Samsung WD10F7S7SRP User Manual

Samsung wd10f7s7srp washing machine user manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Washing Machine

This manual is made with 100% recycled paper.

YUKON-WIFI-03073U-01_EN_130828.indd 1

user manual

imagine

the possibilities

Thank you for purchasing this Samsung product.

To receive a more complete service, please

www.samsung.com/register

WD10F7S7SRP

2013-08-28

10:23:55

Table of Contents

Summary of Contents for Samsung WD10F7S7SRP

Page 1: Washing Machine
WD10F7S7SRP Washing Machine user manual This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing this Samsung product. To receive a more complete service, please register your product at www.samsung.com/register YUKON-WIFI-03073U-01_EN_130828.indd 1 YUKON-WIFI-03073U-01_EN_130828.indd 1 2013-08-28...
Page 2: Bubble Wash
VRT™ washer • VRT™ (Vibration Reduction Technology) This Samsung washer performs smoothly at top spin speeds, helping to minimize noise and vibration. • Bubble Wash Samsung’s Bubble Wash delivers cleanliness with fabric care. Bubble Wash combines water as detergent before the wash cycle commences.
Page 3: Drum Clean
This manual contains important information on the installation, use, and care of your new Samsung washing machine. Refer to it for descriptions of the control panel, instructions on how to use the washing machine, and tips for making the most of its state-of-the-art features and functions.
Page 4: Safety Information
Congratulations on your new Samsung washer. This manual contains important information on the installation, use and care of your appliance. Please take time to read this manual to take full advantage of your washer’s many beneﬁ ts and features.
Page 5 Read all instructions before using the appliance. As with any equipment using electricity and moving parts, potential hazards exist. To safely operate this appliance, become familiar with its operation and exercise care when using it. Do not let children (or pets) play on or in your washing machine.
Page 6 safety information To minimize the risk of ﬁ re in a tumble dryer, the following should be observed: CAUTION Items that have been spotted or soaked with vegetable or cooking oil constitute a ﬁ re hazard and should not be placed in a tumble dryer. Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a tumble dryer.
Page 7 Do not dry unwashed items in the tumble dryer(or washing machine drying mode,etc). WARNING Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, Kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer.
Page 8 safety information SEVERE WARNING SIGNS FOR INSTALLATION WARNING The installation of this appliance must be performed by a qualiﬁ ed technician or service company. - Failure to do so may result in electric shock, ﬁ re, an explosion, problems with the product, or injury.
Page 9 Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance. - This may result in electric shock or ﬁ re. Do not pull the power cord, when unplugging the power plug.
Page 10 safety information Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or other ﬂ ammable or explosive substances. - This may result in electric shock, ﬁ re or an explosion. Do not open the washer door by force while it is operating (high-temperature washing/ drying/spinning).
Page 11 The use for business purposes qualiﬁ es as product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
Page 12 safety information Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in electric shock, ﬁ re, problems with the product, or injury. Do not spray volatile material such as insecticide onto the surface of the appliance.
Page 13 Do not use natural hand-washing soap for the washer. - If it hardens and accumulates inside the washer, it may result in problems with the product, discolouration, rust or bad odors. Do not wash large laundry items such as bedding in the washing net. - Place socks and brassieres into the washing net and wash them with the other laundry.
Page 14: Table Of Contents
contents SETTING UP YOUR WASHING Checking the parts Meeting installation requirements MACHINE Electrical supply and grounding Water Supply Drain Flooring Surrounding temperature Alcove or closet installation Installing your washing machine Environment WASHING A LOAD OF LAUNDRY Washing for the ﬁ rst time Basic instructions Using the control panel Child Lock...
Page 15 CLEANING AND MAINTAINING YOUR Cleaning the exterior Cleaning the interior WASHING MACHINE Cleaning the dispensers Storing your washer Cleaning the debris ﬁ lter Cleaning the door seal/bellow Preserving the top cover and the front frame TROUBLESHOOTING AND Check these points if your washing machine... Information codes INFORMATION CODES CYCLE CHART...
Page 16: Setting Up Your Washing Machine
Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping, or if you do not have all of the parts, contact Samsung Customer Service or your Samsung dealer. Option...
Page 17: Meeting Installation Requirements
MEETING INSTALLATION REQUIREMENTS Electrical supply and grounding Never use an extension cord. Use only the power cord that comes with your washing machine. WARNING When preparing for installation, ensure that your power supply offers: • AC 220-240 V / 50 Hz fuse or circuit breaker •...
Page 18: Drain
Drain Samsung recommends a standpipe height of 46cm. The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory.
Page 19: Removing The Shipping Bolts
STEP 2 Removing the shipping bolts Before installing the washing machine, you must remove all shipping bolts from the back of the unit. Option 1. Loosen all the bolts with the supplied wrench. 2. Hold the bolt with the spanner and pull it through the wide Option section of the hole.
Page 20: Adjusting The Levelling Feet
setting up your washing machine STEP 3 Adjusting the Levelling feet When installing your washing machine, ensure that the power plug, the water supply and the drain are easily accessible. 1. Slide the washing machine into position. 2. Level your washing machine by turning the levelling feet in and out as necessary by hand.
Page 21: Connecting The Water Supply Hose
Connecting the water supply hose 1. Remove the adaptor from the water supply hose. Adaptor Water supply hose 2. First, using a ‘+’ type screwdriver, loosen the four screws on the adaptor. Next, take the adaptor and turn part (2) following the arrow until there is a 5 mm gap.
Page 22 setting up your washing machine ✗ 6. Turn on the water supply and ensure that no water leaks from the water valve, tap or adaptor. If there is a water leaks, repeat the previous steps. Do not use your washing machine if there is a water leak. ✗...
Page 23: Environment
Connecting the drain hose The end of the drain hose can be positioned in three ways: 1. Over the edge of a wash basin: The drain hose must be placed at a height of between 60 and 90 cm. To keep the drain hose spout bent, use the supplied plastic hose guide. Secure the guide to the wall with a hook or to the tap with a piece of string to prevent the drain hose from moving.
Page 24: Washing A Load Of Laundry
With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash ﬁ rst. WASHING FOR THE FIRST TIME Before washing laundry for the ﬁ rst time, you must run a complete empty cycle (i.e. no laundry).
Page 25: Using The Control Panel
USING THE CONTROL PANEL Select the tumble pattern and spin speed for the cycle. For detailed information, refer to “Washing clothes using the cycle selector”. (see page 33) Cotton - For average or lightly soiled cottons, bed linen, table linen, underwear, towels, shirts, etc.
Page 26 washing a load of laundry The large Digital Display is easy to use. It provides instructions and DIGITAL DISPLAY diagnostics while keeping you updated on the cycle status and time remaining. Smart Control - Smart Control technology enables you to control your washer through personal technology devices such as smart phones.
Page 27 Pressing the button cycles through the following options. Cupboard  Iron  Small Load  Low Temp.  Time (30 min.  1:00 h  1:30 h  2:00 h  2:30 h)  Cupboard Cupboard - Select to dry laundry automatically by detecting the amount and weight of the laundry.
Page 28: Child Lock
washing a load of laundry Child Lock Child Lock prevents children from playing with your washer. Once you have activated the Child Lock function, the control panel cannot be activated, preventing children from playing with the washer. Activating/Deactivating Press and hold both the Temp. and Rinse buttons simultaneously for approximately 3 seconds.
Page 29: Smart Check
4 and iPhone 4S Downloading the Samsung Smart Washer app Download the Samsung Smart Washer app to your mobile phone from the Android market (Play store) or Apple App store and install it. You can easily ﬁ nd it by searching for “Samsung Smart Washer”.
Page 30: Sound Off
washing a load of laundry Sound off The Sound Off function can be selected during all courses. When this function is selected, sound is turned off for all courses. Even if the power is turned on and off repeatedly, the setting is retained.
Page 31: Air Wash
Air Wash Air Wash can refresh laundry without using water owing to its powerful airing system. Clothing that can be refreshed includes woolen coats, cotton jumpers, sweaters and suits. [Two items or less (less than 1 kg)] 1. Open the door, place the laundry into the washing machine and close the door. 2.
Page 32: Using Dry Course
washing a load of laundry USING DRY COURSE Refer to the label of drying capacity and be sure to put in the clothes to the lower level than the marked line for the dried clothes of 7.0kg. 1. Open the door, put in the clothes and close the door again. 2.
Page 33: Washing Clothes Using The Cycle Selector
Washing clothes using the cycle selector Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed. 1. Turn on your sink’s water tap.
Page 34: Washing Clothes Manually
washing a load of laundry Washing clothes manually You can wash clothes manually without using the Cycle Selector. 1. Turn the water supply on. 2. Press the Power button on the washing machine. 3. Open the door. 4. Load the articles loosely into the drum one at a time, without overﬁ lling it. 5.
Page 35 Do not overload the washing machine or your laundry may not wash properly. Use the chart below to determine the load capacity for the type of laundry you are washing. Fabric Type Load Capacity Model WD10F7S7SRP Wool 3.0 kg Baby Care 10.0 kg Outdoor Care 3.0 kg...
Page 36: Detergent And Additives Information
washing a load of laundry DETERGENT AND ADDITIVES INFORMATION Which detergent to use The type of detergent you should use is based on the type of fabric (cotton, synthetic, delicate items, wool), colour, wash temperature, and degree of soiling. Always use “low suds” laundry detergent, which is designed for automatic washing machines.
Page 37: Detergent Drawer
Detergent drawer Your washing machine has separate compartments for dispensing detergent and fabric softener. Add all laundry additives to the correct compartment before starting your washing machine. Do not open the detergent drawer while your washing machine is running or you might be exposed to hot water or steam.
Page 38: Smart Control
You may not be able to connect to the Internet due to a ﬁ rewall. In this case, ask your Internet service provider for assistance.If you cannot connect the washer to the Internet even after contacting your Internet service provider, please contact a Samsung Electronics dealer or service center.
Page 39: Setting The Network (Android
1. Touch and bring up the applications menu on your phone. Then ﬁ nd and open the “Play Store” icon. 2. Once the “Play Store” has been open, do a search. 3. Once the search box appears type in “Samsung Smart Washer”. smart control _39 YUKON-WIFI-03073U-01_EN_130828.indd 39 YUKON-WIFI-03073U-01_EN_130828.indd 39...
Page 40 4. Once the search is complete the App “Samsung Smart Washer” will be displayed. You need to download this App to your phone. Make sure the app changes from “Free” to “Installed” 5. Once the phone app has been downloaded to your phone, you are now ready to set up the washer Wi-Fi control.
Page 41 9. Once you are connected to the selected network go back to the applications screen on your mobile phone. Once you are in the phones application screen touch the Samsung icon “Samsung Smart Washer” that was downloaded at the beginning of this process.
Page 42 10. After opening the Samsung app, select “Select a Country” and then “Connection setup”. 11. You need to ﬁ rst press the Power button to activate the your machine. You can activate the machine to any wash cycle.
Page 43 14. After the AP menu appears on the LED screen, press the Start/Pause button. Once the Start/Pause button is pressed the “AP” displayed on the LED screen should start to blink. If the you press the Start/Pause and the “AP” doesn’t blink try again after a moment.
Page 44 smart control 18. The ‘oAP’ code appears on the display panel of the washing machine and the “Transfer complete” message appears on the mobile app. The phone is now connected to the machine through the network. If the “FAP” code appears on the display panel, press the Start/Pause button and restart from Step 14.
Page 45: Setting The Network (Ios
3. Once the search box appears type in “Samsung Smart Washer”. 4. Once the search is complete the App “Samsung Smart Washer” will be displayed. You need to download this App to your phone. Make sure the app changes from “Free” to “Installed”...
Page 46 smart control 5. Once the phone app has been downloaded to your phone, you are now ready to set up the washer Wi-Fi control. 6. You need to ﬁ rst press the Power button to activate the your machine. You can activate the machine to any wash cycle.
Page 47 12. Once you are connected to the selected network go back to the applications screen on your mobile phone. Once you are in the phones application screen touch the Samsung icon “Samsung Smart Washer” that was downloaded at the beginning of this process.
Page 48 13. After opening the Samsung app, select “Connection setup”. 14. Tap the “Setting Start” and input your SSID, Authentication Type, Encryption Type, password of AP. This process delivers the connection information of the “AP” that is connected to the mobile phone to the product.
Page 49 16. After the phone is connected to the machine, press the Temp. + Start/Pause buttons simultaneously for 5 seconds. After 5 seconds the original wash cycle will be displayed on the LED screen. 17. After the wash cycle has been displayed wait approximately 1 minute.
Page 50: Connecting To The Network Using The Wps
CONNECTING TO THE NETWORK USING THE WPS SETTINGS (FOR WPS-ENABLED ROUTERS ONLY) • Samsung washers use PBC as the WPS type. Check if the current wired/wireless router supports Wi-Fi Protected Setup™(WPS). • Check if the wired/wireless share has a WPS button.
Page 51: Quick Authentication (Recommended
INDOOR CONTROL Quick authentication (recommended) 1. The “Authentication” only needs to be run with the initial setup. Touch the “Indoor control” tab to search for the washer’s name. Once the washer’s name(WD10F7S) is displayed touch tab. 2. After you touch the washer name tab you need to touch the “OK” tab to proceed with the certiﬁ...
Page 52 smart control 4. Follow the instructions displayed on the phone to start the washer setup. The waiting time for authentication is 20 seconds. Perform step 5 below within 20 seconds. 5. Press the Smart Control button. If the lamp on the Smart Control button is on, press the Smart Control button once to turn it off .
Page 53: Authentication (If The Quick Authentication
Authentication (if the quick authentication method fails) 1. The “Authentication” only needs to be run with the initial setup. Touch the “Indoor control” tab to search for the washer’s name. Once the washer’s name WD10F7S is displayed touch tab. 2. Verify the that the Wi-Fi icon is not blinking. Press the Temp.
Page 54 smart control 4. After you touch the conﬁ rm tab you will now start preparing the certiﬁ cation. 5. Follow the instructions displayed on the phone to start the washer setup. The waiting time for authentication is 20 seconds. Perform step 6 below within 20 seconds. 6.
Page 55 7. Once the Start/Pause button is pressed the “PS” will start to blink. Once it starts blinking the phone will automatically start to connect. 8. After the “PS” is displayed, press the Temp. + Start/Pause buttons simultaneously for 5 seconds. Please wait until the Smart Control Enabled icon [ ...
Page 56: Using The Mobile App
Then press the Smart Control button to activate the Smart Control function. When this function is activated, the ’Smart Control’ indicator will light up. Now press the “Samsung Smart Washer” icon. If you try to activate the Smart Control function while the door is open, the function will be activated at ﬁ...
Page 57 “Cycle completes”. For iPhones, you need to run the Outdoor control function in the app ﬁ rst to authenticate the Push Notiﬁ cation service after registering your washer to the Samsung Smart appliance (www.samsungsmartappliance.com) website. smart control _57 YUKON-WIFI-03073U-01_EN_130828.indd 57...
Page 58: Outdoor Control
(http://www.samsungsmartappliance.com) 2. Enter the User ID and Password to log in. If you don’t have an account, press “Create a Samsung account” and ﬁ ll in the form to become a member. 3. Select “My page”  “My page”. 4. Select “Add device”.
Page 59 You can ﬁ nd it on your mobile app. (Refer to No.2 on page 56.) 6. Tap the ‘Washers/Dryers’ tab and enter the mac address. (Web) 7. Click the “Certify device”. (Web) 8. Turn the Cycle Selector until “PS” is displayed on the display panel and press the Start/Pause button.
Page 60: Using The Mobile App
Using the mobile app Register the appliance on the Samsung Smart Appliance website ﬁ rst to control the washing machine using the outdoor control function. 1. Press the Smart Control button. 2. Tap the “Outdoor control” tab. 3. Enter the ID and...
Page 61: Cleaning The Exterior
cleaning and maintaining your washing machine CLEANING THE EXTERIOR Turn off the water faucets after ﬁ nishing the day’s washing. This will shut off the water supply to your Washer and prevent the unlikely possibility of damage from escaping water. Leave the door open to allow the inside of your Washer to dry out. Use a soft cloth to wipe up all detergent, bleach or other spills as they occur.
Page 62: Storing Your Washer
cleaning and maintaining your washing machine STORING YOUR WASHER Washers can be damaged if water is not removed from hoses and internal components before storage. Prepare your Washer for storage as follows: • Select the Quick Wash cycle and add bleach to the automatic dispenser. Run your Washer through the cycle without a load.
Page 63: Cleaning The Door Seal/Bellow
CLEANING THE DOOR SEAL/BELLOW 1. Open the washer door and remove any clothing or items from the washer. 2. Inspect the gray colored seal/bellow between the door opening and the basket for stained areas. Pull back the seal/bellow to inspect all areas under the seal/bellow and to check for foreign objects.
Page 64: Check These Points If Your Washing Machine
troubleshooting and information codes CHECK THESE POINTS IF YOUR WASHING MACHINE... PROBLEM SOLUTION Will not start.. • Make sure the door is ﬁ rmly closed. • Make sure your Washer is plugged in. • Make sure the water source faucets are open. •...
Page 65 • Reduce the detergent amount for soft water, Small Load or lightly soiled loads. • Non-HE detergent is NOT recommended. If the problem persists, contact your local Samsung Customer Service. troubleshooting and information codes _65 YUKON-WIFI-03073U-01_EN_130828.indd Sec11:65 YUKON-WIFI-03073U-01_EN_130828.indd Sec11:65 2013-08-28...
Page 66 It appears when the internal temperature of the drum is high. The fan will automatically function, so just wait until “Hot” indication disappeared. For any codes not listed above, or if the suggested solution doesn’t ﬁ x the problem, call your Samsung Service Centre or local Samsung dealer.
Page 67: Cycle Chart
cycle chart CYCLE CHART  default option,  user option) Functions PROGRAM Temp. Rinse Spin Cold 30 ˚C 40 ˚C 60 ˚C 95 ˚C no spin 1000 1200  Drying Sanitization Deodorization         Wool ...
Page 68: Fabric Care Chart
appendix FABRIC CARE CHART The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing (and dry cleaning when necessary). The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow the care label directions to maximize garment life and reduce laundery problems.
Page 69: Speciﬁ Cations
SPECIFICATIONS TYPE FRONT LOADING WASHING MACHINE WD10F7S7SRP DIMENSIONS W686mm X D820mm X H984mm WATER PRESSURE 137 kPa ~ 800 kPa WATER VOLUME ℓ NET WEIGHT 102 kg WASH AND SPIN CAPACITY 10.0 kg [DRY LAUNDRY] DRY CAPACITY 7.0 kg WASHING...
Page 70: Open Source Announcement
You may obtain the complete Corresponding Source code from us for a period of three years after our last shipment of this product by sending email to: oss.request@samsung.com If you want to obtain the complete Corresponding Source code in the physical medium such as CD-ROM, the cost of physically performing source distribution may be charged.
Page 71 Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that redistributors of a free program will individually obtain patent licenses, in eff ect making the program proprietary. To prevent this, we have made it clear that any patent must be licensed for everyone’s free use or not licensed at all.
Page 72 appendix or collective works based on the Program. In addition, mere aggregation of another work not based on the Program with the Program (or with a work based on the Program) on a volume of a storage or distribution medium does not bring the other work under the scope of this License.
Page 73 would not permit royalty-free redistribution of the Program by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely from distribution of the Program. If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply and the section as a whole is intended to apply in other circumstances.
Page 74 appendix HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. END OF TERMS AND CONDITIONS How to Apply These Terms to Your New Programs If you develop a new program, and you want it to be of the greatest possible use to the public, the best way to achieve this is to make it free software which everyone can redistribute and change under these terms.
Page 75 [This is the ﬁ rst released version of the Lesser GPL. It also counts as the successor of the GNU Library Public License, version 2, hence the version number 2.1.] Preamble The licenses for most software are designed to take away your freedom to share and change it. By contrast, the GNU General Public Licenses are intended to guarantee your freedom to share and change free software--to make sure the software is free for all its users.
Page 76 appendix A more frequent case is that a free library does the same job as widely used non-free libraries. In this case, there is little to gain by limiting the free library to free software only, so we use the Lesser General Public License.
Page 77 3) You must cause the whole of the work to be licensed at no charge to all third parties under the terms of this License. 4) If a facility in the modiﬁ ed Library refers to a function or a table of data to be supplied by an application program that uses the facility, other than as an argument passed when the facility is invoked, then you must make a good faith eff ort to ensure that, in the event an application does not supply such function or table, the facility still operates, and performs...
Page 78 appendix the source code is not. Whether this is true is especially signiﬁ cant if the work can be linked without the Library, or if the work is itself a library. The threshold for this to be true is not precisely deﬁ...
Page 79 things: 1) Accompany the combined library with a copy of the same work based on the Library, uncombined with any other library facilities. This must be distributed under the terms of the Sections above. 2) Give prominent notice with the combined library of the fact that part of it is a work based on the Library, and explaining where to ﬁ...
Page 80 appendix Each version is given a distinguishing version number. If the Library speciﬁ es a version number of this License which applies to it and “any later version”, you have the option of following the terms and conditions either of that version or of any later version published by the Free Software Foundation.
Page 81 You should have received a copy of the GNU Lesser General Public License along with this library; if not, write to the Free Software Foundation, Inc., 51 Franklin Street, Fifth Floor, Boston, MA 02110-1301 USA Also add information on how to contact you by electronic and paper mail. You should also get your employer (if you work as a programmer) or your school, if any, to sign a “copyright disclaimer”...
Page 82: Openssl
appendix OPENSSL This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit. (http:// www.openssl.org/) This product includes cryptographic software written by Eric Young (eay@cryptsoft.com) LICENSE ISSUES ===================================================================== The OpenSSL toolkit stays under a dual license, i.e. both the conditions of the OpenSSL License and the original SSLeay license apply to the toolkit.
Page 83 memo YUKON-WIFI-03073U-01_EN_130828.indd Sec3:83 YUKON-WIFI-03073U-01_EN_130828.indd Sec3:83 2013-08-28 2013-08-28 10:24:28 10:24:28...
Page 84 QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT ASTRALIA 1300 362 603 www.samsung.com Code No. DC68-03073U-01_EN YUKON-WIFI-03073U-01_EN_130828.indd Sec3:84 YUKON-WIFI-03073U-01_EN_130828.indd Sec3:84 2013-08-28 2013-08-28 10:24:29 10:24:29...
