Powering On; Connecting - Secure Computing SnapGear Application Note

Setting up SnapGear for VoIP

Powering on

Powering on
Figure 1: SG565 after a
reset

Connecting

4
1 Do not connect any Ethernet cables. Plug the 5V DC mini-plug into the
back of the SnapGear appliance.
2 Plug the AC plug (the three-prong plug) of the power adapter into an
electrical outlet.
3 After 25 to 30 seconds, confirm the unit is in factory default mode by
resetting it. To reset, gently press the
within three seconds, one second apart. The unit will reboot into the factory
default mode.
Figure 1 shows the SG565 after a reset, but before being connected to the
network. All models except the SG300 power on with the front LEDs blinking
green when in the factory default mode.
Note:
When powering down the appliance, it is a good practice to unplug the AC
plug first in order to drain the power adapter, before unplugging the DC mini-plug.
To connect the appliance to the network:
1 Connect the supplied cable into Ethernet port A1 on the appliance.
2 Connect the other end of the cable to a PC or workstation Ethernet jack.
The PC or workstation should have a Java-enabled Internet browser such
as Microsoft Internet Explorer or Mozilla Firefox installed.
Erase button on the rear panel twice
86-0948364-A
