A L T M A N L I G H T I N G , I N C .
SS-SP*-100 and SSW-SP*-100
Spectra-STAR PAR™ Series
Installation and Instruction Manual
2010 Altman Lighting, Inc.
57 Alexander Street, Yonkers
New York 10701 U.S.A.
Phone 914.476.7987 •• Fax 914.963.7304
(Specifications are subject to change without notice)
Copyright© 2010 Rev 2010-08-30
www.altmanlighting.com
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS-SP*-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Altman SS-SP*-100

Summary of Contents for Altman SS-SP*-100

  • Page 1 A L T M A N L I G H T I N G , I N C . SS-SP*-100 and SSW-SP*-100 Spectra-STAR PAR™ Series Installation and Instruction Manual 2010 Altman Lighting, Inc. 57 Alexander Street, Yonkers New York 10701 U.S.A.

  • Page 2: Safety Instructions

    SAFETY INSTRUCTIONS INSTRUCTIONS DE SÛRETÉ LES INSTRUCTIONS AU SUJET D' UN INSTRUCTIONS PERTAINING TO A RISK OF RISQUE D'INCENDIE LE CHOC FIRE, ELECTRICAL SHOCK, OR INJURY TO ÉLECTRIQUE, OU LA BLESSURE AUX PERSONS FOR SS-PAR-100 SERIES LED PERSONNES POUR SS-P AR-100 LIGHTING FIXTURES.

  • Page 3: Packing List

    I N S T A L L A T I O N A N D I N S T R U C T I O N M A N U A L SS-SP*-100 and SSW-SP*-100 Spectra-STAR PAR™ LED Series Solid State Lighting Fixture...

  • Page 4: Setup And Installation

    I N S T A L L A T I O N A N D I N S T R U C T I O N M A N U A L SETUP AND INSTALLATION Unpacking Remove the LED lighting fixture from its shipping box. Set the unit down on a flat surface before proceeding. Lamping and Re-lamping The LED lighting fixture is provided with an integral LED light engine.
  • Page 5 The LED lighting fixture complements the Theatrical and Architectural Lighting Industry and adds to the expanding Spectra-LED™™ family of solid state LED luminaires offered by Altman Lighting, Inc. Four-Colors: Red, Green, Blue, and Amber for more color combinations and better CRI.

  • Page 6: Operation

    I N S T A L L A T I O N A N D I N S T R U C T I O N M A N U A L OPERATION ( Firmware Version: V2.2.1 Date: 2010-08-23) SETTINGS There are 3 buttons below the 3 digit LED display on the side of the unit.
  • Page 7 I N S T A L L A T I O N A N D I N S T R U C T I O N M A N U A L EXAMPLE: Let's say that we want to select personality #05. We enter on the display.
  • Page 8 I N S T A L L A T I O N A N D I N S T R U C T I O N M A N U A L RESOLUTION is selectable as either: 8 Bit (one DMX channel per color) this is normal resolution, 16 Bit (two DMX channels per color Coarse+Fine high resolution similar to moving lights).

  • Page 9: Fixed Color Mode

    I N S T A L L A T I O N A N D I N S T R U C T I O N M A N U A L STAND-ALONE EFFECTS (does not require a control console): Note: stand-alone effects from a single unit will control other units connected via DMX cable to all synchronize.

  • Page 10: Locked Mode

    I N S T A L L A T I O N A N D I N S T R U C T I O N M A N U A L Locked Mode To Lock (or unlock) the buttons: >Wait a few seconds until the display goes blank, >...
