Authorized KICKER Dealer:
Purchase Date:
Speaker Serial Number:
MODEL:
Rated Impedance [Ω]
Fs [Hz]
Sensitivity [1W, 1m]
Qts
Qms
Qes
Re [2Ω, 4Ω]
Vas [ft³, L]
Continuous Power Handling [Watts RMS]
Outer Frame Dimension [in, cm]
Mounting Depth [in, cm]
Mounting Hole Diameter [in, cm]
Frequency Response [Hz]

INSTALLATION

Wiring: Carefully place the speaker wire in a location that is clear of standing water and moving
components of the boat. The terminal cover is removable for wiring installation and, when locked
in place, it aids in ignition protection. Connect the speaker wire to the speaker terminals. Loop the
positive and negative wires into the pocket in the cover, then together and through the slot.
Remove Terminal Cover
2
Terminal Cover Pocket
Route wire through
Terminal Cover Slot
KMW10 Subwoofer
Owner's Manual
KMW10
2 or 4
32
86.5 dB
0.550
14.361
0.580
1.89, 3.6
1.65, 46.6
150
11-1/8, 28.3
5, 12.7
9-1/4, 23.5
30 - 500
Connect wire to terminals
