[3] EXTERNAL VIEWS AND INTERNAL STRUCTURES

1. External components

2 3
1

2. Sensors and switches

No. Symbol Description
1 JCK_S W JAM cover open/
close switch
2 H_SEN Reverse sensor
4
5
6
13
10
7
3
4
5
Type Function and operation
Microswitch Detects that the JAM cover is
opened or closed.
Reflective sensor Detects that a sheet to be
inserted is transported to the
reverse sensor.
AR-CF2 EXTERNAL VIEWS AND INTERNAL STRUCTURES 3 - 1
No. Description
1 Paper feed tray Place blank or printed sheets to be
inserted in this tray.
2 Paper guide Adjust this guide according to the paper
size.
3 Top cover Open this cover to clear a paper jam.
4 Operator panel Operate the staple and punch unit with this
panel (or with the operator panel of the
main unit).
5 Paper guiding Unlock the paper guiding section to clear a
section paper jam.
6 Front cover Open this cover to remove jammed paper
from the finisher or saddle finisher.
12
11
1
8
9
6
2
Output
When the JAM cover is opened,
TP37 turns HIGH.
When a sheet is detected, TP1
turns HIGH.
Function
Product name
Manufacturer
(Model)
DE2L-FAAA HIROSE
CHERRY
PRECISION
SENSOR SANYO
(SNS - SPI-337-01)
