- Page 1 Upright Service Manual ProGen Models 1073300 & 1073290...
-
Page 2: Table Of Contents
Motor ....................5-7 procedure on any ProTeam vacuum, Power Head Hose ................... 8 ALWAYS disconnect the vacuum Front Wheel .................... 8 from power source. Rear Wheel ..................... 9 View Upright Vacuum Wiring Schematic at www.pro-team.com www.pro-team.com 866.888.2168... -
Page 3: Base Cover
Base Cover Remove brush Remove five (5) (M4 x 16mm length) screws To Reassemble. Repeat steps in reverse. Remove cover - Lift up on one side www.pro-team.com 866.888.2168... -
Page 4: Attention Clutch, Led Front Light, Belts, And Control Boards
Remove RPM sensor - Remove screw lift by wires (M4 x 16mm length) Remove LED light - Lift straight up on sensor Remove printed circuit board - Remove two (2) screws (M4 x 16mm length) control board, do not lift by wires www.pro-team.com 866.888.2168... -
Page 5: Clutch, Led Front Light, Belts, And Control Boards
Clutch, LED Front Light, Belts, and Control Boards Lift up on control board Remove clutch assembly - Remove two (2) (M3 x 12mm length) screws Remove clutch assembly - Slide belt off pulley Remove clutch assembly To Reassemble. Repeat steps in reverse. www.pro-team.com 866.888.2168... -
Page 6: Filter Bag Housing
Remove two (2) (M4 x 16 mm length) screws and bracket on each side housing back Remove power head hose from bag housing Lift up on bag housing and slide belt off motor pulley To Reassemble. Repeat steps in reverse. www.pro-team.com 866.888.2168... -
Page 7: Before Servicing Any Part Or Foot Pedal
- Lift up on foot pedal To Reassemble. Repeat steps in reverse. Motor Remove rear bag housing cover - Remove Remove plastic sleeve bearing each side - pull nine (9) (M4 x 20mm length) screws straight off www.pro-team.com 866.888.2168... - Page 8 Remove steel sleeve bearing on each side - Pull (M4 x 20mm length) straight off Remove filter door on each side Remove air separator and motor - Remove two (2) (M4 x 20mm length) screws Remove gasket Lift motor assembly upward www.pro-team.com 866.888.2168...
-
Page 9: Motor
Remove motor brush assembly - Remove two Remove upper motor housing - Remove six (6) (2) (M4 x 16mm length) screws (M4 x 16mm length) screws To Reassemble. Repeat steps in reverse. Pinch tab end and pull to release www.pro-team.com 866.888.2168... -
Page 10: Power Head Hose
Remove power head hose - Remove four (4) Remove hose by twisting/unthreading (M4 x 16 mm length) screws To Reassemble. Repeat steps in reverse. Front Wheel To Reassemble. Repeat steps in reverse. Remove center wheel - Pull wheel upwards - Slide wheel off shaft www.pro-team.com 866.888.2168... -
Page 11: Rear Wheel
Rear Wheel Remove rear wheel (push) e-clip off shaft Pry axle from base Tap axle out with a hammer To Reassemble. Repeat steps in reverse. Note: Shaft knurl is a light press fit into the base. www.pro-team.com 866.888.2168... - Page 12 P.O. Box 7385, Boise, Idaho 83707 • 866.888.2168 www.pro-team.com #SP6916 Revised 10/14...
