Installation Instructions and Homeowner's Manual
WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.
KOZY WORLD PHONE NUMBER: (814) 643-1775
http://www.worldmkting.com
ANSI/UL 1278. MOVABLE AND WALL OR CEILING HUNG ELECTRIC ROOM HEATERS
INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOME OWNER
CUSTOMER: PLEASE RETAIN THIS MANUAL FOR FUTURE USE
Comfort Home Products, Inc.
12256 William Penn Hwy, Ste A
Huntingdon, PA 16652
Kozy-World
EF5620R
Freestanding
Electric Fireplace
FOR YOUR SAFETY
DO NOT STORE
OR USE GASOLINE OR
OTHER FLAMMABLE VAPORS
OR LIQUIDS
IN THE VICINITY OF THIS OR
ANY OTHER APPLIANCE
®
Advertisement
Table of Contents
Related Manuals for Kozy-World EF5620R
Summary of Contents for Kozy-World EF5620R
-
Page 1: For Your Safety
Kozy-World ® EF5620R Freestanding Electric Fireplace Installation Instructions and Homeowner's Manual WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. FOR YOUR SAFETY Comfort Home Products, Inc. -
Page 2: Table Of Contents
TABLE OF CONTENTS PLEASE READ THE INSTALLATION & OPERATIONS INSTRUCTIONS BEFORE USING THIS APPLIANCE IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible electric shock, fire hazard and will void the warranty. Installation instructions……………………………………….…………………….…..…..2 General………………………………………………………………………….…..…..2 Locating Your Electric Fireplace………………………………...……………..…3... -
Page 3: Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS become blocked. PLEASE RETAIN THIS USER’S GUIDE FOR FUTURE REFERENCE When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to person, including the following: 1. Read all instructions before using this 13. -
Page 4: General
WARNING: Procedures and WARNING: Procedures and techniques, which, if not techniques, which, if not carefully followed, will result carefully followed, will expose in damage to the equipment the user to the risk of serious or personal property or may injury, illness or death. cause personal injury. -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS Note: Ensure the circuit breakers for the power supply are turned on. The controls are located behind the grill below front glass and can be accessed by pulling the grill up from the top, forward and down. 1. ON/OFF Button: Main power and flame effect. The red indicator light will turn on when heater is on. -
Page 6: Remote Control
INSTRUCTIONS FOR REMOTE OPERATION Plug in your electric fireplace and it will beep once. This means you have power and your remote is ready to operate your electric fireplace. 1. ON/OFF: Press this button to turn on the main power. 2. -
Page 7: Service Instructions
SERVICE INSTRUCTIONS WARNING: Disconnect power WARNING: Do not exceed before attempting any 40 Watts per light bulb. maintenance or cleaning to Use of a higher rated bulb reduce the risk of fire, may result in a fire electrical shock or personal causing property damage injury. -
Page 8: Instructions For Power
WARNING: Before servicing this heater be sure to unplug heater from wall outlet. Do not only turn off heater from the main “ON/OFF” switch, be sure to unplug this heater. SPECIFICATIONS: Model: EF5620R Voltage: 120V/60Hz Total Amps: 11.3 Amps Total Watts: 1500W... -
Page 9: Replacement Parts List
REPLACEMENT PARTS LIST ITEM DESCRIPTION Power Cord/plug NDF-68NR/94 Front Louver NDF-68NR/04 PVC Screen NDF-68NR/28 Remote Receiver NDF=68NR/11 Firebox Cabinet NDF-68NR/92R Log Set NDF-68NR/25 Rocker Switch NDF-68NR/31 Remote Handset NDF-68NR/85R Touch Switches NDF-68NR/70R Knob NDF-68NR/79 Flame Generator Motor NDF-68NR/55 Flame Reflector NDF-68NR/41 Bulb NDF-68NR/32...
