Rear Panel
ON : Powers On/Off.
1
DC-IN: Connects the detachable D/C power adapter.
2
LNB-IN : One satellite cable can be connected.
3
Audio output :
4
Video output :
5
6 COAXIAL :
HDMI : Connects to TV using a HDMI cable for both audio and video signals.
7
USB : Connects the USB memory stick or external HDD.
8
9 Ethernet : Connects the set top box to network.
1
Connects to TV using RCA cable.
Connects to TV using RCA cable.
Connects to a digital audio system using S/PDIF cable.
5
2 3 4 6
9
7 8
