12V Rail Output Current
Input (V)
12V rail current
6V
3A
7V
4A
8V
6A
9V
7A
10V
7A
For input voltage (6-10V or 20-32v) ventilation might be required for peak load
M2-ATX-HV-HV User Guide
Input (V)
12V rail current
11V
7A
12V
7A
14V
8A
14-18V
7A
20-32V
6A
.
Page 5
