O P E R A T I N G I N S T R U C T I O N S
Neo

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Neo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eliet Neo

Summary of Contents for Eliet Neo

  • Page 1 O P E R A T I N G I N S T R U C T I O N S...
  • Page 2 © ELIET Copyright 2009 ELIET. All rights reserved. All textual material, drawings, fi gures, diagrams, graphs, etc., included in this ELIET booklet are protected by copyright and also by other intellectual property rights. Nothing from this information may be copied for commercial goals or distributed and/or changed or reposted for other goals.

  • Page 3: Introduction

    To be eligible to obtain warranty you must mail the completed warranty card within one month of the date of purchase to the address stated below. ELIET EUROPE NV, Diesveldstraat 2, B – 8553 Otegem (Belgium) Tel. +32 56 77 70 88 - Fax +32 56 77 52 13 REGISTER YOUR PRODUCT ONLINE AT WWW.ELIET.EU.

  • Page 4: Welcome

    Welcome to the family of ELIET users. We would like to thank you for the confi dence that you have placed in ELIET and we are con- vinced that you have purchased the very best machine. The operating life of your ELIET machine depends to a great extent on how you care for your machine.

  • Page 5: Table Of Contents

    Table of Contents 1. Introduction ..........................3 1.1 Carefully read this operating instruction manual................3 1.2 Identifi cation Data – ELIET NEO ......................3 2. Warranty ............................ 3 2.1 Warranty card ............................3 3. Welcome ............................. 4 4. Table of Contents ........................5 5.
  • Page 6 9.4 Operating the machine ........................32 9.4.1 Before starting work ........................32 9.4.2 During the work ..........................32 9.5 Emptying the collection box ......................36 9.6 What to do about motor stalling .......................38 10. Transporting the machine ....................39 11. Maintenance ..........................42 11.1 General ..............................42 11.2 Maintenance schedules ........................43 11.2.1 Special maintenance........................43 11.2.2 Periodic maintenance schedule ....................

  • Page 7: Operator Safety Warnings

    If you apply a working method, action or tech- nique as the user that is not explicitly recommended by ELIET, ensure in any case that this will not represent a danger for bystanders.

  • Page 8: Main Parts

    6. Main parts To fully understand the content of this operator's manual you need to be fully conversant with the terminology used for the descriptions. In this chapter you can fi nd a set of parts identifi ed by name. It is a good idea to take time to study the machine beforehand for an improved under- standing of the descriptions provided in this user manual.

  • Page 9: Motor

    For your information : Your ELIET dealer is at your service, ready to provide you with maintenance or advice so that your ELIET machine always remains in optimal condition. Original ELIET parts and lubricants can be obtained from your ELIET dealer. These serv- ice parts are manufactured to the same stringent accuracy requirements and standard of craftsmanship as the original equipment.

  • Page 10: Set-Up

    Caution: For your safety, use only genuine ELIET parts on ELIET machines. The list of original replacement parts and their ordering code can be consulted online by visiting www. eliet. eu. Set-up The machine can be found in two set-ups.

  • Page 11: Safety Instructions

    These two set-ups are only for storing or transporting the machine. Never work with a machine in the storage set-up. No other set-up is recognised by ELIET whatsoever as being safe. ELIET prohibit users using, moving, transport- ing or storing this machine in any other than the set-ups described above.
  • Page 12 C. Three pairs of icons have been added in relief at the front in the feeding hopper always in the line of vision of the opera- tor whilst working. These icons point to dangers that are real around and at the feeding hopper. This icon warns about the danger of the turning blades at the end of the feeding hopper.
  • Page 13 E. Two icons are shown in relief on the sliding latch of the col- lection box. These icons can be seen perfectly when the collec- tion box is positioned in the machine or when the sliding latch. This icon warns of danger of hand injuries. The collection box is the closing and screening off provision for the discharge side of the machine.
  • Page 14 Part safety stickers that include safety information that are damaged due to use or cleaning, become illegible or have been removed must be immediately replaced. Stickers and parts can be obtained from your offi cial ELIET dealer. • Sticker : BQ 501 220 040 •...

  • Page 15: Safety Features

    fl aps open when the machine is operational. Choice of material : ELIET aims at sustainability and also offers a guarantee with regard to user safety regarding unforeseen conditions due to deciding to use high-tech composite plastics to make the machine.
  • Page 16 Caution : If parts of this safety wear is worn, faulty or lost, ELIET recommends purchas- ing new ones that meet the prevention standard before starting the next work...

  • Page 17: Safety Instructions

    • After you purchase the machine, allow the dealer or a professional to give you some instruc- tion regarding the correct use. • Carefully observe all safety instructions when using the ELIET machine ! Carefully read all the instructions relating to the use of the machine. All these instructions relate to your personal safety.

  • Page 18: Careful And Proper Use

    • Never work with a machine that has not been fully assembled. Check the fi nish of the machine to ensure compliance with the instructions provided in this manual. • You must never use the machine without a feeding hopper, feed restriction (on the NEO) or anti-projection fl aps.

  • Page 19: Responsibilities Of The Operator

    • Children (younger than 16 years of age) and animals must be kept well away (> 3 m) from the machine. • ELIET recommend that the machine should not be lent to others. However, if this is done, only lend it to persons who are conversant with the machine. Always ensure that the user is aware of the potential hazards, and ensure that he reads the manual before he uses the machine.

  • Page 20: Danger Zone

    7.3.5 Danger zone • During the work, do not allow bystand- ers to enter the risk zone that stretches up to 3 m around the machine. • By preference, the operator should stand at the back of the hopper if he or she wishes to deposit green waste in the hopper.

  • Page 21: Periodic Maintenance

    • Always wear suitable clothing for performing maintenance. 7.3.7 Limits of the machine • The branch diameter that ELIET prescribes for this model as the maximum is 30 mm (NEO) and 35 mm (NEO en NEO ). This diameter must not be exceeded in the interest of your own personal safety and to ensure a long life cycle of the machine.

  • Page 22: Guidelines Related To The Electric Machines

    • The overcurrent protection of the mains network will have a fuse of at least 13A (in case of the NEO) and at least 16A (in case of the NEO ). The overcurrent protection must have a response time that is in accordance with the C curve.
  • Page 23 • The plug that is connected to the machine must correspond with the model as described in the specifi cations below. • Female CE plug with fi ve pins (L1, L2, L3, PE, earthing) 16 A (380 V) The direction of rotation of the blade shaft must be checked once the extension cord has been connected.
  • Page 24 Warning : Electrocution can occur should you connect a plug to the electric mains while your hands are wet. • It is forbidden to operate the machine during rainy weather. Never expose the machine to water ingress. Warning : Electrical equipment may cause short circuits when exposed to water and mois- ture.

  • Page 25: Dealer Preparation

    See the list with tightening torques in the annex. • ELIET machines are packaged in accordance with common rules that apply for such transpor- tation. Deliveries will always be ex factory. ELIET cannot, therefore, be held liable for damages that occur during transportation.
  • Page 26 • User manual and warranty card (NEO, NEO , NEO • Paddle (NEO) • Accessory for disassembling the blade shaft (NEO, NEO , NEO • Sticker with a message to remind the user to tighten the blades (NEO, NEO , NEO...
  • Page 27 • Screw in the 12 screws completely so that the screw head is completely sunken into the recess of the hole (max. tightening torque : 2 Nm). Use a Z2 cross head screw driver. The NEO and NEO models are supplied with the feeding hop- per non-assembled.
  • Page 28 The dealer will also point out to the customer how he or she can change the direction of rotation of the machine in case of the NEO . The machine can, after all, rotate in the opposite direction if the extension cord or the domestic mains supply have changed the cabling connection arrangements.

  • Page 29: Operating Instructions

    Operating instructions Preliminary checks Caution : Before commencing the work, it is recommended to get into the habit of checking the following points. Checklist 1. Satisfy yourself that the chipping blades are fi rmly in place and in good condition. For safety's sake, tighten the blade bolts.

  • Page 30: Starting And Stopping The Motor

    • If the plug of the cord does not match the one of the machine, you can order a suitable exten- sion cord from your ELIET dealer (fi nd an authorized ELIET dealer near you by visiting www. eliet.eu).

  • Page 31: Stopping The Motor

    A fault or wear to the brake may mean that the machine may need a longer braking distance, which may represent an injury risk. Therefore, always be very careful. If required, have the machine checked by your offi cial ELIET dealer.

  • Page 32: Operating The Machine

    The machine will also stop if : • You pull out the plug of the extension cord from the machine. • You slide the collection box from the machine. • You loosen the tightening button of the see-through window. Caution : Never pull the cord when disconnecting the plug.
  • Page 33 Caution : Wear your personal protective equipment when the motor is running. This means the following : Gloves, safety goggles and ear defenders. • Be careful when performing work. While operating the machine, focus your concentration completely on the work. •...
  • Page 34 • Short truncated trunks without foliage ( ± 10 to 15 cm) represent a certain risk when chipping. When they come into the chipping chamber, they may be pulled into the blade system in an un- controlled way and without resistance. This may jam the machine. Ensure you leave branches as whole as possible when pruning.
  • Page 35 Caution : If the chipping chamber gets clogged up, switch off the machine to remove the blockage. Ensure that you do, however, wait for the blades to come to a complete standstill before carrying out any operation on the machine. Always disconnect the plug from the mains as a safety precaution.

  • Page 36: Emptying The Collection Box

    Emptying the collection box • The collection box can fi ll up completely in less than 6 minutes when continuously chipping average sized wood. When the level of chippings reach the top of the collection box, it must be emptied. This can be easily checked in two ways : •...
  • Page 37 If the plastic collection box is broken, you can order a new one from your offi cial ELIET dealer: 2 x stock no. : BR 930 010 110 (Find an authorized ELIET dealer near you by visiting www.eliet.eu.)

  • Page 38: What To Do About Motor Stalling

    8 . Should the motor make an abnormal humming noise, this may point to a blockage and the issue must be further investigated or an offi cial ELIET dealer must be consulted. 9. Should the green start button immediately protrude again, this may mean that the motor is still overheated and that you should allow it to cool down.

  • Page 39: Transporting The Machine

    Transporting the machine Caution : Before transporting the machine, check whether the hinge joint for the wheel undercar- riage has been fi rmly tightened. • Do allow only responsible adults move or transport the machine. • In addition, do make sure children, persons untrained in the use of the machine or animals do not enter within 3 m radius when transporting the machine.
  • Page 40 • If you wish to move the machine over a large distance, always fi rst empty the collection box before moving the machine. (See § 9.5.) • You can push the machine forward but the preferred option is to pull the machine behind you. •...
  • Page 41 • Be careful and composed when loading and unloading the chipper so that the machine does not tip over and give rise to an accident. • When walking up a slope push the chipper out in front of you facing uphill. •...

  • Page 42: Maintenance

    11.1 General ELIET recommend that the machine should be brought to an offi cial ELIET dealer for a major overhaul each year. (Find an authorized ELIET dealer near you by visiting www.eliet.eu.) Your ELIET dealer is always at your service for maintenance and advice. Your dealer will stock genuine ELIET service parts and lubricants.

  • Page 43: Maintenance Schedules

    Caution : When performing maintenance, always wear gloves, and also safety glasses for some operations. These are supplied as standard with the machine. 11.2 Maintenance schedules 11.2.1 Special maintenance A Special maintenance of the blades The blades will take up their fi nal position once they have been mounted on the blade shaft after a short break-in period.

  • Page 44: Periodic Maintenance Schedule

    11.2.2 Periodic maintenance schedule Caution : Before performing any maintenance, stop the motor and disconnect the exten- sion cord from the machine. Wear suitable clothing. A. Daily maintenance • Clean the machine (§ 11.3). • Clean the cooling system (§ 11.3.). •...

  • Page 45: Cleaning The Machine

    11.3.1 The importance of cleaning ELIET recommend cleaning the machine after each use. We recommend using every cleaning event to perform an inspection where you check component and machine integrity. You can, thus, intervene on time to prevent faults and failures. This will ensure that the service life of your machine is improved.

  • Page 46: What Does Cleaning Mean

    If any problems are found, fi rst conduct the necessary replacements and/or repairs. Visit your offi cial ELIET dealer. (Find an authorized ELIET dealer near you by visiting www.eliet.eu.) Cleaning the machine means more than just cleaning the outside. Open all protections so that you can also clean the concealed areas.
  • Page 47 • Stickers used to indicate safety messages that are no longer legible, must be immediately replaced. Obtain these original stickers from your ELIET dealer. (Part numbers can be found in section 7.1.) • Compressed air is a handy tool to easily blow out and, thus, clean a number of parts.

  • Page 48: Maintenance Procedures

    • Open the chipping chamber (read annex 2). Pay particular attention to the following : Garden waste chipping with the ELIET chipping system takes place in two steps. We fi rst have the contact of the blades with the garden waste when chopping takes place where the cutting block can be found.
  • Page 49 Each of these chipping actions set certain criteria that the blades must meet for optimal chipping effi ciency: A) The top of the blade, in particular, is important with regard to the primary chipping. Since the blades act as splitting blades, the cutting angle is essential because this forms the key that will cleave through the wood.

  • Page 50: Sharpening The Shredding Knives

    11.4.2 Grinding the blades. Correct and timely grinding of the chipping blades will extend blade life. (ELIET recommend the following : Grind after at least every 10 working hours.) Preparatory warnings • Always wear safety glasses and hearing protection when grinding blades. Wearing gloves is also mandatory when performing any maintenance.
  • Page 51 This will ensure for very short grinding times and you will always have the best possible cutting edge. (ELIET recommend the following : Every 10 working hours.) •...

  • Page 52: Reversing And Changing Chipper Blades

    • A NEO blade shaft has been constructed from two identical blade discs that each contain 6 blades. • Although the blade discs are identical, they are offset...
  • Page 53 • The two blade discs have been welded on the central shaft. This shaft is not symmetrically positioned with regard to the volume of the two blade discs: - On one side, there is a long protruding shaft section in which a large bore is provided that is meant for sliding on the motor shaft: This side will be referred to as follows from now on : The motor side (M)”...
  • Page 54 Remove and refi t one blade at a time. This ensures that reversal is performed in an orderly manner. TIP : There are 36 bolt connections in each blade shaft. ELIET recommend using a pneumatic ratchet wrench to quickly loosen these. Place a ring spanner on the bolt head and loosen the nut using the ratchet wrench ratchet.

  • Page 55: Work Method For Replacing The Blades

    11.4.3.2 Work method for replacing the blades New sets of blades are available form your ELIET dealer under the following part number : BU 401,100,102 • Stop the machine and disconnect the power supply extension cable from the machine.
  • Page 56 • You may not simply randomly reinstall the blades. A specifi c order needs to be respected. • Number the blade positions on the blade disc from 1 to 6 to ensure mistakes cannot be made. Start numbering with the right blade position that shows a notch and number clock- wise (as viewed from the tightening side).

  • Page 57: Lubricating Or Replacing The Nylon Bearing

    • Follow the same procedure for the second blade plate. • Perform a check to verify whether the blades have been installed correctly: Ap- ply the following rules : 1. All blades (2 per blade disc that have been positioned at an angle on the blade disc and are oriented towards the wall of the chipping chamber must always be pointing with their back (R)
  • Page 58 The blade shaft is retained in its position by a nylon sleeve bearing that is mounted in the window cover to limit the blade shaft to move and to ensure that the blades do not touch the chipping chamber. When there is no load, the blade shaft will not come into contact with the sleeve bearing.

  • Page 59: Replacing The Screw Of The See-Through Window

    • Ensure you do not lose the spring when you remove the bolt. (Should you lose it, the part Nr is BV 902 030 010.) • Order the bolt with number BR 930 010 200 and the lock clip with number BD 010 000 100 at your authorized ELIET dealer .
  • Page 60 • Refi t the bolt in the provided hole of the window. Refi t the spring as indicated in the above drawing. • Screw the lock clip on to the thread all the way. Note : The lips of the lock clip should be facing the bolt. •...

  • Page 61: Winterizing The Machine

    • Never position the machine in the immediate environment of a heat source or a naked fl ame. (Keep at least a 2 m distance.) Winterization • The NEO has been designed in such a way that the use of space when it is stored can be optimised. By folding the...
  • Page 62 • The machine weighs more than 40 kg. By prefer- ence, two persons should lift the machine and hang it from its tubular frame from the NEO wall hook. Caution : Never try to lift the machine on your own (max. lifting weight per person = 30 % of the body weight).

  • Page 63: Equipment Specifi Cations

    36000 (chopping movements/min) Yield ( full wheelbarrows/hour) Blade shaft Two discs with in total 12 blades Blades 12 ELIET RESIST blades Chipping technology ELIET patented Chopping Principle™ Chipping width 130 mm 130 mm 130 mm Tranmission Direct Direct Direct (rotor)

  • Page 64: Annexes

    The machine has been designed with a folding undercarriage to compactly store the machine and/or to transport the machine in a boot of a car. This ensures that the machine’s dimensions can be signifi cantly reduced: NEO : Normal dimensions : L x W x H :...
  • Page 65 1. Working set-up The wheels and the tubular frame rest on the fl oor. The hous- ing (upper part) of the machine is positioned straight into the extension of the tubular frame. Line marking has been provided on the housing and on the hinges. In the working set-up, the line markings are in each other’s extension.
  • Page 66 3. Proceed as follows : Caution : Always switch off the motor and disconnect the extension cord from the power supply when you fold the machine. Warning : The machine weighs a good 40 kg net. The upper part of the machine will no longer be a close fi...
  • Page 67 • Lift and move the upper part of the machine ap- proximately half a metre forward so that the wheelbase tilts over the front tube that is press- ing against your foot. • Next, take the upper part to the ground until this is resting near the bottom with its open bottom.

  • Page 68: B2 Opening And Closing The Chipping Chamber

    • Tilt the machine down for the hopper to rest on the ground (NEO & NEO ) or against the tubular frame (NEO). • Slightly tighten the rotary knob (clockwise) ; however, in this position the pivot hinge will not securely lock into the toothed clamp.
  • Page 69 • Completely loosen the rotary knob until it retracts. • Turn and open the see-through window until it abuts against the housing. Caution : Ensure that you do not hit the open see-through window during maintenance. This may cause the pivot point to break. •...
  • Page 70 If a few of these ribs have broken off, replace the see-through window as a precaution. (Consult your authorized ELIET dealer.) (Order Nr. BR930 010 070) • If the see-through window hits the stop, screw the screw button in to secure it.

  • Page 71: B3 Removing The Blade Shaft

    Removing the blade shaft • Always switch off the machine and disconnect the extension cord from the machine prior to removing the blade shaft. Caution : You will come in contact with the blades when performing this maintenance. They may be razor sharp and, therefore, there is a real danger of injuring your hands.
  • Page 72 • Tighten the bolt further whilst releasing the conical clamp fi xing coupling the blade shaft to the motor shaft. Once some stress is put on the bolt, axially hit the bolt head with a hammer. This impact can be suffi cient to loosen the clamping. If this is not the case, repeat this proce- dure until the is released.

  • Page 73: B4 Reversing The Supply Polarity Of The Plug

    Reversing the supply polarity of the plug The NEO is equipped with a 3-phase motor. The machine comes with a standard plug (16 amp) fi tted on the left and suitable for connection to a 3-phase 380V supply. This red CEE plug has 5 pins: L1, L2, L3, N, and PE.

  • Page 74: B5 Maintenance Schedule

    Damage may be caused and the operator and/or third parties will be running increased risks. ELIET EUROPE NV cannot be held liable for the con- sequences that failure to perform maintenance would entail. You may also loose...

  • Page 75: B6 List With Torque Values

    List with torque values Bolt head acc. to. DIN 931,912 ed. Thread Strength 10.9 Normal thread 1050 1100 1550 1450 2100 Fine thread M8 x 1 M10 x 1.25 M12 x 1.5 M14 x 1.5 M16 x 1.5 M18 x 1.5 M20 x 1.5 M22 x 1.5 M24 x 2...

  • Page 76: B7 Hazard Analysis

    Hazard analysis Below you will fi nd a list of dangers and risks that are linked to storing away, transporting or using the chipper. Take note of these dangers and avoid these risks by following the instructions contained in this manual. Be aware that it is not just the user who runs a risk but also third par- ties can be exposed to these risks.

  • Page 77: B8 Troubleshooting

    Troubleshooting : The motor will not start. • The blade shaft is blocked. • Chipping chamber cover is missing. • The see-through window has not been shut. • The collection box has not been (or has been incorrectly) slid in. •...
  • Page 78 • Irregular wear and tear of the chipping blades. • One of the motor bearings is faulty. The rotor does not rotate. • A piece of wood has blocked the blade shaft. • The discharge is blocked. Increased sound level •...

  • Page 79: B9 Ec Declaration Of Conformity

    "EN 13683 : Garden Equipment – Integrally powered shredders/chippers – Safety" ELIET machinefabriek hereby declares that after performing a hazard analysis, it is fully aware of the potential hazards and risks associated with the machine. In this knowledge, the neces- sary steps have been taken in line with Machine Directive 98/37/EEC in order to ensure absolute operator safety for the operator, when the machine is used correctly.

  • Page 80: B10 Warranty Conditions

    At Eliet, we have strict quality rules on designing and manufacturing products. The priorities given by these rules are to guarantee a long service life and permanent safety. That is why at Eliet, we are willing to repair at no charge hidden defects or faults during the whole run-in period (aka the warranty period), provided the prescribed procedure is followed.
  • Page 81 Faulty components shall become the property of ELIET. • Step 8 : When a warranty claim is found to be valid, ELIET will credit the warranty parts. Cus- tomers shall never be entitled to apply for a refund of labour costs.
