- Page 1 QY-IMX6S-V1.2 Single Board Computer Hardware Manual Version NO.：V 1.2 2013.11 QIYANG INTELLIGENT TECHNOLOGY CO., LTD Copyright Reserved...
- Page 2 QY-IMX6S-V1.2 Single Board Computer Hardware Manual Version Update Version Hardware Description Date Revised person QY-IMX6S-V1.2 Launched 2013-12-06 :supports@qiyangtech.com Any question, please send E-mail Page 2 of 27 :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech Copyright...
-
Page 3: Table Of Contents
QY-IMX6S-V1.2 Single Board Computer Hardware Manual Catalogue I. Preface..................................4 1.1 Company Profile............................4 1.2 Suggestion for Using QY-IMX6S Single Board Computer................. 5 . System Composition............................6 Ⅱ 2.1 Chip Summary............................. 6 2.2 Mainboard Resource............................ 8 Ⅲ Interface Function..............................9 3.1 Basic Interface Function Description ...................... -
Page 4: Preface
QY-IMX6S-V1.2 Single Board Computer Hardware Manual Notice: This manul introduce the hardware interface of the mainboard. I. Preface 1.1 Company Profile Hangzhou Qiyang Intelligent Technology Co., Ltd. locates at the bank of the beautiful West Lake. It is a high and new technology enterprise which is specializing in R&D, manufacture and sell embedded computer main board with high... -
Page 5: Suggestion For Using Qy-Imx6S Single Board Computer
QY-IMX6S-V1.2 Single Board Computer Hardware Manual 1.2 Suggestion for Using QY-IMX6S Single Board Computer 1. Please read the instructions first, before using the single board computer; 2. Before using, please check the packing list and see whether there is a missing file in the CD;... -
Page 6: Ⅱ. System Composition
QY-IMX6S-V1.2 Single Board Computer Hardware Manual Ⅱ. System Composition 2.1 Chip Summary QY-IMX6S-V1 embedded mainboard, adopts Freescale i.MX6 processor, Cortex-A9 core with 1G Hz and can be compatible with solo/dual /quad micro processor for upgrade. This mainboard is with standard i.MX6 Dual series: The i.MX 6Dual family provides dual cores running up to 1.2 GHz with 1 MB of... - Page 7 QY-IMX6S-V1.2 Single Board Computer Hardware Manual picture 1 ◆ARM® Cortex™-A9,1.2GHz, compatible with solo/dual/quad core; ◆1MB L2 Cache,32 KB instruction and data caches, NEON SIMD Media Accelerator; ◆2D/3D/VG Accelerator,1080P h.264 video hardware codec,support dual 720P video encoding; ◆1x 20-bit parallel, MIPI-CSI2 (4-channel), three simultaneous inputs;...
-
Page 8: Mainboard Resource
QY-IMX6S-V1.2 Single Board Computer Hardware Manual 2.2 Mainboard Resource Freescale i.MX6D processor,ARM® Cortex™-A9 core,1.2GHz DDR3 SDRAM,4*256MB, total 1GB Flash 4GB EMMC Network AR8035 Network Chip, adopt RGMII mode, support 10M/100M/1000M 1 port (com0) as the debug UART, 5-ch RS232, 2-ch RS232 Compatible with... -
Page 9: Ⅲ Interface Function
QY-IMX6S-V1.2 Single Board Computer Hardware Manual Size 160mm*105mm 8-layer high precision immersion gold process Power ≤3W Consumption Operation -20℃ ~ +70℃ Temperature Operation 5% ~ 95%, Non-Condensing Humidity Ⅲ.Interface Function picture 2 3.1 Basic Interface Function Description Label Function Any question, please send E-mail :supports@qiyangtech.com... - Page 10 QY-IMX6S-V1.2 Single Board Computer Hardware Manual +12V Power supply input UART and CAN BOOT mode selection SPI and 2*4GPIO Debug port BOOT mode selection JTAG USB OTG 2-ch USB USB,can connect to external module Gigabit Ethernet SD Card HDMI LVDS1...
-
Page 11: Jumper Dial-Up Setting
QY-IMX6S-V1.2 Single Board Computer Hardware Manual RS485 and GPIO +5 Power supply output Audio output 3.2 Jumper Dial-up Setting Jumper setting:J4 and J7 jumper choose BOOT MODE BOOT MODE BOOT FROM FUSE SERIAL DOWNLOADER INTERNAL BOOT RESERVED NOTE：’0’ means off, ’1’ means jumper on Dial-up setting：SW1 dial-up switch choose BOOT DEVICE... - Page 12 QY-IMX6S-V1.2 Single Board Computer Hardware Manual UART4_RXD UART5_RXD UART4_TXD UART5_TXD +5.0V +5.0V CAN2_RXD J_CANH1 J5：SPI and 2*4 GPIO Signal Name Signal Name +3.3VD +3.3VD SPI5_MISO SPI5_MOSI SPI5_SCLK SPI5_CS0 SPI5_CS1 SPI5_CS2 GPIO2_0 GPIO2_1 GPIO2_2 GPIO2_3 GPIO2_4 GPIO2_5 GPIO2_6 GPIO2_7 Debug Port ：...
- Page 13 QY-IMX6S-V1.2 Single Board Computer Hardware Manual +3.3VD pull-up JTAG_TMS JTAG_TCK JTAG_TDO JTAG_TRSTn JTAG_TDI pull-down +3.3VD pull-up J10：USB OTG picture 3 picture 4 J11: Dual USB HOST: Top is USB1, Below is USB2 J12: USB2.0 Pin interface, can external USB module...
- Page 14 QY-IMX6S-V1.2 Single Board Computer Hardware Manual USBDN_DM4 +5.0VD J13: Standard 10M/100M/1000M RJ45 Ethernet port, integrated LAN transformer and network indicator picture 5 J14: Standard SD Card interface, support high-capacity SD Card storage picture 6 J15: Standard HDMI Any question, please send E-mail :supports@qiyangtech.com...
- Page 15 QY-IMX6S-V1.2 Single Board Computer Hardware Manual picture 7 Signal Name TMDS_DP2 TMDS_DM2 TMDS_DP1 TMDS_DM1 TMDS_DP0 TMDS_DM0 TMDS_CLKP TMDS_CLKN HDMI_CEC_OUT DDC_CLK DDC_DAT Any question, please send E-mail :supports@qiyangtech.com Page 15 of 27 :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech Copyright...
- Page 16 QY-IMX6S-V1.2 Single Board Computer Hardware Manual HDMI_5VOUT HP_DET J16：LVDS1 Signal Name Signal Name +3.3VD +3.3VD LVDS0_TXN0 LVDS0_TXP0 LVDS0_TXN1 LVDS0_TXP1 LVDS0_TXN2 LVDS0_TXP2 LVDS0_CLKN LVDS0_CLKP LVDS0_TXN3 LVDS0_TXP3 GPIO_1 GPIO_2 J17：LVDS2 Signal Name Signal Name +3.3VD +3.3VD LVDS1_TXN0 LVDS1_TXP0 LVDS1_TXN1 LVDS1_TXP1 LVDS1_TXN2 LVDS1_TXP2...
- Page 17 QY-IMX6S-V1.2 Single Board Computer Hardware Manual LVDS1_CLKP LVDS1_TXN3 LVDS1_TXP3 GPIO_3 GPIO_4 J18: LCD Power supply interface Signal Name +12VD +5.0VD +3.3VD J19：Capacitive touch panel interface Signal Name +3.3VD I2C3_SDA I2C3_SCL GPIO_18 GPIO_19 J21：TTL LCD Signal Name Signal Name Any question, please send E-mail :supports@qiyangtech.com...
- Page 18 QY-IMX6S-V1.2 Single Board Computer Hardware Manual DISP0_CLK DISP0_HS DISP0_VS DISP0_DAT18 DISP0_DAT19 DISP0_DAT20 DISP0_DAT21 DISP0_DAT22 DISP0_DAT23 DISP0_DAT10 DISP0_DAT11 DISP0_DAT12 DISP0_DAT13 DISP0_DAT14 DISP0_DAT15 DISP0_DAT2 DISP0_DAT3 DISP0_DAT4 DISP0_DAT5 DISP0_DAT6 DISP0_DAT7 DISP0_DE LCD_VDD LCD_VDD LCD_PWR LCD_MOD LCD_CC TSC_XP TSC_YP TSC_XM TSC_YM J22：Camera interface Signal Name...
- Page 19 QY-IMX6S-V1.2 Single Board Computer Hardware Manual +3.3VD I2C1_SCL I2C1_SDA CSI0_VS CSI0_HS CSI0_PCLK CSI0_DAT19 CSI0_DAT18 CSI0_DAT17 CSI0_DAT16 CSI0_DAT15 CSI0_DAT14 CSI0_DAT13 CSI0_DAT12 CSI0_DAT11 CSI0_PWDN CSI0_DAT10 J24：VGA Signal Name Signal Name VGA_HS VGA_VS BULE GREEN J25：MIC Any question, please send E-mail :supports@qiyangtech.com Page 19 of 27 :trade@qiyangtech.com sales@qiyangtech.com...
- Page 20 QY-IMX6S-V1.2 Single Board Computer Hardware Manual picture 8 Signal Name MIC_INP MIC_INM picture 9 J26：Audio PIN interface Signal Name LSPK1 LSPK2 RSPK1 RSPK2 Any question, please send E-mail :supports@qiyangtech.com Page 20 of 27 :trade@qiyangtech.com sales@qiyangtech.com Sales E-mail :http://www.qiytech.com Website ©2012 Qiyangtech...
- Page 21 QY-IMX6S-V1.2 Single Board Computer Hardware Manual J27：Standard SATA hard disk interface Signal Name SATA_TXP SATA_TXM SATA_RXM SATA_RXP J28:SATA hard disk power supply interface, 2.54 PIN with frame Signal Name +5.0VD +12.0VD J29：MINI_PCIE Signal Name Signal Name Reserved PCIE_3V3 Reserved Reserved...
- Page 22 QY-IMX6S-V1.2 Single Board Computer Hardware Manual CLK1_P UIM_RST UIM_VPP Reserved Reserved PCIE_DISEN PCIE_RSTN PCIE_RXM PCIE_3V3 PCIE_RXP PCIE_1V5 I2C2_SCL PCIE_TXM I2C2_SDA PCIE_TXP USBDN_DM3 Reserved USBDN_DP3 Reserved Reserved LED_WWAN Reserved LED_WLAN Reserved LED_WPAN Reserved PCIE_1V5 Reserved Reserved PCIE_3V3 Any question, please send E-mail :supports@qiyangtech.com...
- Page 23 QY-IMX6S-V1.2 Single Board Computer Hardware Manual picture 10 J30：SIM Card Signal Name Signal Name UIM_PWR UIM_RST UIM_VPP UIM_CLK UIM_DATA J31: 2*4GPIO interface 2-ch, 5-wire UART multiplex with 2-ch RS485 Signal Name Signal Name GPIO2_16 GPIO2-20 GPIO2-17 GPIO2-21 GPIO2-18 GPIO2-22 GPIO2-19...
- Page 24 QY-IMX6S-V1.2 Single Board Computer Hardware Manual J32:+5.0VD Power supply output, can supply to peripherals Signal Name +5.0VD J33:Audio output interface, PJ245 vertical 3.5mm board plug earphone socket Signal Name RSPK1 LSPK1 Any question, please send E-mail :supports@qiyangtech.com Page 24 of 27 :trade@qiyangtech.com sales@qiyangtech.com...
- Page 25 QY-IMX6S-V1.2 Single Board Computer Hardware Manual Ⅳ.Size & Structure Chart picture 11 Ⅴ. Remark 1. Before connect to LCD, confirm LCD power specification. 2. Please use the original connecting accessories, avoid damaging the main board. Any question, please send E-mail :supports@qiyangtech.com...
- Page 26 QY-IMX6S-V1.2 Single Board Computer Hardware Manual 3. We ensure offering communication technology support through E-mail, telephone for lifelong technical support service. 4. We ensure offering 6 months repair service for free, if malfunction occurs in warranty because of quality problem, contact our retailer or our company with purchase receipt in warranty period, we will repair or replace it.
- Page 27 QY-IMX6S-V1.2 Single Board Computer Hardware Manual Hangzhou Qiyang Intelligent Technology Co., Ltd Tel: 86-571-87858811 / 87858822 Fax: 86-571-89935912 Technology Support：86-571-89935913 E-MAIL: supports@qiyangtech.com Website: http://www.qiytech.com Address: 5F, Building 3A, NO.8 Xiyuanyi Road, West Lake Science Park, Hangzhou, China Post Code：310030 Any question, please send E-mail :supports@qiyangtech.com...
