Drawing 1
Drawing 3
I M P O R T A N T
Check that your detergent is suitable for
cleaning plastic parts. Some washing agents
are too alkaline (e.g. high levels of caustic
soda or ammonia) and totally incompatible
with certain types of plastic, causing them to
deteriorate rapidly.

MAINTENANCE

• BLADE

The quality of the cut depends mainly on the
sharpness of your blades and the degree of wear.
The blades are actually wearing parts, which
should be replaced occasionally to ensure consistent
quality in the final product.

• MOTOR SEAL

The motor seal around the motor shaft should be
lubricated regularly using a food safe lubricant.
In order to keep the motor completely watertight, it
is advisable to check the motor seal regularly for
wear and tear and replace it if necessary.
The motor seal can be easily replaced without
having to remove the motor, so we strongly advise
you to ensure that it is in good condition.

• LOCKING WASHER ASSEMBLY

The locking washer assembly is located on the
lower inside of the bowl and holds the bowl in
Drawing 2
place. If it becomes worn, it needs to be replaced.

• SCRAPER ARM

The scraper arm is equipped with rubber pieces
which are wearing parts. They should be replaced
occasionally to always ensure an optimum
efficiency of the scraper arm.
These pieces are easy to dismantle and to
reassemble.
Rubber piece to
scrape the bowl

• WEIGHT

Blixer ® 2
Blixer 3
®
Blixer 4
®
Blixer 4 V.V.
®
• DIMENSIONS (in mm)
Blixer ® 2 Blixer
A 389 A
B 281 B
C 210 C
165
D D

• WORKING HEIGHT

We recommend that you position the Blixer
stable worktop so that the upper edge of the cutter
bowl is at a height of between 1.20 and 1.30 m.

• NOISE LEVEL

The equivalent continuous sound level when the
Rubber pieces to
scrape the lid.
Blixer is operating on no-loads is less than
®
70 dB (A).
TECHNICAL
SPECIFICATIONS
Net Gross
9.8 kg 11 kg
14 kg 16 kg
15 kg 17 kg
15 kg 17 kg
® 3 Blixer ® 4
Blixer 4 V.V.
®
420
A 480
330
304
B
210
C 226
190
D 255
on a
®
