Amana GUC* User's Informational Manual

Gas fired warm air furnace
Hide thumbs Also See for GUC*:
Table of Contents

Advertisement

Quick Links

See also: User's Information Manual
GUC*, GUX*, GUD*
Gas Fired Warm Air
Furnace
WARNING
If the information in these instructions is not
followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
—Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
—What to do if you smell gas:
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
—Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
WARNING
Should overheating occur or the gas supply
fail to shut off, turn off the manual gas con-
trol valve to the furnace before shutting off
the electrical supply.
THE INSTALLATION AND SERVICING OF THIS EQUIPMENT MUST BE PERFORMED BY QUALIFIED,
Due to policy of continual product improvement, the right is reserved to change specifications and design without notice.
Effective: September 1995
RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION
EXPERIENCED TECHNICIANS ONLY.
User's Informational
Manual
Affix this manual, Installation Instructions and Specification
Sheet adjacent to the furnace.
WARNING
To avoid death, personal injury or property
damage, do not use this furnace if any part of
the furnace has been under water. Immedi-
ately call a qualified service technician to
inspect the furnace and to replace any part of
the control system and any gas control hav-
ing been under water.

Important Note To The Owner

It is important that you fill out the owner's registration card
and mail it today. This will assist Amana in contacting you
should any service or warranty information change in the
future. When filling in the registration card, be sure to include
the Model, Manufacturing and Serial Numbers, plus the
installation date. If the registration card cannot be located,
please call 1-800-843-0304 to register the furnace.
Your warranty certificate is also supplied with the unit. Read
the warranty carefully and note what is covered. Keep the
warranty certificate in a safe place, so you can find it, if
necessary.
10318810

Advertisement

Table of Contents
loading

Related Manuals for Amana GUC*

Summary of Contents for Amana GUC*

  • Page 1: Important Note To The Owner

    • Do not try to light any appliance. It is important that you fill out the owner’s registration card and mail it today. This will assist Amana in contacting you • Do not touch any electrical switch; do should any service or warranty information change in the not use any phone in your building.

  • Page 2: Table Of Contents

    IV. Inspection of Furnace (Qualified Servicer Only................9 Inspection Procedures ................................9 V. For More Information ........................10 VI. Safety Labels ..........................11 Amana Refrigeration, Inc. Fayetteville, TN 37334 ATTENTION INSTALLING PERSONNEL As a professional installer you have an obligation to Remember, it is your responsibility to install the know the product better than the customer.

  • Page 3: General Information

    I. General Information WARNING This furnace is built to provide many years of safe and PERSONAL INJURY HAZARD dependable service, providing it is properly installed and maintained. However, abuse and/or improper use can shorten To avoid personal injury or fire, minimum the life of the furnace and create hazards for you, the clearances to combustible surfaces must be homeowner.

  • Page 4: Air Requirements

    WARNING To prevent possible death or personal injury This product contains or produces a chemi- due to asphyxiation, Amana Condensing Gas cal or chemicals which may cause serious Fired Warm Air Furnaces must be Category illness or death and which are known to the IV vented.

  • Page 5: Indoor Humidity

    WARNING Propane Furnaces Only To prevent possible death or personal injury WARNING due to asphyxiation, common venting with PERSONAL INJURY HAZARD other induced draft appliances is not al- lowed. Carefully read and follow all instruc- To avoid death, personal injury or property tions given in this section.

  • Page 6: Operation

    II. Operation Electrical Components This furnace is equipped with an electronic ignition device which lights the burners. It also has a power vent blower to Thermostat exhaust combustion products. There are many types and styles of thermostats but the operation is usually similar. BE SURE TO BECOME FAMIL- Keep both doors in place except for inspection and mainte- IAR WITH YOUR THERMOSTAT.

  • Page 7: Roll-Out Protection Device

    Flame Roll-Out Protection Device Figure 3 White Rodgers Model 36E Figure 6 Roll-Out Protection Device (GUC and GUX) Flame Roll-Out Protection Device Figure 4 Honeywell Model VR-8205 Gas Control Valve Lever Outlet Pressure Tap (In ON Position) (Side of Valve) Figure 7 Roll-Out Protection Device OUTLET...

  • Page 8: Turning Off Furnace

    III. Maintenance Turning Off Furnace 1. Set the thermostat to lowest setting. AT LEAST ONCE A YEAR, BEFORE THE HEATING SEA- SON BEGINS, have the furnace checked by a qualified 2. Turn off the electrical power supply to the furnace. servicer to be certain there is adequate combustion air and 3.

  • Page 9: Side Air Return

    Side Air Return Bottom Air Return 1. Lift filter above bottom 2. Tilt filter to clear rail. The filter is held in place by a sheet metal retainer strap rail. (Figure 9). To change and clean the filter, slide one end of the retainer towards the front and remove filter.

  • Page 10: Inspection Of Furnace

    IV. Inspection of Furnace (Qualified V. For More Information Servicer Only. Most questions can be answered by the local Amana dealer. Check with dealer first if needing any further information regarding the operation, maintenance, or service of the WARNING furnace.

  • Page 11: Safety Labels

    VI. Safety Labels NOTE: If safety labels are missing or illegible, contact the installing dealer or Amana Customer Service Department for ordering information. 11072703 THIS COMPARTMENT MUST BE CE COMPARTIMENT DOIT RESTER W ARNING: AVERTISSEMENT: CLOSED EXCEPT WHEN SERVICING FERME, SAUF POUR L'ENTRETIEN...
