- Page 1 S5Ti OWNER’S MANUAL Important: Read all instructions carefully before using this product. Retain this owner’s manual for future reference. BH North America | 20155 Ellipse, Foothill Ranch, California 92610 | p.949.206.0330 | f.949.206.0350 | www.BHFitnessUSA.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Title Page Introduction Safety Information Exercise Instruction Training Guidelines Workout and Stretching Overview Assembly Instructions Belt Adjustments Console Operations Maintenance and Cleaning Information and Recommendations Exploded View Drawing Parts List Warranty... -
Page 3: Introduction
CONGRATULATIONS Congratulations on your purchase of BH Fitness equipment. We hope you appreciate the style, quality, and value that exercisers across North America have come to expect from BH Fitness. If you have any questions, concerns or product issues, please call our Customer Service at 1-866-325-2339 or email us at CustomerSupport@BHNorthAmerica.com. -
Page 4: Safety Information
SAFETY INFORMATION PRECAUTIONS The machine has been designed and constructed to provide maximum safety. Nevertheless, certain precautions should be taken when using exercise equipment. Read the whole manual before assembling and using the machine. Please observe the following safety precautions: 1. -
Page 5: Exercise Instruction
EXERCISE INSTRUCTION Use of the machine offers various benefits; it will improve fitness, muscle tone and when used in conjunction with a calorie controlled diet, it will help you lose weight. 1. Consult your doctor before starting any exercise program. It is advisable to undergo a complete physical examination. -
Page 6: Training Guidelines
TRAINING GUIDELINES Exercise is one of the most important factors in the overall health of an individual. Listed among its benefits are: • Increased capacity for physical work (strength endurance) • Increased cardiovascular (heart and arteries/veins) and respiratory efficiency • Decreased risk of coronary heart disease •... - Page 7 OXYGEN UPTAKE The effort that you can exert over a prolonged period of time is limited by your ability to deliver oxygen to the working muscles. Regular vigorous exercise produces a training effect that can increase your aerobic capacity by as much as 20 to 30%. An increased VO2 Max indicates an increased ability of the heart to pump blood, of the lungs to ventilate oxygen, and of the muscles to take up oxygen.
- Page 8 HEART RATE As you exercise, your heart beat increases. This is often used as a measure of the required intensity of an exercise. You need to exercise hard enough to condition your circulatory system, and increase your pulse rate, but not enough to strain your heart. Your initial level of fitness is important when developing an exercise program for you.
- Page 9 MUSCLE SORENESS For the first week or so, muscle soreness may be the only indication you have that you are on an exercise program. This, of course, does depend on your overall fitness level. A confirmation that you are on the correct program is a very slight soreness in most major muscle groups. This is quite normal and will disappear in a matter of days.
-
Page 10: Workout And Stretching
SUGGESTED STRETCHES Head Rolls Rotate your head to the right for one count while feeling the stretch up the left side of your neck. Next, rotate your head back for one count, stretching your chin to the ceiling. Rotate your head to the left for one count, and finally, drop your head to your chest for one count. - Page 11 SUGGESTED STRETCHES Inner Thigh Stretch Sit with the soles of your feet together with your knees pointing outward. Pull your feet as close into your groin as possible. Gently push your knees towards the floor. Hold for 15 counts. Toe Touches Slowly bend forward from your waist, letting your back and shoulders relax as you stretch toward your toes.
-
Page 12: Overview
OVERVIEW The assembly of this product requires two or more people. When assembling the uprights, one person should hold the uprights to prevent them from falling. -
Page 13: Assembly Instructions
ASSEMBLY INSTRUCTIONS STEP 1 (this step will require two people) Take the treadmill and the parts from the carton. Take the right upright post and connect the wire on the bottom of the post with the wire in the bracket at the front right of the machine. - Page 14 STEP 2 Connect wires from the console to the wires from the console tray. After connecting the wires, tuck them into the console. Secure the console housing with 4pcs of M6*25 screws. Make sure not to pinch the wires when tightening down the console. Console Console Tray...
- Page 15 STEP 3 (this step will require two people) Connect the wire in the right upper end of the upright post with the wire from the bottom right console tray bracket. Slide the left and right console tray brackets into the upright posts.
- Page 16 STEP 4 Tighten the screws on the upright posts where they connect to the frame and console tray. There should be 12 total screws. Once you have done that, installation is complete.
-
Page 17: Belt Adjustments
BELT ADJUSTMENTS To adjust the running belt, stop the treadmill, then use the Hex Wrench and adjust the Hex Screw located in the Rear End Cap. If the running belt is moving towards the left side, tighten the left Hex Screw about 1/4 turn (clockwise); if the running belt is moving towards the right side, tighten the right Hex Screw about 1/4 turn (clockwise);... -
Page 18: Console Operations
CONSOLE OPERATIONS GETTING STARTED: SWITCHING FROM MPH TO KM AND VICE VERSA 1. When taking out the safety key, E-07 will appear on the screen. Press the PROGRAM and MODE button at the same time. 2. MPH (M) and KM (KM) will appear on the screen. Choose according to preferences. 3. -
Page 19: Choosing/Starting Program
CHOOSING AND STARTING A PROGRAM 1. Program description: A. One Manual program: Normal, time count-down, calories count-down, distance count-down. B. P01,P02,P03,P04,P05,P06,P07,P08,P09,P10,P11,P12:12 pre-set programs. C. One body fat program. D. One HRC program. 2. How to start: A. Place the safety key in place. The LCD screen will light up for 2 seconds, the beeper will then make a sound. -
Page 20: Body Fat Program
will display: E07 while the beeper will make a sound. This machine will come to a complete stop within 3 seconds. H. When the count down hits zero for time, speed, calories, and distance all halt and the display will read "END". This means that the countdown is complete. -
Page 21: Parameters
display: 05, distance window will show 00 (body fat rate). To display the body fat rate: place two hands on the handle pulse sensor for about 8 seconds, distance window will then show the user’s body fat rate. 8. To start the fan, press the on/off fan button. It can also be turned off when the safety key is removed and placed back again, as well as pressing the STOP button. -
Page 22: Setting Information
Weight Loss Weight Loss (Beginner) Hill Run Hill Climb Rolling Hills Speed Run (Intermediate) Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline SETTING INFORMATION 1. Age setting: 15-80 years old. 2. (220-AGE) X 0.9. Target heart rate setting: 80: (220-AGE) X 0.9 3. -
Page 23: Troubleshooting
D: (user’s heart rate-target heart rate)<30, speed will reduce 0.6 MPH. 4. The machine will do this evaluation every 30 seconds. 5. If the user's heart rate exceeds (220-AGE), the speed will slow down to 0.6 MPH immediately and run for 15 seconds. An alarm will sound every second, then the treadmill will stop. 6. - Page 24 4. ELECTRONIC ERROR: E05 A: E05: Motor current is over limited. B: Solution: Visually inspect the motor to see if it turns freely. Make sure that there is nothing obstructing the movement of the running belt on rollers. If the problem persists, change the motor. 5.
-
Page 25: Downloading Software
DOWNLOADING APPS AND PAIRING YOUR DEVICE WITH YOUR EQUIPMENT DOWNLOADING THE SOFTWARE Connect the Apple device with the App Store (iTunes) or your Android Device with Google Play. Search for compatible fitness applications, read the APP introductions and Download the APPs with treadmill machine functions to your device, an example is TreadMonitor or other applicable apps. - Page 26 Mini iPad iPad iPad 2 BH Fitness i.Concept Bluetooth products are compatible with Apple devices with iOS 5.1 or later. It is recommended to update iOS to the latest version to obtain the best user experience. iPad, iPhone, iPod, iPod classic, iPod nano, iPod shuffle, and iPod touch, is a registered...
-
Page 27: Maintenance And Cleaning
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic accessory has been designed to connect specifically to iPod, iPhone, or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. -
Page 29: Parts List
PARTS LIST To order replacement parts: provide your customer service representative with the product model number and the part number located on the Parts List below, along with the quantity you require. Description Description S5Ti-1 Base frame S5Ti-60 Plastic bushing S5Ti-2... - Page 30 PARTS LIST CONTINUED S5Ti-43 Allen C.K.S. half thread bolt M8*50 S5Ti-100 Bracket (right) S5Ti-44 Phillips C.K.S. self-tapping screw S5Ti-101 MP3 socket cover S5Ti-45 Phillips C.K.S. full thread screw M4*10 S5Ti-102 Back cover S5Ti-46 Allen socket full thread screw M8*50 S5Ti-103...
-
Page 31: Warranty
WARRANTY LIMITED RESIDENTIAL WARRANTY BH Fitness will repair or replace, free of charge, at its option, parts that are defective as a result of material or workmanship. Lifetime replacement warranty coverage on frame and motor. Ten (10) year on other parts. Labor warranty coverage is one (1) year.
