- Page 2 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Before you proceed with the installation, please notice the following descriptions. Note 1: The following installation was operated under Windows XP. (Procedures are similar for Windows 98SE/Me/2000.) Note 2: If you have installed the WLAN USB driver & utility before, please uninstall the old version first.
- Page 3 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Choose a set up language Click Next to process the installation.
- Page 4 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Click Install to WLAN USB adaptor installation Click Finish to complete the installation.
- Page 5 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Uninstall Uninstall the WLAN USB Adaptor Driver from [start], [All Programs], [REALTEK 11n USB Wireless LAN Utility], click Uninstall or [Control Panel],[Add or Remove Programs], [REALTEK 11n USB Wireless LAN Driver and Utility], click Remove...
- Page 6 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual B. Click Yes if you want to remove Wireless LAN USB Adaptor driver. C. Click Finish to complete uninstall.
-
Page 7: Making A Basic Network Connection
POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Making a Basic Network Connection In the following instruction for making a network connection, we use the utility we provided to configure your wireless network settings. Note: For Windows XP users that want to configure your wireless network using... - Page 8 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Ad-Hoc Mode An Ad-Hoc mode wireless network connects two computers directly without the use of a router or AP. It is also know as a peer-to-peer network. For example, we can install this wireless adapter to two computers respectively.
- Page 9 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual A pop out window allows you to configure wireless network properties of the connection profile. Click the OK button when you fill in all of required information. Check out Available Network. You will find Ad hoc network is available for remote station...
-
Page 10: Infrastructure Mode
POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Infrastructure mode An Infrastructure Mode network contains at least one wireless client and one wireless AP or router. This client connects to Internet or intranet by communicating with this wireless AP. - Page 11 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Double click or click on Add to Profile to create profile that you are connecting to an open wireless network. Click OK to add this network into the profile list.
- Page 12 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Note: This example is an open wireless network. If you are going to connect to an AP with security protection, you will have to configure the encryption settings in this “Network...
-
Page 13: Introduction To The Wireless Lan Utility
POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Introduction to the Wireless LAN Utility Note: This management instruction uses Windows XP as the presumed operation system. Some functions are not supported in Windows 98se or Windows ME. Starting the Wireless LAN Utility You may click on the tabs above to configure this adapter. - Page 14 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual General After starting the utility, the general page pops up This General tab provides the information of your current wireless network connection. You may click the Renew IP button to refresh those listed information.
- Page 15 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Profile The Profile tab lists the preferred connections. You can click the buttons beside to do configure each connection. Click this button to add a connection profile for this adapter.
- Page 16 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Available Network This available Network tab lists the reachable wireless network of this adapter. Refresh Click this button to rescan available networks around the adapter. Add to Profile To add an available Network to your profile list, select an available...
- Page 17 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Status This tab shows the current connection status of this adapter.
- Page 18 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Statistics See this tab to show the transmission activity record. Clicking the “Reset” button recounts the values from zero.
-
Page 19: Ap Mode Management Guide
POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual AP mode management guide General After configuring the adapter in AP mode, this “General” page shows up, which shows the general information of this AP. SSID: The SSID (network name) of the wireless network constructed by this AP. - Page 20 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Advanced Beacon Interval: Define the interval between beacons from 20~1000 DTIM Period: Set the DTIM period between 1~255 Preamble Mode: Click the drop list to select the preamble to be long, short or...
- Page 21 POWERLINK High Power Wireless LAN 802.11b/g/n USB Adapter User Manual Internet Connection Sharing (ICS) This page allows users to select the adapter for connect to public network. Please click on the device that are used for connecting to public network and click the...
