- Page 3 FEATURES / VOICE ARCHITECTURE .............. ii IMPORTANT NOTES ..................1 INTRODUCTION ..................2 B A S I C O P E R A T I O N GETTING IT STARTED................... 3 CONNECTIONS ..................4 USING THE MEMBRANE AND ROTARY ENCODER (reading the display) ... 5 C R E A T I N G S O U N D S OSCILLATORS ..................
- Page 4 I. Portamento and auto glide. II. Single and multiple triggering. III. Inverting of envelopes 1 and 3. IV. Note priority: low or last. V. LFO 2 sync to MIDI clock with seven beat divisions: whole, half, quarter, quarter note triplet, eighth, eighth note triplet, sixteenth, and sixteenth note triplet.
- Page 5 5 years as a rule. When it is time to change it, contact us, or your local authorized Studio Electronics service station. Please be aware that the contents of the memory may possibly be lost: when sent for repair work, or when a chance malfunction occurs––it is always prudent to back up your complete memory via a SYSEX bulk...
- Page 6 Thank you for purchasing the S T UDIO E LECTRONICS ATC- X. You're soon to discover the world's only 4-way discrete multi-filtered analog synthesizer. Like never before, you now have the ability to create and explore all of the classic Analog synthesizer sounds in one powerfully expressive and versatile machine.
- Page 7 Setting Up the Instrument A. Plug the power supply cable into any conventional A.C. outlet. With its auto- ATC-X switching power supply the is capable of accommodating voltages ranging ATC-X from 90 - 250. So, wherever you and your are in this great big world, proper operation is a cinch.
- Page 9 *Note that the display blinks momentarily after each press, informing you that your action has been recognized. The Rotary Encoder ATC-X The main user interface in programming the is the rotary encoder; which turns smoothly in either direction for complete control. After a switch pad is pressed you will use the encoder in almost all operations to edit or change any desired function or parameter.
- Page 10 The waveshape selectors determine the harmonic spectrum of the signal, its basic timbre, or tone color. ATC-X 1 has two oscillators that each produce three waveforms. All the waveforms are continuously being generated, so they are available to be outputted either individually or simultaneously, depending upon how they are selected.
- Page 11 Selects the mix level of Oscillator 2 (same potential for harmonic distortion as Oscillator 1). Selects the mix level of the noise or distortion. Noise is a random signal, a ATC-X rushing, static-like sound. The 's noise generator produces white noise.
- Page 12 The ATC-X with its unique interchangeable filter system features four classic wide range lowpass filters, and in the case of the MINI and 2600, "resonant" filters (see VOICE ARCHITECHURE). The Filter attenuates, or "cuts- off" the higher frequency components––those which lie above the adjustable cutoff frequency, and passes the lower frequency components of the audio signal.
- Page 13 The filter envelope shapes the timbre and overtone content of the audio signal as it passes through the modifying circuitry from the mixer. This envelope or "contour" generator is used to dynamically move the cutoff frequency. It works as such: each time a key is depressed an envelope or "contour”...
- Page 14 E n v e l o p e 2 : V C A The volume of the audio signal, which passes through the VCA envelope, is contoured by the envelope controls. Each time a key is pressed, the envelope or "contour" generator attached to the amplifier is actuated, and sends a control signal to the amplifier.
- Page 15 E n v e l o p e 3 : A ss i g n a b l e Envelope 3 can be assigned to modulate a variety of different parameters to create unusual textures and interesting effects. See the target list below for the parameters Envelope 3 can control.
- Page 16 LFO 2 LFO 2 can be synchronized to MIDI time clock (see PROGRAM). The ATC-X also has the capability of allowing Oscillator 2 to modulate Oscillator 1 and the frequency of the filter. This is known as Audio Frequency Modulation because the modulation control signal, in this case Oscillator 2, resides in the audio spectrum.
- Page 17 Void below vintage NAMM Show banner reserved for doodling, grease stains and sectional integrity (by mercurial order of the Knights Regis). May it serve and soothe you well. Pimp your wall: full-sized, color banner art available at: http://studioelectronics.com/assets/PDFs/ATC-X/NAMM97Banner.tif.zip...
- Page 18 ATC-X is completely controllable by MIDI, with a long list of parameters and functions assignable to Velocity, Modwheel, and Aftertouch. Certain sound parameters also have a dedicated Continuous Controller assignment (see chart on page 16). In addition, parameter edits made by the rotary encoder are transmitted as Controller data.
- Page 19 Selects the MIDI clock assignment to LFO 2. The rate of LFO 2 can be synchronized to incoming MIDI time clock sent from your sequencer. The beat divisions available are: 1 1 = whole note, 2 2 = half note, 4 4 = quarter note, 4 4 - - 3 3 = quarter note triplet, 8 8 = eighth note, 8 8 - - 3 3 = eighth note triplet, 1 6 1 6 = sixteenth note, 1 6 1 6 - - 3 3 = sixteenth...
- Page 20 Located in this section is the display and rotary encoder, which along with the membrane front panel, makeup the user interface. Playing ATC-X and programming the involves two basic modes of operation: Patch Play Mode and Edit Mode. In Patch Play mode, the unit will ATCX cycle through its 512 patches when the encoder is turned.
- Page 21 Osc 1&2 freq Osc 1mix Osc 2 PW VCF freq Osc 1 PW X mod amnt VCF res Osc 2 freq Noise mix Osc 1 freq Osc 2 mix Volume Env 1 amnt VCF freq X mod amount Osc 1&2 freq Env 2 amnt VCF res Noise mix...
-
Page 22: Midi Implementation Chart
Studio Electronics December 30, 2007 ATC-X Version 2.2 MIDI Implementation Chart Function*** Transmitted Recognized Remarks Basic Default 1-16 MEMORIZED Channel Changed 1-16 Mode Default OMNI OFF, Messages MONO Altered Note True Voice 0-127 Number Velocity Note ON 09n. V=127 Note OFF... - Page 23 Although the ATC-X has been thoroughly tested for potential software bugs, we cannot simulate all possible user setups. So in some instances, the ATC-X may "lock up" or "stick" on a note. To rectify this situation, try one or more of the following fixes: Play and hold more...
