2. Wiring chart
Indoor
Unit
Please ground air conditioner well. Otherwise, an important grounding may affect anti-jamming
performance of whole unit
Note: The cooling only type without the link listed by broken line.
MCA-24CRN2, MCA-24HRN2
Power
Chart 33
3-core AWG24
220~240VAC 50Hz
(3-core cable
2
3x2.5mm)
3-core cable
2
3x1mm
3-core cable
2
3x2.5mm
air conditioner link-circuit
Chart 34
Switch/Fuse
Power linking wiring (indoor)
Outdoor
Unit
Weak elec-signal link wiring
Strong elec-signal link wiring
INDOOR UNIT
L1
N1
L
N
17
1 N 3 4 5
