- Page 1 NX Series Network Camera & Video Server NX173 / NX288 / NX301 NX589 / 599 Installation Guide Introduction...
- Page 2 Signal Communications Limited. TeleEye is a trademark of Signal Communications Limited and is registered in China, European Communities, Hong Kong, US and other countries. All other trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
NX589/NX599…...…………………………………………………..13 2.5. NX301....................17 3. Software Installation................20 3.1. PC Requirements .................20 3.2. IP Setup Utility..................20 3.3. WX-M4Lite..................21 4. Connecting NX173/NX288/NX589/NX599/NX301 .......21 4.1. Configuration ..................21 4.2. Web Browsing..................22 4.2.1. Connecting to Remote Site ............22 4.2.2. Settings..................24 Appendix A: Specifications..............25 Appendix B: Dimension .................26... -
Page 4: Introduction
SMAC-M compression technology. The NX range offers the balanced combination of high-quality video, mobility, scalability and cost effectiveness. By using TeleEye NX, users can build an integrated, scalable, wired or wireless IP & mobile video surveillance solution over existing network infrastructure. -
Page 5: Functional Features
Scalable and Flexible Network Configuration Flexible connections: LAN, ADSL, mobile network, etc. sureLINK, support both static and dynamic IP Monitoring and recording up to 16 cameras with TeleEye WX-M16 Multi- site software Live video delivery over bursty and limited network resources with TeleEye... -
Page 6: Packages Contents
NX User Guide PAGE 3 Packages Contents After removing the package, make sure you have the following items: For NX173 NX173 network camera Warranty card and registration code User Guide Software CD Analog video cable RJ-45 Ethernet adapter Power jack converter... - Page 7 NX User Guide PAGE 4 Label For NX288 NX288 network camera Warranty card and registration code User Guide Software CD Analog video cable RJ-45 Ethernet adapter Screws driver, wall mount screws and plastic wall plugs Introduction...
- Page 8 NX User Guide PAGE 5 For NX589/NX599 NX589/NX599network camera Warranty card and registration code User Guide Software CD RJ-45 Ethernet adapter Network and alarm cable AC Adapter AC and Earth cable wall mount screws, bracket screws and acrylic dome shield screws Introduction...
- Page 9 NX User Guide PAGE 6 For NX301 NX301 video server Warranty card and registration code User Guide Software CD Wall mount screws and plastic wall plugs DC Adapter Power cord RJ-45 Ethernet cable Introduction...
-
Page 10: Hardware Installation
NX User Guide PAGE 7 2. Hardware Installation 2.1. Cautions Do not install the camera in extreme temperature conditions. Do use the camera under conditions where temperatures are within 0°C ~ +50°C : (32°F ~ 122°F) Do not install the camera under unstable lighting conditions. Severe lighting change or flicker can cause the camera to work improperly. -
Page 11: Nx173
NX User Guide PAGE 8 2.2. NX173 Installation/Configuration The positions marked with circles show the holes for mounting screw. There is an alternate hole for the power cable, Ethernet cable and alarm cable. When this hole is used, the upper hole has to be sealed with the plastic cork. - Page 12 NX User Guide PAGE 9 With reference to the following figure, connect the power cable with a 12V DC supply, Ethernet cable through the LAN adapter and alarm cable to the camera. Power cable (DC12V IN) Ethernet cable Alarm cable After mounting the camera on the wall or ceiling, connect the analog video output to a monitor by using the analog video cable.
-
Page 13: Nx288
NX User Guide PAGE 10 2.3. NX288 Installation/Configuration Drill ф25mm hole on the ceiling for video and power connector cable to pass through. Take off the dome cover from the camera. Use specified holes inside the camera base for installation. Finally, with reference to the following figure, connect the power cable with a 12V DC supply, Ethernet cable through the LAN adapter and alarm cable to the camera. - Page 14 NX User Guide PAGE 11 After mounting the camera on the wall or ceil, connect the analog video output to a monitor by using the analog video cable. Video output Adjust the direction (pan/tilt/rotation) of the camera. Adjust the focal and focus by sliding the sticks at the side of the lens. Adjust focus Adjust focal Hardware Installation...
- Page 15 NX User Guide PAGE 12 Adjust the IRIS level of Auto Iris lens by tuning the “DC LEVEL” as shown in the following figure. Adjust the switches with reference to the following description. Flickerless FL: In FL mode, the shutter speed is 1/100sec. (NTSC system) / 1/120sec. (PAL).
-
Page 16: Nx589/Nx599
NX User Guide PAGE 13 2.4. NX589/NX599 Installation/Configuration -Installation steps of shield dome. 1. The positions marked with circles show the fixing holes of acrylic shield, i.e. four M3 screw holes. 2. Aim the open end of shield dome at the lens of camera. - Page 17 NX User Guide PAGE 14 -Installation Instruction of the Acrylic Dome Shield Installation of the Acrylic Dome Shield 1. Remove Acrylic DOME shield (Please do not scrape the Acrylic shield. It is recommended to wear cotton gloves when operate). 2. As shown in the figure below, first take the flexible flat cable through connector above the base plate and buckle it on the connector.
- Page 18 NX User Guide PAGE 15 2. Wall mount bracket installation Wiring of Dome System Finally, with reference to the following figure, connect the AC Adapter and AC and Earth cable, network cable through the LAN adapter and alarm cable to the camera. During installation, you can use the analog video cable to connect to a video monitor for testing.
-
Page 19: Network Configuration
NX User Guide PAGE 16 Network Configuration NX589/NX599 OSD Control Use of the main menu: In WX-M4lite, pop up a PTZ screen by clicking the PTZ icon on the left corner of the control panel. And click the maximize screen icon Hardware Installation... - Page 20 NX User Guide PAGE 17 Then, click the [Additional] tab page. After click the OSD icon, an OSD menu on the video can be seen. The up and down arrows can be use as option selection. The left and right arrows can be use as enter the submenu or change the value or setting of an option.
-
Page 21: Nx301
NX User Guide PAGE 18 2.5. NX301 Front Panel There is a red LED on the front panel. It flashes when just powered on and indicates the NX is starting. It lights continuously when the starting process is completed. Rear Panel The following figure shows the rear panel of NX301. - Page 22 RS485 out: 2-way terminal block for connecting a PTZ camera DC output: Supply 12V, 0.5A DC to camera. Installation / Configuration Two configurations are available: Configuration 1: Through Ethernet network TeleEye NX301 TeleEye SF373 210.17.139.146 Network Switch / Router with PoE supported...
-
Page 23: Software Installation
NX User Guide PAGE 20 3. Software Installation 3.1. PC Requirements Computer Personal Computer Processor Intel Pentium IV 2.4GHz or above Memory 1GB RAM or above Hard Disk Minimum 1GB hard disk space required Drive CD-ROM Display 1024x768, true colour, with Direct3D supported Sound Sound card is required Ethernet Card... -
Page 24: Wx-M4Lite
NX User Guide PAGE 21 3.3. WX-M4Lite Click [Next] in the welcome screen and follow the instructions in the installation wizard. Select [Typical] in the following screen and click [Next]. Click [Next] to confirm the installation and wait the installation complete. When the installation is successful, it is recommended to restart the PC before using the software. -
Page 25: Connecting Nx173/Nx288/Nx589/Nx599/Nx301
Connecting NX173/NX288/NX589/NX599/NX301 4.1. Configuration Step 1: Double click the [TeleEye IP Setup Utility] icon on the Windows desktop to run the utility. Step 2: The list on the left shows the NX network cameras inside the network of the PC. By comparing the [Serial number] column with the serial number of the camera to be configured, click on that row. -
Page 26: Web Browsing
Utility which will open the Internet Explorer and go to that address directly. Note: Java Runtime Environment is required for the web browser. Please go to http://www.java.com, follow the instruction to download and install it if it has not been installed. Connecting NX173/NX288/NX589/NX599/NX301... - Page 27 NX User Guide PAGE 24 Step 2: Enter the password and select the connection speed, then press [Enter]. If the password is correct, the video should be shown as the following figure. Connecting NX173/NX288/NX589/NX599/NX301...
-
Page 28: Settings
Change to smaller resolution Change to larger resolution Select the video quality Toggle the switch Event status - no event Event status - Event triggering, press to clear the event Event status - Event triggered, press to clear the event Connecting NX173/NX288/NX589/NX599/NX301... -
Page 29: Appendix A: Specifications
NX User Guide PAGE 26 Appendix A: Specifications MODEL NX301 NX288 NX173 NX589/NX599 Single Channel IR Vandal Resistant Vandal Resistant Network Speed Video Server Network Dome Network Dome Dome VIDEO AND AUDIO IMAGE SENSOR − 1/3″ colour CCD 1/4″ colour CCD RESOLUTION (P): 720 ×... - Page 30 NX User Guide PAGE 27 Appendix B: Camera Dimension NX173 NX288 NX589/NX599 Appendix B: Camera Dimension...
