GF-RK3399-Kit Embedded Development Board
Hardware Manual
Ver.:2.0
2021.08
Zhejiang Qiyang Intelligent Technology Co., Ltd
Copyright Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GF-RK3399-Kit and is the answer not in the manual?

Questions and answers

Related Manuals for Qiyang GF-RK3399-Kit

Summary of Contents for Qiyang GF-RK3399-Kit

  • Page 1 GF-RK3399-Kit Embedded Development Board Hardware Manual Ver.:2.0 2021.08 Zhejiang Qiyang Intelligent Technology Co., Ltd Copyright Reserved...
  • Page 2 GF-RK3399-Kit Embedded Development Hardware Manual Version Records Version Hardware Description Date Reviser GF-RK3399-MB-V1_00 Internal released 2020-04 wangwx GF-RK3399-MB-V2_01 Updated picture 2021-08 Any question, please send E-mail :supports@qiyangtech.com Page 2 of 38 :trade@qiyangtech.com; sales@qiyangtech.com Sales E-mail :http://www.qiytech.com http://www.qiyangtech.com Website ©2012 Qiyangtech...

  • Page 3: Table Of Contents

    Notice: This manual introduces the hardware interface of the development board........... 4 I. Preface ..................................4 1.1.Company Profile ............................4 1.2.Suggestion for Using GF-RK3399-KIT development board ............... 5 Ⅱ. Product Introduction ............................5 2.1.Chipset Introduction ............................ 5 2.2.Board Resources: ............................8 2.3.Core Board Resources ..........................

  • Page 4: Notice: This Manual Introduces The Hardware Interface Of The Development Board

    Control, Internet of Things, New Retail, Smart Medical, Electricity Device, Environmental Surveillance, Charging Pile etc. With the growth of the business, Qiyang has set up a SMT factory in Zhuji, Zhejiang province, which is 5000 ㎡, with a 2xSMT production lines. The SMT factory performs the ISO9001 Quality Management System strictly.

  • Page 5: Suggestion For Using Gf-Rk3399-Kit Development Board

    4. If you need to develop on Android system and burn program into the development board, in addition to this document, we also suggest reading another document GF-RK3399-KIT Android User Manual. 5. GF-RK3399-KIT development board supports batch order.
  • Page 6 GF-RK3399-Kit Embedded Development Hardware Manual Rockchip RK3399 Processor Architecture: Picture 1 Any question, please send E-mail :supports@qiyangtech.com Page 6 of 38 :trade@qiyangtech.com; sales@qiyangtech.com Sales E-mail :http://www.qiytech.com http://www.qiyangtech.com Website ©2012 Qiyangtech Copyrigh...
  • Page 7 GF-RK3399-Kit Embedded Development Hardware Manual ◆Big.Little architecture: Dual Cortex-A72 + Quad Cortex-A53, 64-bit CPU, with 1.8Ghz ◆Support Mali-T8640GPU, and OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11, and AFBC ◆Dual channel DDR3-1866/DDR3L-1866/LPDDR3-1866/LPDDR4, supports eMMC5.1, SDIO3.0 ◆Support 4K VP9 and 4K 10bits H265/H264 video decoding, 60fps,1080P multi-format video decoding (VC-1,MPEG-1/2/4, VP8), 1080P video encoding, it supports H.264, VP8, video...

  • Page 8: Board Resources

    GF-RK3399-Kit Embedded Development Hardware Manual 2.2.Board Resources: Model Rockchip RK3399 (28nm HKMG processing) ARM Hexa-core 64 bit processor, up to 1.8GHz Based on the big.LITTLE architecture, Dual Core Cortex-A72(Big Core)+Quad Core Cortex-A53(Little Core) ARM Mali-T860 MP4 Quad Core GPU Support OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11...

  • Page 9: Core Board Resources

    GF-RK3399-Kit Embedded Development Hardware Manual 2-ch Speaker out Voice 1-ch earphone output 1-ch MIC input Storage 1-ch TF card Expansion 1-ch I2C interface, 8-ch GPIO interface Others Reset, Watch Dog, RTC Power Supply +12V power input Development environment: virtual machine VM9.02+Ubuntu 14.04 or Ubuntu 16.04 system...
  • Page 10 GF-RK3399-Kit Embedded Development Hardware Manual CPU, LPDDR4, eMMC, power management chip, etc. It adopts Gold Finger (317Pins) Interface leads to function pins, which fully expanded the hardware resources of RK3399. And different interface functions can be multiplexed and combined according to the pin conditions to make a backplane that meets the requirements.

  • Page 11: Iii.base Board Interface Functions

    GF-RK3399-Kit Embedded Development Hardware Manual III. Base Board Interface Functions Base Board Block Diagram – Top Side Picture 3 Any question, please send E-mail :supports@qiyangtech.com Page 11 of 38 :trade@qiyangtech.com; sales@qiyangtech.com Sales E-mail :http://www.qiytech.com http://www.qiyangtech.com Website ©2012 Qiyangtech Copyrigh...
  • Page 12 GF-RK3399-Kit Embedded Development Hardware Manual Base Board Block Diagram – Bottom Side Picture 4 Any question, please send E-mail :supports@qiyangtech.com Page 12 of 38 :trade@qiyangtech.com; sales@qiyangtech.com Sales E-mail :http://www.qiytech.com http://www.qiyangtech.com Website ©2012 Qiyangtech Copyrigh...

  • Page 13: Interface Function's Introduction

    GF-RK3399-Kit Embedded Development Hardware Manual 3.1.Interface function’s Introduction Functions DC12V power input Gigabit Ethernet Gigabit Ethernet USB3.0 HOST Type-C HDMI TF Card Slot Earphone eDP display MIPI display 3.3V/5.0V jumper LCD backlight I2C interface (capacitive touch screen) LVDS 2-ch Speaker output...
  • Page 14 GF-RK3399-Kit Embedded Development Hardware Manual RS232 port(COM2) USB2.0 HOST USB2.0 HOST RS232 port(COM5) RS232 port(DEBUG) UART-TTL RS485 DC12V power input RTC battery(+3.0V), locate beneath the Core Board WIFI module, locate beneath the Core Board Camera, locate at the back side of Base Board...

  • Page 15: Pin Definition

    GF-RK3399-Kit Embedded Development Hardware Manual 3.2.Pin Definition J34- Pin Definition : MXM Connector J34A Pin # Signal name Description E1-1 VCC_SYS_5V0 E1-2 VCC_SYS_5V0 E1-3 VCC_SYS_5V0 E1-4 VCC_SYS_5V0 E1-5 VCC_SYS_5V0 5V power input (required) E1-6 VCC_SYS_5V0 E1-7 VCC_SYS_5V0 E1-8 VCC_SYS_5V0 E1-9...
  • Page 16 GF-RK3399-Kit Embedded Development Hardware Manual MAC_TXCLK GPIO3_C1 Ethernet signal MAC_RXDV GPIO3_B1 MAC_RXD0 GPIO3_A6 MAC_RXD1 GPIO3_A7 MAC_RXD2 GPIO3_A2 MAC_RXD3 GPIO3_A3 MAC_RXCLK GPIO3_B6 GPIO2_B4_u I2C2_SDA GPIO2_A0 I2C signal I2C2_SCL GPIO2_A1 GPIO2_A2_d GPIO2_A3_d GPIO signal GPIO2_A4_d GPIO2_A5_d GPIO2_A6_d I2C7_SDA GPIO2_A7 I2C6_SDA GPIO2_B1 I2C signal...
  • Page 17 GF-RK3399-Kit Embedded Development Hardware Manual VCCA SPI1_RXD GPIO1_A7 SPI1_TXD GPIO1_B0 SPI signal SPI1_CLK GPIO1_B1 SPI1_CSN0 GPIO1_B2 PCIE_RCLK_100M_P PCIE_RCLK_100M_N PCIE_TX0_N PCIE_TX0_P PCIE_RX0_N PCIE_RX0_P PCIe signal PCIE_TX1_N PCIE_TX1_P PCIE_RX1_N PCIE_RX1_P PCIE_TX2_N PCIE_TX2_P PCIE_RX2_N PCIE_RX2_P Any question, please send E-mail :supports@qiyangtech.com Page 17 of 38 :trade@qiyangtech.com;...
  • Page 18 GF-RK3399-Kit Embedded Development Hardware Manual PCIE_TX3_N PCIE_TX3_P PCIE_RX3_N PCIE_RX3_P J34C Pin # Signal name Description GPIO1_C2_u GPIO1_C4_u I2C4_SDA I2C signal I2C4_SCL PWR_EN Switch enable PWR_KEY Switch control GPIO1_D0_d GPIO0_A6_d GPIO0_B5_d MPU_RESET System reset GPIO0_A2_d GPIO0_B0_u GPIO signal GPIO0_A5_u GPIO2_D3_d HDMI_CEC...
  • Page 19 GF-RK3399-Kit Embedded Development Hardware Manual HDMI_I2C3_SCL HDMI GPIO4_C1 HDMI_I2C3_SDA GPIO4_C0 GPIO1_A2_d RTC_CLK_OUT GPIO0_A4_d GPIO2_D2_u UART0_RTSn GPIO2_C3 UART0_CTSn GPIO2_C2 UART 0 UART0_TXD GPIO2_C1 UART0_RXD GPIO2_C0 GPIO0_B1_d SDIO0_D1 GPIO2_C5 GPIO2_C4 SDIO0_D0 SDIO0_D2 GPIO2_C6 SDIO signal SDIO0_D3 GPIO2_C7 SDIO0_CLK GPIO2_D1 SDIO0_CMD GPIO2_D0 GPIO0_A3_d...
  • Page 20 GF-RK3399-Kit Embedded Development Hardware Manual GPIO4_D4_d GPIO4_D5_d UART2DBG_TXD UART 2 GPIO4_C4 UART2DBG_RXD GPIO4_C3 GPIO4_D3_d GPIO4_D0_u GPIO4_D1_d GPIO4_D2_d GPIO4_C6_d GPIO4_C2_d VCCA_CODEC_3V0 3.0V output VCCA_CODEC_3V0 VCCA_CODEC_1V8 1.8V output VCCA_CODEC_1V8 I2S0_SCLK GPIO3_D0 I2S0_LRCK_RX GPIO3_D1 I2S signal I2S0_LRCK_TX GPIO3_D2 I2S0_SDI0 GPIO3_D3 GPIO3_D4_d GPIO3_D4 GPIO3_D5_d...
  • Page 21 GF-RK3399-Kit Embedded Development Hardware Manual GPIO4_A5_d GPIO4_A6_d GPIO4_A7_d I2C1_SDA GPIO4_A1 I2C1_SCL GPIO4_A2 GPIO4_C5_d GPIO4_C5 J34D Pin# Signal Name Description E2-1 E2-2 E2-3 E2-4 E2-5 E2-6 E2-7 E2-8 E2-9 E4-2 VCC_SYS_3V3 E4-3 VCC_SYS_3V3 E4-4 VCC_SYS_3V3 E4-5 VCC_S3_3V3 E4-6 VCC_S3_3V3 E4-7 VCC_S3_3V3...
  • Page 22 GF-RK3399-Kit Embedded Development Hardware Manual E4-9 VCC_3V0 E4-10 VCC_3V0 VCC_1V8 VCC_1V8 VCC_RTC VCC_S3_1V8 EDP_AUXN EDP_AUXP EDP_TX0N EDP_TX0P EDP signal EDP_TX1N EDP_TX1P EDP_TX2N EDP_TX2P EDP_TX3N EDP_TX3P SPDIF_TX GPIO3_C0 GPIO0_B4_d SDMMC0_DET GPIO0_A7 Any question, please send E-mail :supports@qiyangtech.com Page 22 of 38 :trade@qiyangtech.com;...
  • Page 23 GF-RK3399-Kit Embedded Development Hardware Manual SDMMC0_D2 GPIO4_B2 SDMMC0_D3 GPIO4_B3 SDMMC signal SDMMC0_CMD GPIO4_B5 SDMMC0_CLK GPIO4_B4 SDMMC0_D0 GPIO4_B0 SDMMC0_D1 GPIO4_B1 GPIO1_A1_d GPIO1_A4_d GPIO1_A3_d GPIO1_A0_d TYPEC0_U2VBUSDET TYPEC1_U2VBUSDET GPIO1_C6_d GPIO1_C7_d GPIO2_D4_d ADC_IN4 ADC_IN3 AD signal ADC_IN0 ADC_IN1 ADC_IN2 HOST1_DN HOST1_DP USB-HOST signal HOST0_DN...
  • Page 24 GF-RK3399-Kit Embedded Development Hardware Manual TYPEC1_AUXP TYPEC1_AUXN TYPEC1_TX2N USB-Typec signal TYPEC1_TX2P TYPEC1_RX2P TYPEC1_RX2N TYPEC1_AUXP_PD_PU TYPEC1_AUXP_PU_PD J34F Pin # Signal Name Description TYPEC1_RX1N TYPEC1_RX1P TYPEC1_TX1P TYPEC1_TX1N TYPEC1_DP TYPEC1_DN TYPEC0_TX2N TYPEC0_TX2P TYPEC0_RX2P TYPEC0_RX2N USB-Typec signal TYPEC0_DN Any question, please send E-mail :supports@qiyangtech.com Page 24 of 38 :trade@qiyangtech.com;...
  • Page 25 GF-RK3399-Kit Embedded Development Hardware Manual TYPEC0_DP TYPEC0_TX1N TYPEC0_TX1P TYPEC0_RX1P TYPEC0_RX1N TYPEC0_AUXP TYPEC0_AUXN TYPEC0_AUXN_PU_P TYPEC0_AUXN_PU_P HDMI_TX2P HDMI_TX2N HDMI_TX1P HDMI_TX1N HDMI signal HDMI_TX0P HDMI_TX0N HDMI_TXCP HDMI_TXCN MIPI_TX0_D0P MIPI_TX0_D0N MIPI_TX0_D1P MIPI_TX0_D1N Any question, please send E-mail :supports@qiyangtech.com Page 25 of 38 :trade@qiyangtech.com; sales@qiyangtech.com Sales E-mail :http://www.qiytech.com...
  • Page 26 GF-RK3399-Kit Embedded Development Hardware Manual MIPI-TX signal MIPI_TX0_CLKP MIPI_TX0_CLKN MIPI_TX0_D2P MIPI_TX0_D2N MIPI_TX0_D3P MIPI_TX0_D3N MIPI_RX0_D0P MIPI_RX0_D0N MIPI_RX0_D1P MIPI_RX0_D1N MIPI-RX signal MIPI_RX0_CLKP MIPI_RX0_CLKN MIPI_RX0_D2P MIPI_RX0_D2N MIPI_RX0_D3P MIPI_RX0_D3N MIPI_TX1/RX1_D3P Any question, please send E-mail :supports@qiyangtech.com Page 26 of 38 :trade@qiyangtech.com; sales@qiyangtech.com Sales E-mail :http://www.qiytech.com...
  • Page 27 GF-RK3399-Kit Embedded Development Hardware Manual MIPI_TX1/RX1_D3N MIPI_TX1/RX1_D2P MIPI_TX1/RX1_D2N MIPI-RX//TX signal MIPI_TX1/RX1_CLKP MIPI_TX1/RX1_CLKN MIPI_TX1/RX1_D1P MIPI_TX1/RX1_D1N MIPI_TX1/RX1_D0P MIPI_TX1/RX1_D0N J35： DC12V power input Pin # Signal Name DV +12V J25：Camera Pin # Signal Name VCC-3V3 VCC-3V3 Any question, please send E-mail :supports@qiyangtech.com Page 27 of 38 :trade@qiyangtech.com;...
  • Page 28 GF-RK3399-Kit Embedded Development Hardware Manual MIPI_RX0_CLK_N MIPI_RX0_CLK_P MIPI_RX0_D0_N MIPI_RX0_D0_P MIPI_RX0_D1_N MIPI_RX0_D1_P MIPI_RX0_D2_N MIPI_RX0_D2_P MIPI_RX0_D3_N MIPI_RX0_D3_P MIPI_I2C_SDA MIPI_I2C_SCL MIPI_PWDN MIPI_nRST MIPI_PWR_EN J23：eDP display Signal Name Pin# Pin# Signal Name VCC_LCD（3.3V/5.0V） VCC_LCD（3.3V/5.0V） Any question, please send E-mail :supports@qiyangtech.com Page 28 of 38 :trade@qiyangtech.com;...
  • Page 29 GF-RK3399-Kit Embedded Development Hardware Manual EDP_TX0_N EDP_TX0_P EDP_TX1_N EDP_TX1_P EDP_TX2_N EDP_TX2_P EDP_TX3_N EDP_TX3_P EDP_LCD_AUX_N EDP_LCD_AUX_P EDP_LCD_PHD J19：3.3V/5.0V jumper Pin# Signal Name VCC_EXT_5V0 VCC_LCD VCC_IO_3V3 J20：LVDS Signal Name Pin# Pin# Signal Name LVDSA_TX0_N LVDSA_TX0_P LVDSA_TX1_N LVDSA_TX1_P LVDSA_TX2_N LVDSA_TX2_P LVDSA_CLK_N LVDSA_CLK_P LVDSA_TX3_N...
  • Page 30 GF-RK3399-Kit Embedded Development Hardware Manual LVDSB_CLK_N LVDSB_CLK_P LVDSB_TX3_N LVDSB_TX3_P PMW0_OUT LVDS_LCD_EN VCC_LCD（3.3V/5.0V） VCC_LCD（3.3V/5.0V） VCC_LCD（3.3V/5.0V） J21：I2C Pin# Signal Name VCC_IO_3V3 TP_nINT TP_nRST J22：Power Supply Pin# Signal Name VCC_LVDS_LED（12.0V） VCC_LVDS_LED（12.0V） BL_EN PWM1_Out J29：Speaker Any question, please send E-mail :supports@qiyangtech.com Page 30 of 38 :trade@qiyangtech.com;...
  • Page 31 GF-RK3399-Kit Embedded Development Hardware Manual Pin# Signal Name SPKPL SPKNL SPKPR SPKNR J27：MIC Pin# Signal Name AUD_MIC+ AUD_MIC- J31：GPIO Signal Name Pin# Pin# Signal Name VCC_IO_3V3 VCC_IO_3V3 GPIO_IN1_S GPIO_OUT1 GPIO_IN2_S GPIO_OUT2 GPIO_IN3_S GPIO_OUT3 GPIO_IN4_S GPIO_OUT4 J12/J13/J14/J15:USB-HOST Pin# Signal Name 5V0_USB1（5.0V）...
  • Page 32 GF-RK3399-Kit Embedded Development Hardware Manual J2/J3/J4/J5/J6/J7:RS232 Pin# Signal Name J8：UART-TTL Pin# Signal Name VCC_IO_3V3 UART_TXD UART_RXD J1：RS485 Pin# Signal Name RS485_B RS485_A Any question, please send E-mail :supports@qiyangtech.com Page 32 of 38 :trade@qiyangtech.com; sales@qiyangtech.com Sales E-mail :http://www.qiytech.com http://www.qiyangtech.com Website ©2012 Qiyangtech...

  • Page 33: Iv.size & Structure

    GF-RK3399-Kit Embedded Development Hardware Manual IV.Size & Structure Unit: mm, if needs the connector’s size, please email: suppots@qiyangtech.com 4.1.Core Board Size Picture 5 Any question, please send E-mail :supports@qiyangtech.com Page 33 of 38 :trade@qiyangtech.com; sales@qiyangtech.com Sales E-mail :http://www.qiytech.com http://www.qiyangtech.com Website ©2012 Qiyangtech...

  • Page 34: Base Board Size

    GF-RK3399-Kit Embedded Development Hardware Manual 4.2.Base Board Size Picture 6 Any question, please send E-mail :supports@qiyangtech.com Page 34 of 38 :trade@qiyangtech.com; sales@qiyangtech.com Sales E-mail :http://www.qiytech.com http://www.qiyangtech.com Website ©2012 Qiyangtech Copyrigh...

  • Page 35: V.connector Picture

    GF-RK3399-Kit Embedded Development Hardware Manual V.Connector Picture Pay attention to the direction of the Core Board: (refer to the picture below) Picture 7 Any question, please send E-mail :supports@qiyangtech.com Page 35 of 38 :trade@qiyangtech.com; sales@qiyangtech.com Sales E-mail :http://www.qiytech.com http://www.qiyangtech.com Website ©2012 Qiyangtech...
  • Page 36 GF-RK3399-Kit Embedded Development Hardware Manual VI.Electrical Specification Items Parameter Operation 0℃ ~ +60℃ Temperature Storage temperature 0℃ ~ +60℃ Working Humidity 5%-95%, non-condensation 82mm*63mm,8-layer high-precision gold Core Board Size immersion process 158mm*121mm,4-layer PCB high-precision gold Base Board Size immersion process Core Board ≤2W...

  • Page 37: Vii.software Description

    6. We reserve intellectual property for the software and hardware technical data of GF-RK3399-KIT. Users can only use them for teaching, testing, researching. Shall not be engaged in any commercial purpose. Shall not distribute them on the Internet. Shall not intercept, modify them to tamper copyright.
  • Page 38 GF-RK3399-Kit Embedded Development Hardware Manual Zhejiang Qiyang Intelligent Technology Co., Ltd Tel: 86-571-87858811 / 87858822 Fax: 86-571-89935912 Technical Support：0571-87858811 ext.805 E-MAIL：supports@qiyangtech.com Website： http://www.qiytech.com or http://www.qiyangtech.com ADD: 3rd Floor, Building A, WSCG Building, NO.6 Xiyuan 8th Road, Sandun Town, Xihu District, Hangzhou City, Zhejiang China Postal Code：310013...
