2014 Own er's Man ual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2014 TEM and is the answer not in the manual?

Questions and answers

Don
May 2, 2025

The recycling pump runs all the time

1 comments:
Mr. Anderson
May 17, 2025

The Hot Spot 2014 TEM recycling pump may run continuously if the pressure switch is sensing flow through the heater even though the jet pump is off. This could be due to a faulty pressure switch or incorrect water flow. Contact an Authorized Service Technician for diagnosis and repair.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for Hot Spot 2014 TEM

  • Page 1 2014 Own er’s Man ual...
  • Page 2 (or spa) by children under 5 years of age. your Hot Spot spa is equipped with a locking cover that meets the AsTM F1346-91 standard for safety Important! covers and as a result, is usually exempt from most barrier requirements.
  • Page 3: Table Of Contents

    General Information ............28 Indoor/Basement Installation ..........4 Methods for Testing the spa Water ........ 28 spa Leveling Preparation ..........4 Hot Spot spa Water Maintenance Program ....29 spa cover Installation ............5 Freshwater Ag+ silver Ion system ....... 31 ®...
  • Page 4: Safety Information

    • To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. • To reduce the risk of injury, lower water temperatures are recommended for young children. Children are especially sensitive to hot water. • Make sure you always lock the child resistant locks after using the spa for your children’s safety. Every Hot Spot is equipped with a locking cover that meets the AsTM F1346-91 standard for safety covers. • Test the water temperature with your hand before allowing your child to enter the spa to be sure that it’s comfortable. Children are especially sensitive to hot water.
  • Page 5: Unclean Water

    • Persons taking medications that induce drowsiness, such as tranquilizers, antihistamines, or anticoagulants should not use the spa. HEAlTH problEMS AFFECTEd bY SpA uSE • Pregnant women should consult a physician before using spa. • Persons suffering from obesity or with a medical history of heart disease, low or high blood pressure, circulatory system problems, or diabetes should consult a physician before using spa. unClEAn WATEr • Keep the water clean and sanitized with correct chemical care. The recommended levels for your Hot Spot spa are: Free Available chlorine (FAc): 3.0-5.0 ppm Total Alkalinity: 40-120 ppm Water pH: 7.2-7.6...
  • Page 6: Important Spa Instructions

    • Use and lock the cover when the spa is not in use, whether it is empty or full. • Follow the Spa Care and Maintenance recommendations stated in this manual. • Use only approved accessories and recommended spa chemicals and cleaners. don’T: • Leave the Hot Spot spa exposed to the sun without water or the cover in place. exposure to direct sunlight can cause solar distress of the shell material. • Roll or slide the spa on its side. This will damage the siding. • Lift or drag the vinyl cover by using the cover lock straps; always lift or carry the cover by using the handles. • Attempt to open the electrical control box. There are no user serviceable parts inside. Opening of the control box by the spa owner will void the warranty.
  • Page 7: Outdoor Installation And Patio Installation

    If you install the spa outdoors, we recommend a reinforced concrete pad at least four inches thick. The Hot spot dealer for more ® reinforcing rod or mesh in the pad should be attached to a bond wire.
  • Page 8: Spa Cover Installation

    A wiring diagram is provided inside the equipment module showing where the connections are to be made. ElECTrICAl rEQuIrEMEnTS And prECAuTIonS your Hot Spot spa has been carefully designed to give you maximum safety against electrical shock. connecting the spa to an improperly wired circuit will negate many of the spa’s safety features. Improper wiring may also cause electrocution, risk of fire, and other risks of injuries. Please...
  • Page 9: 115 Volt 30 Amp Conversion (Sx & Tx Models)

    Conversion instructions Note: An Authorized Hot Spot spa Technician must reconfigure spa using the soft jumpers to allow the heater to run concurrent with jet pump. A licensed electrician must install the sub-panel (available from your Hot Spot spa dealer) to supply power to the spa.
  • Page 10: 230 Volt Wiring Conversion 50 Amp (Sx & Tx Models)

    ImpoRtaNt: should you ever find the need to move or relocate your Hot Spot spa, it is essential that you understand and apply these installation requirements. your Hot Spot spa has been carefully engineered to provide maximum safety against electric shock. Remember, connecting the spa to an improperly wired circuit will negate many of its safety features.
  • Page 11 ImpoRtaNt: should you ever find the need to move or relocate your Hot Spot spa, it is essential that you understand and apply these installation requirements. your spa has been carefully engineered to provide maximum safety against electric shock. Remember, connecting the spa to an improperly wired circuit will negate many of its safety features.
  • Page 12: 230 Volt Subpanel Wiring Instructions

    230 VOlT SUBPANEl WIRING INSTRUCTIONS EMpO ELAY & hYThM Note: The subpanel must be placed within 100 feet (30.5m) of the main electrical service panel, and between 5 (1.5 m) and 50 feet (15 m) away from the spa. All electrical connections must be made in accordance with the wiring information contained in this manual and on the back of the field wiring access panel of the control box.
  • Page 13: Spa Specifications & Illustration

    SpA SpECIFICATIONS & ILLUSTRATION TEMpO (MOdEl TEM) HoRIZoNTAL dIMeNsIoNs: ... . . 89” (226 cm.) square HeIGHT (without cover): ....38” (97 cm.) eFFecTIVe FILTeR AReA: .
  • Page 14: Relay (Model Rel)

    RELAY (MOdEl REl) HoRIZoNTAL dIMeNsIoNs: ... . . 84” (213 cm.) square HeIGHT (without cover): ....36” (91 cm.) eFFecTIVe FILTeR AReA: .
  • Page 15: Rhythm (Model Rhy)

    RhYThM (MOdEl RHY) HoRIZoNTAL dIMeNsIoNs: ... . . 84” (213 cm.) square HeIGHT (without cover): ....36” (91 cm.) eFFecTIVe FILTeR AReA: .
  • Page 16: Sx (Model Sx)

    SX (MOdEl SX) HoRIZoNTAL dIMeNsIoNs: ... . . 72” (183cm.) square HeIGHT (without cover): ....33” (83.8 cm.) eFFecTIVe FILTeR AReA: .
  • Page 17: Tx (Model Tx)

    TX (MOdEl TX) HoRIZoNTAL dIMeNsIoNs: ... . . 68.5" x 68.5" (174 cm x 174 cm) HeIGHT (without cover): ....29” (74 cm.) eFFecTIVe FILTeR AReA: .
  • Page 18: Operating Instructions

    START-UP ANd REFIll PROCEdURES your Hot Spot spa has been thoroughly tested during the manufacturing process to ensure reliability and long-term customer satisfaction. A small amount of water may have remained in the plumbing after testing and, as a result, may have spotted the spa shell or the spa siding prior to delivery.
  • Page 19: Heating And Hydromassage Systems

    HEATING ANd HYdROMASSAGE SYSTEMS The Hot Spot spas use two-speed jet pumps to operate hydromassage jets and to circulate the spa water through the heating system (the tempo , Relay and RHytHm are also equipped with a single speed jet pump used for jets only). The low speed mode of the pump, which is activated automatically by the control thermostat, will cause the spa water to be drawn slowly in through the filter, the heater, and into the pump.
  • Page 20: Safety Equipment

    SAFETY EQUIPMENT A. GFcI: The Ground Fault circuit Interrupter, located on the end of the power cord (115 Volt models only), is a safety device that is designed to sense as little as 5 milliamps of electrical current leakage to ground. It is very important to protect a GFcI from rain and other moisture. Watkins Manufacturing corporation recommends that the GFcI be tested before each use to ensure it is functioning correctly.
  • Page 21: System Mode

    READY jET puMp ConTrol Pressing the Jet button for the tempo, Relay & RHytHm changes the jet pump functions, depending on the number of presses: 1st press: Two-speed jet pump runs on low speed 2nd press: Two-speed jet pump runs on high speed 3rd press: one and Two-speed jet pumps run on high speed 4th press:...
  • Page 22: Locking Features

    To enter into the TooLs menu, scroll through the main menus using the seT  b utton until the TooLs menu is illustrated. Press the TeMP   b utton to enter into the TooLs submenu, use the seT button to scroll through the submenus. once the desired submenu is illustrated, press the TeMP  ...
  • Page 23 Note: Whenever power is disconnected and then reconnected to the spa, the summer Mode timer will reset starting with the 8-hour shutdown mode. If a different 8-hour shut down time is desired, deactivate the summer Mode, then reactivate at the beginning of the desired eight-hour shut down time.
  • Page 24: Audio Menu (Optional)

    AudIo MEnu once the music system is installed, an AudIo menu will be accessible on the control panel screen. To access the menu, press the seT button on the control panel until AudIo is displayed. bASIC ConTrol pAnEl opErATIon • To enter into a sub-menu, or to adjust the current function displayed, use the temp ▲ or temp ▼ buttons.
  • Page 25 Note: Blue = Bluetooth ® . To use the Bluetooth screen, your audio Bluetooth device must be paired with the spa. on your device, find My Spa. If you do not see this on your device you may be too far away from spa or your Audio source is not set to BLue. Pair your device and you will be ready to use the Bluetooth.
  • Page 26: Tempo (Model Tem)

    TEMpO (MOdEl TEM) JET SYSTEM MENU jET puMp 1 • 2 Directional Hydromassage Jets on back wall. • 1 Water Feature. • 6 directional pReCISIoN Jets in Lounge (foot Jets). • 4 directional pReCISIoN Jets in Lounge (calf Jets). • 1 Directional Hydromassage Jet, 2 Rotary Hydromassage Jets and 4 Directional pReCISIoN Jets in lounge. • 2 directional pReCISIoN Jets and 1 Directional Hydromassage Jet on Left wall. jET puMp 2 • 10 directional pReCISIoN Jets on left back wall. • 4 directional pReCISIoN Jets and 2 Rotary Hydromassage Jets on back right wall.
  • Page 27: Jet Menus

    RELAY (MOdEl REl) JET SYSTEM MENU jET puMp 1 • 8 directional pReCISIoN Jets on back left wall. • 2 Directional Hydromassage Jets on back wall. • 1 Water feature. • 3 directional pReCISIoN Jets on right wall. • 2 directional pReCISIoN Jets and 1 Directional Hydromassage Jet on Left wall. • 2 directional pReCISIoN Jets in footwell. jET puMp 2 • 4 directional pReCISIoN Jets and 2 Rotary Hydromassage Jets on back right wall. •...
  • Page 28: Rhythm (Model Rhy )

    RhYThM (MOdEl RHY) JET SYSTEM MENU jET puMp 1 • 2 Directional Hydromassage Jets on back wall. • 4 directional pReCISIoN Jets and 2 Rotary Hydromassage Jets on back right wall. • 2 Directional Hydromassage Jets, 1 Rotary Hydromassage Jet and 2 Directional pReCISIoN Jets on front left side. jET puMp 2 • 8 directional pReCISIoN Jets on back left wall. • 1 Water feature. • 3 directional pReCISIoN Jets on right wall. • 6 directional pReCISIoN Jets and 1 Directional Hydromassage Jet on front right side. •...
  • Page 29: Sx (Model Sx)

    SX (MOdEl SX) JET SYSTEM MENU jET SYSTEM • 8 directional pReCISIoN Jets on back left wall. • 1 moto-maSSaGe Jet on right back wall. • 2 directional pReCISIoN Jets on front right wall. • 2 Directional Precision Jets in front left footwell. Page 26 page 26 jet Menu...
  • Page 30: Tx (Model Tx)

    TX (MOdEl TX) JET SYSTEM MENU jET SYSTEM • 8 directional pReCISIoN Jets on left back wall. • 1 moto-maSSaGe Jet on right back wall. • 1 Rotary Hydromassage Jet in front left footwell. jet Menu page 27 Page 27...
  • Page 31: Water Quality And Maintenance

    Watkins recommends that you either use an entirely chlorine-based system, or an alternative system which uses silver ions (the FReSHWateR ag + silver ion purifier). Hot SpRING FReSHWateR products, which Watkins recommends, are available from authorized Hot Spot dealers. GENERAl INFORMATION THE THrEE FundAMEnTAl ArEAS oF WATEr MAInTEnAnCE: • Water Filtration...
  • Page 32: Hot Spot Spa Water Maintenance Program

    C. If the CH is too high (commonly known as “hard” water), formation of scale on the spa’s shell surface and equipment can result. CH can be decreased by using the Vanishing act calcium remover available from your Hot Spot dealer. [Additionally, a stain and scale inhibitor, ® such as FReSHWateR stain and scale defense, should be added to the spa water, according to label instructions.] d.
  • Page 33 bAlAnCIng THE pH Add pH A. The ideal pH level for your spa water is 7.2-7.6. ALKALINE decReAseR sPA WATeR B. The pH level is the measure of acidity and alkalinity. Values above 7.6 are alkaline; To LoWeR pH (scALING ZoNe) those below 7.2 are acidic. Maintaining the proper pH level is extremely important for: • Optimizing the effectiveness of the sanitizer.
  • Page 34: Freshwater Ag+ Silver Ion System

    Freshwater SIlVER ION SYSTEM The silver ion system is comprised of the following products: • FReSHWateRsodium dichlor • FReSHWateRMonopersulfate (MPs) • FReSHWateR silver ion purifie ag + • CleaN SCReeN Pre-Filter CleaN SCReeN pre-Filter is used when filling a spa for the first time, at top off, or at refill. It attaches to a garden hose and filters out rust, dirt, detergents, algae and chemicals.
  • Page 35: Hot Spot Water Treatment Guide

    Hot Spot WATEr TrEATMEnT guIdE At spa startup or refill Follow start-up and Refill Procedures section Prior to each use Add one-half (½) teaspoon of chlorine per Add one (1) tablespoon of monopersulfate 250-gallons (950 liters) (MPs)* per 250-gallons (950 liters).
  • Page 36 Note: Well water may contain high concentrations of minerals. The use of a low water volume, extra-fine pore water filter (such as the CleaN SCReeN pre-filter) will help to remove many of the larger particles during the filling of the spa. CleaN SCReeN pre-filters can be purchased at your local Hot Spot spa dealer. Water Quality and Maintenance...
  • Page 37: Ozone (Optional)

    FoAM InHIbITorS spa water requires changing due to the build-up of soap in the water. Typically, soap will cause the spa water to foam when the jets are used. soap is introduced into the spa water from two sources; users’ bodies, which retain a soap residue after showering, and swimming apparel, which retains soap after washing. Foam inhibitors, such as FReSHWateR defoamer, can suppress foam, but cannot remove soap from the water. soap is very difficult to remove from the water because soap is not oxidized by any chemical added to the spa.
  • Page 38: Common Water Chemistry Questions

    While over-exposure to any chemical can be unhealthful, many low levels of chemicals are effective and beneficial. In the case of spa water, the chemicals recommended in the Hot Spot spa Water Maintenance program are needed to protect the user from water-borne pathogens (disease-causing microbes) and to prevent corrosion of spa components.
  • Page 39: Water Terminology

    WATER TERMINOlOGY The following chemical terms are used in this Water Quality and Maintenance section. understanding their meaning will help you to better understand the water maintenance process. Bromamines: compounds formed when bromine combines with nitrogen from body oils, urine, perspiration, etc. unlike chloramines, bromamines have no pungent odor and are effective sanitizers.
  • Page 40: Care Of Spa Pillow

    FIlTEr CArTrIdgE rEMovAl And ClEAnIng 1. disconnect the spa from the power supply by turning the power to the spa oFF. 2. Remove any floating items from within the filter compartment. RETAINER HANDLE 3. Turn the filter retainer handle (located on the top of the filter cartridge) counterclockwise until the retainer can be removed from the filter standpipe.
  • Page 41: To Clean/Condition Vinyl Cover

    The spa will drain by gravitational flow. ImpoRtaNt: All Hot Spot spa models will drain almost completely through the main drain valve. equipment such as the jet pump and heating system will drain. Any water remaining within the plumbing or equipment after draining will only need to be removed if the spa is being winterized.
  • Page 42: Winterizing Your Spa

    prEvEnTIon oF FrEEzIng your spa has been designed and engineered for year-round use in any climate. In some areas, extremely cold temperatures (below 10°F) combined with strong wind, may cause partial freezing of the jet pump, even though the water inside the spa remains at the selected temperature. The energy efficiency of the spa may also decrease during these cold periods, as the heater will cycle more frequently.
  • Page 43: Service Information

    2. The Hot Spot spa is equipped with a safety suction spring valve which will break the prime of the jet pump if both suction fittings are obstructed.
  • Page 44: Acts Invalidating Warranty

    ACTS INVAlIdATING WARRANTY The limited warranty is void if the Hot Spot spa has been subjected to alteration, misuse or abuse, or if any repairs on the spa are attempted by anyone other than an authorized representative of Watkins Manufacturing corporation. Alteration is defined as any component or plumbing change, electrical conversion, or the addition of any non-approved sanitation, or water purification device, or heating system which contributes to a component failure, unit failure, or unsafe operating condition.
  • Page 45: Troubleshooting

    Watkins Manufacturing corporation strives to provide the most trouble-free spas on the market. should you experience any problem whatsoever, do not hesitate to contact your authorized Hot Spot spa dealer. Here are some tips to help you to diagnose and rectify some more common sources of trouble yourself, if you choose to do so.
  • Page 46: Priming The Pumps

    PRIMING THE PUMP(S) upon filling or refilling the spa, if a pump is operating and water is not flowing from any of its jets, the pump may not be properly primed. To correct, refer to the illustration below and perform the following procedures: • Turn off power to the spa at the breaker and remove the equipment compartment door.
  • Page 48 (ModeL sX/sXc) (ModeL TX/TXc) ©2013 Watkins Manufacturing corporation. Hot spot, Tempo, Relay, Rhythm, Precision, No-Fault, FreshWater, FreshWater Ag+ , everFresh, clean screen and Vanishing Act are trademarks of Watkins Manufacturing corporation. Baquaspa is a trademark of Arch UK Biocides Limited.
