- Page 1 BLVMS 8100 Benutzer- und Wartungshandbuch User and maintenance manual Manuel d’utilisation et d’entretien Handleiding voor gebruik en onderhoud...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS YOUR SAFETY AND THAT OF OTHERS IS VERY IMPORTANT This manual and the appliance itself provide important safety warnings, to be read and observed at all times. This is the danger symbol, pertaining to safety, which alerts users to potential risks to themselves and others. All safety warnings are preceded by the danger symbol and the following terms: Indicates a hazardous situation which, if not avoided, will cause serious injury. - Page 4 - If the surface of the induction plate is cracked, do not use it and switch off the appliance to avoid the possibility of electric shock (only for models with induction function). - Do not touch the appliance with any wet part of the body and do not operate it when barefoot.
- Page 5 - Do not use containers made of synthetic materials. - Overheated oils and fats catch fire easily. Always remain vigilant when cooking foods rich in fat and oil. - Never leave the appliance unattended during food drying. - If alcoholic beverages are used when cooking foods (e.g. rum, cognac, wine), remember that alcohol evaporates at high temperatures.
-
Page 6: General Recommendations
GENERAL RECOMMENDATIONS Before use: Remove cardboard protection pieces, protective film and adhesive labels from accessories. Remove the accessories from the oven and heat it at 200° for about an hour to eliminate the smell and fumes from the insulating materials and protective grease. During use: Do not place heavy objects on the door as they could damage it. -
Page 7: After Sales Service
AFTER-SALES SERVICE Before calling the After-Sales Service: See if you can solve the problem yourself with the help of the suggestions given in the “Troubleshooting guide“. Switch the appliance off and back on again it to see if the fault persists. If after the above checks the fault still occurs, get in touch with the nearest After-sales Service. -
Page 8: Maintenance
MAINTENANCE Use protective gloves. WARNING Ensure the oven is cold before carrying out the following operations. Disconnect the appliance from the power supply. REMOVING THE DOOR To remove the door: Open the door fully. Lift the catches and push them forwards as far as they will go (fig. 1). Close the door as far as it will go (A), lift it up (B) and turn it (C) until it is released (D) (fig. - Page 9 Fig. 6 Fig. 7 Fig. 8 Fig. 9 N.B.: Only use 25-40W/230V type E-14, T300°C incandescent lamps, or 20-40W/230 V type G9, T300°C halogen lamps. The lamp used in the appliance is specifically designed for electrical appliances and is not suitable for household room illumination (Commission Regulation (EC) No 244/2009).
-
Page 10: Instructions For Oven Use
INSTRUCTIONS FOR OVEN USE FOR ELECTRICAL CONNECTION, SEE THE PARAGRAPH ON INSTALLATION Control panel Upper heating element/grill Cooling fan (not visible) Dataplate (not to be removed) Light Circular heating element (not visible) Turnspit (if present) Lower heating element (not visible) 10. -
Page 11: Control Panel Description
INSERTING WIRE SHELVES AND OTHER ACCESSORIES IN THE OVEN The wire shelf and other accessories are provided with a locking mechanism to prevent their accidental removal. Fig. 1 Insert the wire shelf horizontally, with the raised part “A” upwards (Fig. 1). Angle the wire shelf when it reaches the locking position “B”... -
Page 12: Function Details
FUNCTION DETAILS After selection of the desired function, the display will show further options and related details. 180°C --:-- Zone 3 Zone 4 TEMPERATURE COOK TIME Convection Bake Zone 2 --:-- Zone 5 Start PREHEAT END TIME Cursor Zone 1 To move between the different areas, turn the “Browse”... -
Page 13: Preheating The Oven
PREHEATING THE OVEN 200°C --:-- 200°C --:-- TEMPERATURE COOK TIME TEMPERATURE COOK TIME Conventional Conventional --:-- --:-- Start Start PREHEAT END TIME PREHEAT END TIME 200°C --:-- 200°C --:-- TEMPERATURE COOK TIME TEMPERATURE COOK TIME Conventional Conventional --:-- --:-- Start Start PREHEAT END TIME... - Page 14 SETTING END OF COOKING TIME / START DELAYED The end of cooking time can be set, delaying the start of cooking by up to a maximum of 23 hours and 59 minutes. This can only be done once cooking time has been set. This setting is only possible when pre-heating is not required for the selected function.
- Page 15 Confirm by pressing : the display shows the approximate cooking time. Place the dish in the oven and turn the “Browse” knob to position the cursor at “Start”, then press The display indicates which shelf food should be placed on. Do as instructed and press to start cooking.
-
Page 16: Function Description Table
FUNCTION DESCRIPTION TABLE FUNCTION SELECTOR KNOB To stop cooking and switch off the oven. LAMP To switch the oven interior light on/off. FAST PREHEATING To preheat the oven rapidly. To cook any kind of dish on one shelf only. Use the 3rd shelf. To cook pizza, CONVENTIONAL savoury pies and sweets with liquid fillings, use the 1st or 2nd shelf. - Page 17 SPECIAL To speed up defrosting of food. Place food on the middle shelf. Leave food DEFROST in its packaging in order to prevent it from drying out on the outside. For keeping just-cooked food hot and crisp (e.g.: meat, fried food or flans). KEEP WARM Place food on the middle shelf.
-
Page 18: Cooking Table
COOKING TABLE Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) 160-180 30-90 Cake tin on rack Leavened cakes Level 4: cake tin on rack 160-180 30-90 Level 1: cake tin on rack Drip-tray / baking tray or 160-200 35-90 Filled pies... - Page 19 Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) 180-190 40-55 Cake tin on rack Level 4: cake tin on rack 180-190 45-70 Savoury pies Level 1: cake tin on rack (vegetable pie, Level 5: cake tin on rack quiche lorraine) Level 3: cake tin on rack 1-3-5...
- Page 20 Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) Drip-tray or baking tray (turn food two thirds of the way Baked potatoes Medium 45-55 through cooking if necessary) Vegetables au gratin High 10-25 Drip-tray or pan on rack Level 4: pan on rack Lasagna &...
- Page 21 TESTED RECIPES in compliance with IEC 60350-1:2011-12 and DIN 3360-12:07:07 Recipe Function Pre- Shelf (from Temp. Time Accessories and notes heating bottom) (°C) (min) IEC 60350-1:2011-12 § 7.5.2 15-30 Drip-tray / baking tray Shortbread Level 4: baking tray 25-40 Level 1: drip-tray/baking tray IEC 60350-1:2011-12 §...
-
Page 22: Recommended Use And Tips
