Studio Electronics ATC-X Operation Manual page 19

Selects the MIDI clock assignment to LFO 2. The rate of LFO 2 can be
synchronized to incoming MIDI time clock sent from your sequencer. The beat
divisions available are:
1 1 = whole note, 2 2 = half note, 4 4 = quarter note, 4 4 - - 3 3 = quarter note triplet, 8 8 =
eighth note, 8 8 - - 3 3 = eighth note triplet, 1 6
note triplet. Note: LFO 2 rate control will not respond when a MIDI clock division
is selected.
Selects the master tuning and overall transpose.
Press once to access the master tune control
which raises or lowers the pitch of the
oscillators over a semitone range; Press again to
access the overall octave transpose. The pitch
can then be transposed up or down one octave.
Selects
recommend this level be set at maximum or
close to it, for the best possible sound quality.
Selects the glide time and auto glide interval
and regular or legato functions. Glid
movement from note to note at a selected rate
and Auto Auto - - Glide
selected interval at a rate determined by the glide time. Note: If the auto-glide
interval is anything but 0 0 , the auto glide function will override glide. First press:
glide on/off. Second press: regular mode or legato mode (notes will only glide if
legato notes are played). Third press: glide rate. Fourth press: Auto-glide interval.
Note: with all presses, use encoder to edit.
To defeat of glide to OSC 1, 2 or VCF (cool effects yo) frequency, edit thusly:
O SC 1: press and hold glide button then press OSC 1 frequency. Release glide button and
use OSC 1 frequency button to toggle on or off. Press any other button to exit this mode.
O SC 2: press and hold glide then OSC freq/fine. Release glide button and use OSC 2
freq/fine button to toggle on or off. Same exit strategy.
VCF fr eq u e n cy: press and hold glide button then press VCF frequency. Release glide
button and use OSC 2 freq/fine button to toggle on or. Ditto exit plan.
Note: unless programmed all patches will default to glide being sent to all sources.
Selects the key triggering and note priority functions. Press once to access single
or multiple triggering selections. Press again to access note priority selection.
M u lt iple triggering
M u lt iple
keystroke; with single triggering the filter envelope is re-triggered only with
staccato, or non-legato key strikes. Note P r iorit y
note, any new note, or a lower note only, will be played next.
the master volume
Glide is pitch movement from a
triggering is the re-triggering of the filter envelope with each note or
1 6 = sixteenth note, 1 6
level. We
Glid e e is pitch
Note P r iorit y determines if while a holding
1 6 - - 3 3 = sixteenth
