Page 1: Quick Installation Guide
Mini Dome Network Camera Quick Installation Guide Before attempting to set up or operate this camera, please read this installation guide and retain it for future reference. Model No. TN2200 QR-code for camera installation in the C4Home app. V1-130906 P/N: 3GA0310904... - Page 2 The information in this document is subject to change without notice. COMPRO reserves the right to make revisions to this publication without obligation to notify any person or entity of any such changes.
-
Page 3: Table Of Contents
Technical Specifications ........18 TN2200 Technical Specifications ......18 Technical Support Information . -
Page 4: Important Notices
• Please do not place the camera around the heat sources, such as television or micro- wave oven. • Please do not remodel the camera; it may cause damage or fire. • Please do not attempt to repair the camera on your own; contact Compro or your lo- cal distributor for repair service. Important Notices... -
Page 5: Product Overview
If anything is missing, please don’t hesitate to contact your local distributor. Item Description Network camera Compro TN2200 network camera Wall mount base For mounting the camera on the wall Self-tapping screw For fastening the wall mount base to the wall,... -
Page 6: Hardware Overview
Hardware Overview Camera Layout Product Overview... - Page 7 Name Description Ethernet port For connection to the network Socket head screw (4 To remove the top cover, unscrew the 4 socket head in total ) screws with the supplied L-shaped wrench Microphone pinhole For receiving ambient sound Screw holes for wall For installing the wall mount base;...
-
Page 8: Installation
Installation Wall / Ceiling Mount The camera can be mounted on a wall or ceiling with or without the supplied wall Composite Video Output Reset Button mount base installed. The wall mount base is generally used for wall mount applications when the camera's cable is not run through the mounting surface. - Page 9 3. Then, if you're mounting on a concrete wall, insert a screw anchor into each of the mounting holes. After that, secure the wall mount base to the wall with the supplied self-tapping screws. 4. Fasten the camera to the wall mount base on the wall. Make sure you use a sup- Rubber O-ring plied rubber O-ring in between the screws and the screw holes (as circled) to avoid moisture entering the casing.
- Page 10 Rubber O-ring Rubber O-ring Note: Should you ever need to detach the mounted camera from the wall in the future, simply twist the camera in counter-clockwise direction and then pull it off the wall. Installation...
- Page 11 Without Using Wall Mount Base 1. Use the supplied hex key to remove the top cover. 2. Drill 2 mounting holes on the mounting surface. The 2 screw holes should be spaced exactly 80 mm (3.15 inch) apart to correspond to the position of mount- ing holes on the camera.
-
Page 12: Connect The Cables
Rubber O-ring Connect the Cables This camera can only be powered using PoE (Power-over-Ethernet), which allows elec- trical power and IP data to be both delivered on a single Ethernet cable. The following instructions explain ways to connect this PoE-enabeld network camera. Using a PoE Switch If the Ethernet ports on your network switch/router support PoE, connect your camera in the following way:... - Page 13 1. Ethernet cable from wireless router/hub to PoE switch/router: Connect the PoE switch/router with the wireless router/hub that has been connected to your Cable/ADSL modem for internet connecting. PoE Switch Wireless 2. Ethernet port of the camera: Use the RJ-45 Ethernet cable (not supplied in the Router/Hub (802.3af class3) package) to connect the Ethernet port of the network camera to the PoE port of...
-
Page 14: Install C4Home App And Add Camera
Install C4Home App and Add Camera Make sure your smartphone is able to go to internet via your wireless router. Then download the C4Home app from Apple store or Google Play and install to your smart- phone. Start C4Home app and register your personal C4Home account. (You can scan the QR-code below on your smartphone to add C4home app.) Login to the C4Home account and click “+”... -
Page 15: Adjust The Lens
Adjust the Lens To adjust the direction of the lens, you need to remove the camera’s top cover first. You can connect the camera’s composite video jack to the video input jack of your TV to aid you in lens adjustment. Composite Video Output Reset Button Adjust Pan/Tilt... -
Page 16: Change Sd Memory Card
90° 40° 4. Having obtained the optimal result, tighten the tilt adjustment screws and re- attach the top cover to complete the operation. Change SD Memory Card The camera comes with a 4GB microSD card pre-installed inside the housing. The SD memory card is user-upgradeable. -
Page 17: Operation
From C4Home iPhone/Android App When you enable and register the C4Home service, you can use the C4Home app on your iPhone, Android phone or tablet to manage and watch live video of Compro cloud network cameras. The C4Home app is a safe and easy way to monitor your home, office and your valuable possessions from anywhere in the world. - Page 18 Camera Page After login the C4Home app, you will see the camera page, here shows the camera list, you can click to watch the live video or you can click the buttons below for more fea- tures. Icon Name Description Click here to remove the installed network camera Edit from list.
-
Page 19: Reset To The Factory Default Settings
2. Press and hold the reset button for about 10 seconds. 3. After the camera is reset, it will take 1 minute to reboot. Please wait patiently and start the Compro iWizard later again to scan for and re-configure the camera. Operation... -
Page 20: Technical Specifications
Technical Specifications TN2200 Technical Specifications Sensor 1/3" CMOS 2-Megapixel sensor Lens Fixed iris, F 2.0, f 1.96mm Zoom 10x digital Angle of View 105° CAMERA Min Illumination 1.0 lux Shutter Time 1/5 ~ 1/16000 Sec. Camera Angle 40° pan, 90° tilt... - Page 21 Internet Explorer • Remotely viewing and adjust camera settings (ActiveX) • Capture snapshots and recording video • PC, laptop, tablet, nettop with IE8 Web Browser Supported • iPhone®/iPad, BlackBerry, Android™, WM, PDA, Viewing or cell phones with web browser (MJPEG mode) Devices • Mac OS 10.6 (Live view in M-JPEG mode only) Free mobile applications for iPhone and Android • Smart motion detection and push notification • Private mode • Mobile digital zoom control • Air firmware update C4Home App • Dropbox cloud storage for event snapshot Mobile • SD card playback for event recording Monitor • Share video to others • Watch 4 channels at the same screen (Android only, not support iOS) MJPEG Mode Viewing of camera image via phone browsers...
- Page 22 Free bundles ComproView 32-channels video Video Surveillance management software Built-in microSD memory slot (inside case) Local Storage (with a pre-installed 4GB memory card) Operating Temperature: 0 °C ~ 50 °C (32 °F ~ 122 °F) Condition Humidity: 20~80% RH non-condensing Weather IP66-Rated Resistance...
-
Page 23: Technical Support Information
Technical Support Information Contact Compro Technical Support If you need any technical support, fill out the online form (http://comprousa.com/en/ form.htm) or directly email to support@comprousa.com. Compro Technology, Inc. www.comprosecurity.com Tel. +886 2 2918 0169, Fax +886 2 2915 2389 4F, No.12, Alley 6, Lane 45, Pao Shin Road,... - Page 24 . c o m p r o u s a . c o m Compro Technology Head Office 4F, No.12, Alley 6, Lane 45, Pao Shin Road, Hsintien District, New Taipei City 231, Taiwan Tel. +886 2 29180169 Fax. +886 2 29152389...
