Campbell Hausfeld Air Powered Rivet Gun Operating Instructions Manual

See Warranty on page 4 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
BUILT TO LAST
Description
Professional air powered rivet guns are
air tools designed for riveting a variety
of materials, and can be used with up
to 3/16" steel rivets.
Unpacking
When unpacking this product, carefully
inspect for any damage that may have
occurred during transit.
General Safety
Information
This product is part of a high pressure
system and the following safety
precautions must be followed at all
times along with any other existing
safety rules.
1. Read all manuals included
with this product careful-
ly. Be familiar with the
controls and the proper
use of the equipment.
2. Only persons well acquainted with
these rules of safe operation should
be allowed to use the air tool.
Do not exceed the
CAUTION
!
maximum
operating pressure of the air tool (90
PSI). This can reduce the life of the
tool.
3. Do not exceed any pressure rating
of any component in the system.
4. Disconnect the air tool from the air
supply before changing tools or
attachments, servicing, and during
non-operation.
WARNING
!
Safety glasses and ear
protection must be worn
during operation.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2003 Campbell Hausfeld/Scott Fetzer
5. Do not wear loose fitting clothing,
scarves, neck ties or jewelry when
operating any tool. Loose clothing
or jewelry may become caught in
moving parts and result in serious
personal injury.
6. Do not depress trigger when
connecting the air supply hose.
7. Always use nose pieces designed for
use with air powered tools. Do not
use damaged or worn attachments.
8. Never trigger the tool when not
applied to a work object.
Attachments must be securely
attached. Loose attachments can
cause serious injury.
9. Protect air lines from damage or
puncture.
10. Never point an air tool at oneself or
any other person. Serious injury
could occur.
MANUAL
11. Check air hoses for weak or worn
condition before each use. Make
sure all connections are secure.
WARNING
!
Release all pressure from the
system before attempting to
install, service, relocate or perform any
maintenance.
12. Keep all nuts, bolts and screws tight
and ensure equipment is in safe
working condition.
13. Do not put hands near or under
moving parts.
14. Always secure workpiece in a vise or
clamp. Do not place hands on the
back cylinder when operating the
tool.
WARNING
!
the safety cap installed. Personal injury
can occur if the rivet gun is operated
without the safety cap (SV825800AV)
installed.
For parts, product & service information
visit www.chpower.com
Air Powered
Rivet Gun
!
working in awkward positions and
repetitive work motions can cause
injury to hands and arms. Stop using
any tool if discomfort, numbness,
tingling or pain occur and consult a
physician.
Assembly
SYSTEM SETUP
PLEASE REFER TO AIR TOOL AND SPRAY
GUN SET-UP (IN170102AV) FOR AIR
SYSTEM HOOK-UP INSTRUCTIONS.
Using fittings or air hoses which are too
small can create a pressure drop which
will result in a loss of power in the tool.
NOTE: Do not install a quick coupler set
between the tool and whip hose.
Before tool is connected to air, attach
safety cap to gun by tightening frame
cap nut to back of gun.
Pre-Operation
LUBRICATION
Air tools require lubrication
throughout the life of the tool. Proper
lubrication is the owner's responsibility.
Use Campbell Hausfeld air tool oil (Part
No. ST127000AV) to lubricate, clean
and inhibit rust in one step. Failure to
lubricate and maintain the air tool
properly will dramatically shorten the
life of the tool and will void the
warranty.
!
tion before initial use and before and
after each additional use.
!
Never operate the
rivet gun without
air supply before lubricating.
1. Turn the rivet gun on it's side so
Excessive exposure
WARNING
to vibration,
This rivet gun
CAUTION
requires lubrica-
Disconnect the
WARNING
rivet tool from the
that the air inlet is facing up.
IN243801AV 2/03
