Clock (Lithium) Battery Removal/Insertion; Open Cover; Viewfinder Adjustment - JVC GR-AXM4U Instructions Manual

10
A
Set POWER to "CAMERA".
GETTING STARTED

Clock (Lithium) Battery Removal/Insertion

This battery is necessary for clock operation and to
perform date/time settings.
SWITCH OFF POWER
1
Switch off the unit's power and remove the power
supply unit.

OPEN COVER

2
Open the clock battery compartment cover while
pressing the release tab.
REMOVE BATTERY (when replacing)
3
Insert a pointed, non-metallic object between the
battery and the compartment (
battery out.
INSERT BATTERY
4
Ensuring the plus (+) side is up, insert a CR2025
lithium battery and push it in.
CLOSE COVER
5
Close the compartment cover until it clicks in place.
NOTE:
See "SAFETY PRECAUTIONS"(
on safe handling of lithium batteries.

Viewfinder Adjustment

POSITION VIEWFINDER
1
Adjust the viewfinder manually for best viewability
(see illustration at left).
SELECT MODE
2
Set the power switch to CAMERA.
ADJUST DIOPTER
3
Turn the diopter adjustment control until the
indications in the viewfinder are clearly focused.
NOTE:
When the power switch is set to CAMERA and the LCD
monitor is opened at an angle of 60 degrees or more, the
LCD monitor switches on and the viewfinder switches off
automatically to save power.
(cont.)
) and pull the
A
pg. 2) for information
