Congratulations on your decision to enjoy the finest spa available...
Welcome to the growing family of Hot Spot
Pre-Delivery Instructions
Please take the time to read this booklet carefully, as it will provide you with the information you will need to ensure
the safe, secure, and timely installation of your new spa. The following sections are guidelines on how to prepare for
delivery and set-up of your new spa. Specifically covered are site selection, delivery access, ground preparation, and
electrical requirements.
Remember to carefully read the Owner's Manual that accompanies your spa, and to complete the warranty register
within 10 days of delivery. These items, along with other valuable information, will be found in the Owner's Package
which has been placed in the equipment compartment of your spa, where you will also find its serial number.
Watkins Manufacturing Corporation reserves the right to change features, specifications and design without
notification and without incurring any obligation.
DATE PURCHASED: _________________________________________________________________
DATE INSTALLED: ___________________________________________________________________
DEALER: ___________________________________________________________________________
ADDRESS: __________________________________________________________________________
TELEPHONE: _______________________________________________________________________
In most cities and counties, permits will be required for the installation of electrical circuits or the construction of
exterior surfaces (decks and gazebos). In addition, some communities have adopted residential barrier codes which
may require fencing and/or self-closing gates on the property to prevent unsupervised access to a pool (or spa) by
children under 5 years of age. Your Hot Spot spa is equipped with a locking cover that meets the ASTM F1346-91
Standard for Safety Covers and as a result, is usually exempt from most barrier requirements. As a general practice,
your local Building Department will inform you of any applicable barrier requirements at the time a permit is obtained
for the installation of an electrical circuit. Your Hot Spot dealer can provide information on which permits may be
required.
Hot Spot Spa Pre-Delivery Instructions
®
Spa owners.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEMP and is the answer not in the manual?

Questions and answers

Summary of Contents for Hot Spot TEMP

  • Page 1 10 days of delivery. These items, along with other valuable information, will be found in the Owner’s Package which has been placed in the equipment compartment of your spa, where you will also find its serial number. Watkins Manufacturing Corporation reserves the right to change features, specifications and design without notification and without incurring any obligation.
  • Page 2: Outdoor And Patio Installation

    SIte SeleCtIon anD PreParatIon IMPortant: Site selection and preparation are your responsibility. Carefully read these instructions and consult ® your authorized Hot Spot dealer if you have any questions. You probably have a spot picked out for your new spa, whether it’s indoors or outdoors, on a patio or on a deck. Just make sure you check the following: • Always put your spa on a structurally sound, level surface. A filled spa can weigh a great deal. Make certain that the location you choose can support the weight of your filled spa.
  • Page 3: Delivery Access

    DelIVerY aCCeSS First, locate the dimensions of your spa on the following chart. The dimensions shown are the measurements of the spa in the vertical position, laid on its side. Next, contact your dealer to find the height and width added by the delivery cart which the dealer will use to deliver your new spa.
  • Page 4: Ground Preparation

    If the spa has to be taken off of the cart to go over a wall (either because the entry area is too narrow, the eaves are too low, the corner is too tight, or the stairway is too steep), a crane will be required. Don’t be alarmed! The crane has a truck-mounted boom which can fit right in your driveway.
  • Page 5 4.0” (10.2cm) 84.25” (214.0cm) 88.75” (225.4cm) note: Watkins Manufacturing Corporation recommends that the Tempo be installed on a minimum 4” thick reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification chart.
  • Page 6 (10.2cm) 80.25” (203.8cm) 83.5” (212.1cm) note: Watkins Manufacturing Corporation recommends that the Relay be installed on a minimum 4” thick reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification chart. WarnInG: tHe relaY MuSt not be SHIMMeD In anY Manner.
  • Page 7 (192.4cm) (Bottom view) DOOR SIDE note: Watkins Manufacturing Corporation recommends that the Sprint be installed on a minimum 4” thick reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification chart. WarnInG: tHe SPrInt MuSt not be SHIMMeD In anY Manner.
  • Page 8 (Bottom view) DOOR SIDE note: Watkins Manufacturing Corporation recommends that the Dash be installed on a minimum 4” thick reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification chart. WarnInG: tHe DaSH MuSt not be SHIMMeD In anY Manner.
  • Page 9: Electrical Requirements

    eleCtrICal reQuIreMentS SeleCtInG tHe VoltaGe For Your SPa The Dash™ spa model is designed to operate at 115 volts 20 amps or 115 volts 30 amps, 60 Hz and the Tempo™, Relay™ & Sprint™ spa models require a 230 volt power supply. When the Dash spa model is connected to 115 volts 20 amps, the heater will provide approximately 1000 watts of heat only when the jet pump is operating in LOW speed and the thermostat is calling for heat. When the Dash spa model is connected to 30 amps, the heater will provide heat whether the pump is operating in LOW or HIGH speed and the thermostat is calling for heat. All electrical connections must be made in accordance with the wiring information contained in the electrical control box or on the back of the field wiring access panel of the equipment module.
  • Page 10: Volt Installation

    115 Volt 30 aMP ConVerSIon (DaSH SPa MoDel) ™ To ensure you will have an opportunity to use your spa soon after delivery, it is very important that the required electrical service has been installed. Unless otherwise stipulated by your dealer, tHIS IS Your reSPonSIbIlItY. IMPortant: All electrical circuits must be installed by a qualified, licensed electrician.
  • Page 11: Spa Specifications

    SPa SPeCIFICatIonS CONTRACTOR SUGGESTIONS Electrician Name: ____________________________________________________________________________ Telephone: ____________________________________________________________________________ Name: ____________________________________________________________________________ Telephone: ____________________________________________________________________________ General Name: ____________________________________________________________________________ Telephone: ____________________________________________________________________________ Name: ____________________________________________________________________________ Telephone: ____________________________________________________________________________ Page 11 Page 11 Pre-Delivery Instructions...
  • Page 12 ADDITIONAL PRODUCTS AvAILAbLE fROM yOUR HOT SPOT SPA DEALER ® ® • EverFresh water care system ® • FreshWater water care products • Vanishing Act™ Calcium Remover • Clean Screen™ Pre-Filter • Vinyl covers • Spa vacuums • Stain kits • Spa upgrade jet kits • Replacement filter cartridges •...
  • Page 13 ® SERvICES AvAILAbLE fROM yOUR HOT SPOT SPA DEALER Service Cost Pre-Delivery site inspection _____________ Deliver spa to installation site _____________ Unwrap spa and haul away packaging material _____________ Set up & level spa _____________ Fill the spa with water _____________ Connect the spa to its power source (115 Volt 20 amp models) _____________...
  • Page 14 Spa Specifications Tempo™ 89"x 89" 38" 4,000 920 5915 230 volt, 50 amp (TEM) Square Gallons lbs. lbs. lbs. per Single phase 2.26m .97m feet square GFCI circuit Seating 1514 2683 foot (6 Adults) 2.26m 6m² litres Relay™ 84"x 84" 36" 4,000 4636 230 volt, 50 amp (REL) Square...
  • Page 15 NOTES: Page 15 Page 15...
  • Page 16 ® WATKINS MANUFACTURING CORPORATION 1280 Park Center Drive Vista, California 92081 (800) 999-4688 extension 8432 ©2010 Watkins Manufacturing Corporation. Hot Spot, Hot Spring, Tempo, Relay, Sprint, Dash, Cover Cradle, UpRite, Lift 'n Glide, EverFresh, FreshWater, Vanishing Act, Clean Screen and The Home Relaxation Specialists are trademarks of Watkins Manufacturing Corporation. Part #62758 Rev. A (2/10) Page 16...
