header Mixer with venturi Injector Flue thermostat... -
Page 38: Illustrated Wiring Diagram
23. illustrated Wiring diagram InstructIons pErtaInInG to thE 91.550.1 - GB/IE InstaLLEr... -
Page 39: Technical Data
24. tecHnical data Boiler model Wh Wh 90 Wh 110 category hp hp Nominal heat input (net/gross) 87.2 - 95.9 105 - 115.4 Reduced heat input (net/gross) 26.4 - 29.9 29.8 - 32.7 Rated heat output 75/60°C kcal/h 73,100 87,720 Rated heat output 50/30°C 91.6 110.3... - Page 40 Commercial sales Applications & Installations technical & service enquiries Our experienced technical support team are available to offer Tel: 0845 070 1055 advice on any aspect of heating system design and boiler Fax: 0845 070 1059 installation. Sales hotline: 0845 070 1056 Technical helpline: 0845 070 1057 Please contact:...
