WARNING!
Failure to install or use this product according to manufacturers recommendations may result in property
damage, serious bodily/personal injury, and/or death to you and those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the
safety information contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices
are essential to ensure the safety of you and those you are trying to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including fire.
4. Proper placement and installation are vital to the performance of this warning device. Install this product so that output
performance of the system is maximized and the controls are placed within convenient reach of the operator so that
s/he can operate the system without losing eye contact with the roadway.
5. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use,
the vehicle operator should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open
trunks or compartment doors), people, vehicles, or other obstructions.
6. The use of this or any other warning device does not ensure all drivers can or will observe or react to a warning signal.
Never take the right-of-way for granted. It is your responsibility to be sure you can proceed safely before entering an
intersection, driving against traffic, responding at a high rate of speed, walking on or around traffic lanes.
7. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying
all laws regarding warning signal devices. Therefore, the user should check all applicable city, state, and federal laws
and regulations. The manufacturer assumes no liability for any loss resulting from the use of this warning device.
Introduction:
The ECCO Rear Vision System is designed to provide rear of the vehicle information that may not be available to a driver relying solely
on a vehicle's standard rear view mirror system. A driver using a properly installed and maintained ECCO Rear Vision System, in
conjunction with the standard rear view mirror system, can be alerted to potential safety hazards and thus take the appropriate action to
prevent an accident. This manual provides information about installation, function, safety, maintenance, replacement parts, and warranty.
Specifications:
Camera
Voltage Requirement
Power Consumption
Lens
Lens Angle
Audio
Light Sensor
Infrared LEDs
Pigtail Connection: CAM
920-5201-00 Rev. B

Installation Instructions

Camera/Monitor System
EC2014-SVC
1/3" Sony CCD Color
NTSC: 510*492,
PAL: 500*580 Pixels
12VDC
3 W
F=2.8mm / F=2.0
120°
Yes
Auto Switch B&W
11 (10M Max. Visibility)
Male 4 Pin Threaded
Camera
Housing
Mech. Vibration
Mounting
Weight
Dimensions (WxHxD)
Operating Temp.
IP Rating
Approvals
Current Consumption
EC2014-SVC
Aluminum Alloy
10g
Rear/Front
0.74 lbs
2.87"x2.99"x2.60"
-22°F to 158°F
IP69K
FCC, CE/R10, C-Tick, E13
250mA Max
Page 1 of 8
