MANUAL CLIMATE CONTROL SYSTEM
GETTING
TO KNOW
YOUR CAR
SAFETY
STARTING
AND DRIVING
fig. 38
IN AN
EMERGENCY
CONTROLS fig. 38
SERVICING AND
A air temperature adjustment knob:
MAINTENANCE
❍ blue zone = cold air
❍ red zone = hot air
B climate control compressor on/off button;
TECHNICAL
C fan activation/adjustment knob:
SPECIFICATIONS
❍ 0 = fan off
❍ 1-2-3-4-5-6 = fan speed
CONTENTS
60
D heated rear windscreen on/off button;
E air distribution knob:
❍ various selections are possible
❍ quick demisting (windscreen and side windows)
F air recirculation on/off button
A0K0055m
