Operator's Manual
18.0 Volt Cordless String Trimmer
Model No. 267-3333
IMPORTANT :
WARNING! To reduce the risk of injury, user must read instruction manual.
Safety symbols in this manual are used to flag possible dangers. The safe-
ty symbols and their explanations require your full understanding. The safety
warnings do not, by themselves, eliminate any danger, nor are they substitute
for proper accident-prevention measures.
This Safety Alert Symbol indicates caution, warning, or danger. Failure to
obey a safety warning can result in serious injury to yourself or others. To reduce
the risk of injury, fire, or electric shock, always follow the safety precautions.
CHARGE BATTERY
BEFORE FIRST USE
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MasterForce 267-3333
Summary of Contents for MasterForce 267-3333
- Page 1 Operator’s Manual 18.0 Volt Cordless String Trimmer Model No. 267-3333 CHARGE BATTERY BEFORE FIRST USE IMPORTANT : WARNING! To reduce the risk of injury, user must read instruction manual. Safety symbols in this manual are used to flag possible dangers. The safe- ty symbols and their explanations require your full understanding.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Symbols ..................page 3-4 Safety Instructions ................page 5-9 Description ..................page 9-10 Assembly ....................page 11 Operation ....................page 12-20 Maintenance ..................page 21-22 Troubleshooting .................page 22 Warranty .....................page 23 INTRODUCTION SAVE THESE INSTRUCTIONS! This Cordless String Trimmer has many features for making its use more pleasant and enjoyable. -
Page 3: Safety Symbols
SAFETY SYMBOLS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures. - Page 4 Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) Watt...
-
Page 5: Safety Instructions
SAFETY INSTRUCTIONS GENRAL SAFETY RULES WARNING! When using electric gardening appliances, basic safety pre- cautions should always be followed to reduce the risk of fire, electric shock, and personal injury, including the following. Read All Instructions! Avoid Dangerous Environments – Don’t use appliances in damp or wet locations. - Page 6 Check Damaged Parts – Before further use of the appliance, a guard or other part that is damaged should be carefully checked to determine that it will operate properly and perform its intended function. Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting, and any other condition that may affect its operation.
- Page 7 Exercise care in handling batteries in order not to short the battery with conducting materials such as rings, bracelets and keys. The battery or conductor may overheat and cause burns. Do not open or mutilate the batteries. Released electrolyte is corrosive and may cause damage to the eyes or skin.
- Page 8 Make sure that the cord is located so that it will not be stepped on, tripped over, come in contact with sharp edges or moving parts, or otherwise subjected to damage or stress. This will reduce the risk of accidental falls, which could cause injury and damage to the cord, which could then result in electric shock.
-
Page 9: Description
Save these instructions. Refer to them frequently and use them to instruct others who may use this tool. If you lend this tool to someone else, also lend these instructions to them to prevent misuse of the product and possible injury. DESCRIPTION KNOW THE STRING TRIMMER (Fig.1) Before attempting to use this trimmer, become familiar with all of its... - Page 10 PRODUCT SPECIFICATIONS Motor 18Volt DC No Load Speed 9000 RPM Cutting capacity 12” (305mm) Line diameter Twist 0.065” (1.65mm) Shaft rotation Replacement spool part number 267-3334 Weight (without battery) 4 LBS 1 OZ Battery Voltage 18 Volt DC Charger Input 120-Volts, 60 Hz AC only Optimum Charging Temperature 41°F (5°C) -122°F (50°C)
-
Page 11: Assembly
ASSEMBLY WARNING! If any part is broken or missing, do not attempt to attach the battery or operate the String Trimmer until the broken or missing part is re- placed. Failure to do so could result in possible serious injury. WARNING! Do not attempt to modify this tool or create accessories not recommended for use with this String Trimmer. -
Page 12: Operation
OPERATION POWER INDICATOR (Fig.2) Fig. 2 80-100% Charge 60-79% Charge 40-59% Charge 20-39% Charge Under 20% Charge High/low temperature This Li-ion battery pack is equipped with a power indicator, which is used to display the battery pack remaining run time. Press the power indicator button to display the LED lights. - Page 13 The power indicator will display four flashing LED lights if the circuitry detects a momentary overload. You can conveniently reset the battery pack by releasing the power-tool trigger. Press the power indicator button again to display the remaining charge. NOTE: If the power indicator continues to flash four LED lights after resetting, place the battery pack on the charger to evaluate the battery condition.
- Page 14 3. Attach the battery pack to the Fig. 3 charger by aligning the raised ribs of the battery pack with the slot in the charger. Slide the battery pack onto the charger (Fig. 3) 4. The Charger will communicate with the battery pack’s circuitry to evaluate the condition of the battery pack.
- Page 15 DEFECTIVE BATTERY If the charger detects a problem, the red LED will begin flashing and the green LED will be off. 1. If registering as defective, remove and reinsert the battery pack in the charger. If the LED status reads “defective” a second time, try charging a different battery pack.
- Page 16 TO DETACH BATTERY PACK (Fig. 5) 1. Lock the trigger switch in “OFF” position. 2. Depress the battery release buttons located on the front of the battery pack to release the battery pack. 3. Pull forward on the battery pack to remove from the tool. CAUTION: when placing battery pack on the tool, be sure that the raised rib on battery pack aligns with the groove on the saw and the latches snap into place properly.
- Page 17 CUTTING HEIGHT ADJUSTMENT (Fig.8) The overall height of the trimmer Fig. 8 can be adjusted. 1. Remove the battery pack. 2. Pull the lock collar to loosen the telescoping shaft. 3. The telescoping shaft can then be adjusted to be shorter or longer.
- Page 18 OPERATION CAUTION: Always wear eye protection. CAUTION: Inspect the area to be trimmed and remove any wires, cords, or string-like objects which could become entangled in the rotating line or spool. Be particularly careful to avoid any wire which might be bent outward into the path of the tool, such as barbs at the base of a chain link fence.
- Page 19 LINE FEEDING Your trimmer uses 0.065” diameter twist nylon line to cut grass and weeds quickly and easily. Check the nylon line regularly. When trimming performance decreases, adjust the line length. With the trimmer running, bump the cutting head on the grass; the nylon line will extend automatically.
- Page 20 REWINDING SPOOL FROM BULK LINE (Use only 0.065” diameter line) To install bulk line, follow the steps below. 1. Turn off the trimmer and remove the battery. 2. Press the release tabs on the line spool cover and remove the cover by pulling it straight off.
-
Page 21: Maintenance
MAINTENANCE CAUTION! Before performing maintenance or cleaning, remove the bat- tery pack from the trimmer. 1. The tool may be cleaned most effectively with compressed dry air. Always wear safety goggles when cleaning tools with compressed air. 2. Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of commercial solvents. -
Page 22: Troubleshooting
WARNING! Upon removal of the battery pack for disposal or recycling, cover the battery pack’s terminals with heavy-duty adhesive tape. Do not at- tempt to destroy or disassemble battery pack or remove any of its components. Lithium-Ion batteries must be recycled or disposed of properly. Also, never touch both terminals with metal objects and/or body parts as short circuit may result. -
Page 23: Warranty
WARRANTY 3-MONTH MONEY BACK GUARANTEE: This MASTERFORCE™ brand power tool carries our 3-Month Money Back Guarantee. If you are not completely satisfied with your MASTERFORCE™ brand power tool for any reason within three (3) months from the date of purchase, return the tool with your original receipt to any retail store, and we will provide you a refund –...
