About QuadScan Elite HD
Thank you for purchasing the Focus Enhancements QuadScan Elite HD Video
Processor. QuadScan Elite HD is a cost-effective high-resolution video
processor for high definition display devices which provides video
enhancement previously found only in systems costing over $10,000.
Functioning as a video scaler, QuadScan Elite HD enables output from
852x480 to 1365x1024 to support popular Plasma Panels, D-ILA projectors
and HD display devices. Controls are accessible via RS232/422, infrared
remote control, or backlit control panel. The QuadScan Elite HD also provides
for any combination of source, display, and screen operation with storage of
parameters, image positioning, and range reference on color control.
QuadScan Elite HD eliminates visible scan lines and flicker from standard
video. The resulting picture, with its improved detail and color quality, is ideally
suited for professional presentation and home theater applications. QuadScan
Elite HD accepts interlaced composite (NTSC/PAL), Y/C (S-VHS), and
component (YPbPr) video signals. Output is flicker-free, progressive video.
User's Guide Addendum
Included with your QuadScan Elite HD is the QuadScan Elite User's Guide.
The following changes apply for the QuadScan Elite HD:
Output Resolutions
QuadScan Elite HD has the following output resolutions:
XGA For use with 1024x768 display devices.
D-ILA For use with 1365x1024 display devices such as D-ILA projectors.
480P For use with 852/853x480 progressive display devices such as
Plasma panels.
720P For use with HDTV display devices such as HD monitors,
widescreen DLP and LCD projectors or Plasma panels.
1024L For use with 1024x1024 display devices such as Plasma panels.
768L (P) For use with 1280x768 or 1366x768 display devices such as
plasma panels that require a positive sync. (FACTORY DEFAULT)
768L (N) For use with 1280x768 or 1366x768 display devices such as
plasma panels that require a negative sync.
MANL-0839-01
High-Definition Video Processor
