Focus QuadScan Elite HD Quick Start Manual

1. Connect Source(s) and Display to QuadScan

Use the supplied DB-
15 M to DB-15 F Cable
Display
Device or Projector

2. Power Up Source Devices

3. Power Up QuadScan Elite and Identify Buttons

TView QuadScan
Power Switch. (on
Rack Mount units, it
may be necessary to
turn on power switch
on rear panel.
MANL-0840-01
Video Processor QuickStart Guide
On power up, the
LED display will
read
"QUADSCAN" or
"QUADSCAN HD"
(model dependent)
Component Composite
DVD
+
-
Menu Scroll
up and down
buttons.
(circular list)
Input
A
Input
B
S-Video
Use
Component,
Composite or
S-Video
outputs on
your source
device.
Arrow selection
keys (for multi
and range
selections).
