Page 1: User Manual
User Manual English Version SDP95004 CAUTION ELECTRICALLY OPERATED PRODUCT Not recommended for children under 16 years of age. As with all electrical products, precautions should be observed during handling and used to reduce the risk of electric shock. -
Page 2: Table Of Contents
Contents Introduction Parts diagram WARNINGS Getting started Battery use Care & Maintenance Trouble Shooting Technical Specifications... -
Page 3: Parts Diagram
Instruction Parts Diagram Thank you for having chosen the SEA-DOO ® SEASCOOTER ™ GTI - with the SEASCOOTER swimming, snorkeling and ™ diving is effortless and fun. Years of design and engineering have resulted in a personal water propeller that gives you power - up to 2.5 mph/4km/h for up to 120 minutes of use at a depth of up to 30m/100ft - but at the same time is compact and light. -
Page 4: Warnings
WARNINGS • Read the user's manual carefully. • Do not use alcohol or mind-altering drugs prior to using this product. • Never remove the grilles except for maintenance. ® • Never stick body parts, clothing or other objects in the •... -
Page 5: Getting Started
Getting Started ® When you buy the SEA-DOO SEASCOOTER ™ GTI the Shown in "ON" position battery is disconnected and needs to be charged. Follow the Rotate to turn "OFF" safety cautions on pages 9 to 12 and charging instructions on pages 13 to 16. - Page 6 ® Using the SEA-DOO SEASCOOTER ™ for diving - adjusting the buoyancy. 5. If the SEASCOOTER sinks, remove the weight until it is ™ neutrally buoyant. Your SEASCOOTER ™ can be used for diving up to 30m/100ft but will need to be adjusted for neutral buoyancy. The If the SEASCOOTER ™...
-
Page 7: Battery Use
Battery Use Battery Use CAUTION ® • Your SEA-DOO SEASCOOTER GTI is supplied ™ with a battery that needs to be treated carefully as it will release potentially explosive gases during its normal cycle of use (off gassing). Please read the entire manual thoroughly and follow all instructions. - Page 8 Battery Use Battery Use CAUTION CAUTION ® • The battery supplied with your SEA-DOO • Never charge the battery in sealed container. SEASCOOTER ™ GTI releases a potentially explosive gas during charging. Charging should only take place • Never charge the battery near water. in a well ventilated area, away from children and naked flames or other ignition sources (cigarettes, sparks).
- Page 9 Battery Use Charging the battery For battery charging follow these instructions. 1. Always ensure that the Master Switch is Off - see figure ® 2. Always ensure that the SEA-DOO SEASCOOTER ™ GTI is out of the water, dry and placed in a dry area. 3.
- Page 10 17. Make sure the seals and sealing surfaces are clean 21. Replace the Buoyancy Control Chamber. and lubricated before replacing the Inner Nose Cone. 22. Replace the Outer Nose Cone making sure the key is See fig.8 aligned correctly and insert the Latches and lock the Nose Cone by giving them a half turn.
-
Page 11: Care And Maintenance
Care And Maintenance To replace a flat battery with a fully charged battery. Battery Care • Please read and understand important Battery Use 1. Follow the steps 1 to 7 on page 12, to open the safety information on pages 9 to 12. SEASCOOTER ™... -
Page 12: Trouble Shooting
Trouble Shooting • When storing the SEASCOOTER ™ for extended periods Unit does not function of time, open the Vent Plug in the Inner Nose Cone. If the motor does not start when both triggers are pressed, make sure • DO NOT store battery in SEASCOOTER ™. - Page 13 Fig.15 5. Whilst holding the Propeller, use an M6 socket to Fig.13 remove the nut from the Propeller shaft (See figure 16). Fig.14 Fig.16 Removing rear grille and Propeller to remove obstruction 6. Slide the Propeller off the shaft, taking care not to loose 1.
- Page 14 SEASCOOTER™ cuts out To protect the electronic circuit of your SEASCOOTER ™ from damage a safety mechanism has been built in that cuts the power if a wall or rock or other immovable object is hit. If this occurs simply wait for a short period to allow the SEASCOOTER to reset itself and resume use.
-
Page 15: Technical Specifications
Technical Specifications For more information on Unit Dimensions 24 x 15.2 x 12.3” (612 x 385 x 312 mm) Sea-Doo ® Seascooter Products ™ Unit Weight 18 lbs (8.2 kg) (with rechargeable battery) ( Warranty, Customer Care / Maintenance, Parts & Battery Purchase ) Battery Type 1 x rechargeable battery PLEASE VISIT...
