6. Commands description

6.1.

Escape commands for the contact interface

6.1.1. Sending escape commands to @MAXX prime

A developer can use the following method to send escape commands to @MAXX prime for the
contact interface
•
SCardControl method defined in PC/SC API

6.1.2. Escape command codes

Escape commands can be used by an application to configure @MAXX prime to function in a
mode that is not its default configured mode or to get specific information. To put the @MAXX
PRIME back into its default mode, either the @MAXX prime has to be unplugged and plugged
again or the application can send again the same escape command.
The following escape commands are supported by @MAXX prime for the contact interface
S.No. Escape message ID
1 CCID_ESC_GETINFO
2 CCID_ESC_SETMODE
3 CCID_ESC_GETMODE
4 CCID_ESC_GET_FW_VERSION
5 CCID_ESC_SET_POWER_ON_RESET_ORDER
6 CCID_ESC_EMV_LOOPBACK
7 CCID_ESC_APDU_TRANSFER
8 CCID_ESC_CLK_FREQUENCY
9 CCID_ESC_GET_SET_ETU
10 CCID_ESC_GET_SET_WAITTIME
11 CCID_ESC_GET_SET_GUARDTIME
12 CCID_ESC_GET_SET_EGT
13 CCID_ESC_GET_SET_ATR_TIMEOUT
14 CCID_ESC_POWER
15 CCID_ESC_ROUGH_TANSFER
16 CCID_ESC_GET_SET_PROTOCOL
17 CCID_ESC_GET_SET_TA1_RFU
M
ANUAL
Value
0x00
0x01
0x02
0x03
0x04
0x05
0x08
0x1F
0x80
0x81
0x82
0x83
0x84
0xC0
0xC1
0xC2
0xC3
