Ecco Gemineye EC5605-WK Installation Instructions Manual

Ecco Gemineye EC5605-WK Installation Instructions Manual

Wireless camera/monitor system

Advertisement

!
WARNING!
Failure to install or use this product according to manufacturers recommendations may result in property
damage, serious bodily/personal injury, and/or death to you and those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the
safety information contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of vehicle camera systems
are essential to ensure the safety of you and those you are trying to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including fi re.
4. Proper placement and installation are vital to the performance of this device. Install this product so that output
performance of the system is maximized and the controls are placed within convenient reach of the operator so that
s/he can operate the system without losing eye contact with the roadway.
5. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use,
the vehicle operator should ensure the projection of the signal is not blocked by vehicle components (i.e., open
trunks or compartment doors), people, vehicles, or other obstructions.
Introduction:
The Gemineye™ wireless camera system features 2.4GHZ digital signal transmission and offers quality and functionality equal to
wired systems. Featuring a 5.6" LCD color monitor with touchscreen menu control and a CMOS infrared camera this system provides
exceptional and consistently stable picture quality. The system is expandable to operate up to four separate cameras, each with
independent trigger wires and all using a wireless signal to transmit image data to the monitor. This system dramatically reduces
installation complexity and expense while eliminating the potential for wires being damaged during operation of the vehicle.
!
WARNING!
1. High voltage is present within the monitor. The opening of the case should be by professionals.
2. Do not watch the video while driving unless you are monitoring the rear view camera display.
IMPORTANT!
Occasionally, a few highlights or dark spots may occur on the LCD screen. This is a very
common phenomenon in active matrix display technology, and doesn't necessarily indicate any defects or
faults. Never try to repair this device by yourself. In case of any problems, please turn off the display at once
and notify our company or authorized dealer. The monitor is a complex device. Any disassembly or modifi cation
may lead to damage and void the warranty.
920-5203-00 Rev. B

Installation Instructions

Wireless Camera/Monitor System
Page 1 of 12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Gemineye EC5605-WK and is the answer not in the manual?

Questions and answers

Summary of Contents for Ecco Gemineye EC5605-WK

  • Page 1: Installation Instructions

    Installation Instructions Wireless Camera/Monitor System WARNING! Failure to install or use this product according to manufacturers recommendations may result in property damage, serious bodily/personal injury, and/or death to you and those you are seeking to protect! Do not install and/or operate this safety product unless you have read and understand the safety information contained in this manual.
  • Page 2: Specifications

    Specifications: SYSTEM SPECIFICATIONS / FEATURES CAMERA SPECIFICATIONS / FEATURES 5.6” Digital TFT - LCE Color, Image Device 1/3” CMOS Product 2.4 GHz Wireless Ingress Protection IP69K Resolution 800 x 3 (RGB) x480 Night Vision 11 IR LEDS = MAX. 10M Distance Contrast 500:1 TV System...
  • Page 3: Maintenance

    Maintenance: 1. Remove all the cable connections from the monitor before cleaning the device. 2. Use a mild household detergent and clean the unit with a slightly damp, soft cloth. Never use strong solvents such as thinner or benzine, as they might damage the finish of the device. WARNING! To prevent accidental shock, DO NOT OPEN THE MONITOR CASE.
  • Page 4: Camera Installation

    Camera Installation: Important! Mount the camera at a location that provides the best view of the area immediately behind the vehicle. Generally, mounting locations toward the top of the vehicle provide the best field of view. Lower mounting locations reduce the field of view and increase the likelihood of damage from road spray.
  • Page 5 DC/12-24V Figure 3 Single red wire to positive power supply of DC/10-32V using a 3A fuse. Single black wire to GND. Single brown wire to positive power wire of back-up light. Single white wire to positive power wire of left light . Single blue wire to positive power wire of right light .
  • Page 6: Bracket Installation

    Reversing Display: CAM1 1. When the white wire is connected to the positive wire of the left turn light , the monitor automatically switches to CAM1 (left side camera) when the left turn indicator is activated. 2. When the blue wire is connected to the positive wire of the right turn light, the monitor automatically CAM2 switches to CAM2 (right side camera) when the right turn indicator is activated.
  • Page 7 Installation instruction of using base support 1. Select suitable position on vehicle and fix the base support. (Figure 7) 2. Fix the monitor to the base support and adjust the view angle. (Figure 8) 3. Connect the monitor with the AV and power supply conversion cable (Figure 9) Figure 7 Figure 8 Figure 9...
  • Page 8: Remote Control Operation

    Remote Control Operation: Mute Power Switch Horizontal Flip Vertical Flip Setting Selection Up More Brightness Less Brightness Menu Setting Selection Call Down Picture Mode Timer Select CAM1/CAM2/ Language Selection CAM3/CAM4 PAL/AUTO/NTSC Important! 1. Align the remote control with the infrared-receiving window on the monitor to operate. 2.
  • Page 9 Menu: Press MENU to display the following options and settings: Picture, Option, System, Auto Scan and Set up. 1. Picture: BRIGHT, CONTRAST, COLOR, VOLUME, AUTO DIM and SCALE ADJUST options will display on the screen as illustrated below: • Press CH- to select BRIGHT PICTURE BRIGHT CONTRAST...
  • Page 10 • Firstly press SEL to choose the channel to be paired, • Turn on the PAIRING function, the screen will secondly press CH- to select PAIRING. display “PAIRING START”. It counts down 50 seconds. OPTION LANG ENGLISH SCALE PAIRING PAIRING START CAM1 NORMAL CAM2...
  • Page 11: Troubleshooting

    5. Set Up: SOURCE-CAM1, SOURCE-CAM2, SOURCE-CAM3, SOURCE-CAM4 options will display on the screen as illustrated below : • Press to select SOURCE-CAM1 to SOURCE-CAM4 SET UP SET UP SOURCE-CAM1 SOURCE-CAM1 SOURCE-CAM2 SOURCE-CAM2 SOURCE-CAM3 SOURCE-CAM3 SOURCE-CAM4 SOURCE-CAM4 E.g. Press to select SOURCE-CAM4 and press - / + to select OFF. CAM4 Press - / + to select ON / OFF will be shut off.
  • Page 12: Exclusion Of Other Warranties

    Manufacturer Limited Warranty and Limitation of Liability: Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specifications for this product (which are available from the Manufacturer upon request), and Manufacturer further warrants that this product is free from defects in materials and workmanship. This Limited Warranty extends for 1 year/12 months from the date of purchase.
