Logging in and
configuring
Configuration window
86-0948364-A
To log in and configure the appliance, follow the process described in Table 1,
"Configuration sequence" below.
Table 1: Configuration sequence
Actions
Configure the PC for IP address 192.168.0.2 by doing the
following:
1 Select Start > Settings > Control Panel.
2 Double-click Network Connections.
3 Right-click Local Area Network, and then click
Properties.
4 Select the Use the following IP address option, and
then enter 192.168.0.2 in the IP address field.
The default gateway IP address is the factory default address
of the SnapGear unit (192.168.0.1). DNS settings are not
required at this time.
Note: Because the PC and the SnapGear are isolated
during the initial configuration process, you can use any PC
IP address in the range of 192.168.0.2 through
192.168.0.254.
Log into the unit by doing the following:
1 Enter http://192.168.0.1 into a Web browser.
2 Enter the default user name root in the User name field.
3 Enter the default password default in the Password field.
4 Click OK.
Setting up SnapGear for VoIP

Logging in and configuring
