IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be
followed to reduce the risk of fire, electric shock, and/or injury to persons, including
the following:
1 Read all instructions and information in this instruction book and any other
literature included in this carton referring to this product before operating or using
this appliance.
2 Do not touch hot surfaces. Use handles or knobs.
3 To protect against fire, electric shock and personal injury do not immerse cord,
plugs or appliance in water or other liquid.
4 Close supervision is necessary when any appliance is used by or near children.
5 Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts, and before cleaning the appliance.
6 Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any way. Return appliance to the nearest
authorized service centre for examination, repair or adjustment.
7 The use of accessory attachments not recommended by the appliance manufacturer
may result in fire, electric shock or personal injury.
8 Do not use outdoors.
9 Do not let cord hang over edge of table or counter, or touch hot surfaces.
10 Do not place on or near a hot gas or electric burner, or in a heated oven.
11 Always turn appliance "OFF", then plug cord into the wall outlet. To disconnect,
turn switch to "OFF", then remove plug from wall outlet.
12 Do not use appliance for other than intended household use.
13 Use extreme caution when using hot steam.
SAVE THESE INSTRUCTIONS
CAUTION
This appliance is for household use. Any servicing, other than cleaning and user
maintenance, should be performed by an authorized service centre. Do not immerse
base in water. To reduce the risk of fire or electric shock, do not disassemble the base.
There are no user serviceable parts inside. Repair should be done by authorized service
personnel only.
1 Check voltage to be sure that the voltage indicated on the nameplate agrees with
your voltage.
2 Never use warm or hot water to fill the water tank. Use cold water only.
3 Keep your hands and the cord away from hot parts of the appliance during
operation.
4 Never clean with scouring powders or hard implements. Simply use a soft cloth
dampened with water.
5 To avoid your coffee maker scaling up, use purified or bottled water.
INSTRUCTIONS FOR THE POWER SUPPLY CORD
A A short power-supply cord is provided to reduce risks of getting tangled up or
tripping over a longer cord.
B Longer extension cords are available and may be used if care is exercised in their use.
C If a long extension cord is used:
1 the marked electrical rating of the extension cord should be at least as great as
the electrical rating of the appliance.
2 if the appliance is of the grounded type, the extension cord should be a
grounding type
3 the cable does not hang from the table to avoid the risk of getting caught up in it.
Espresso Italia PTY LTD
www.espressoitalia.com.au
Freecall 1300 660 976

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the coffee machine and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Saeco coffee machine

  • Page 1: Important Safeguards

    IMPORTANT SAFEGUARDS CAUTION When using electrical appliances, basic safety precautions should always be This appliance is for household use. Any servicing, other than cleaning and user followed to reduce the risk of fire, electric shock, and/or injury to persons, including maintenance, should be performed by an authorized service centre.
  • Page 2: General Information

    GENERAL INFORMATION TECHNICAL SPECIFICATIONS This coffee machine is ideal for preparing espresso coffee either with coffee beans • Voltage rating See rating plate on appliance or preground coffee and also features a device for dispensing steam and hot water. This elegantly styled machine is designed for household use only. It is not suitable •...
  • Page 3: Safety Rules

    SAFETY RULES - Do not use the power cord to carry or pull the coffee machine. N THE EVENT OF AN EMERGENCY Immediately unplug the appliance. AZARDS - The appliance must not be used by children or by individuals unacquainted with HE APPLIANCE MAY ONLY BE USED the operating instructions.
  • Page 4: Component Description

    COMPONENT DESCRIPTION Coffee bean container lid Coffee bean container Grind adjustment knob Cup heater plate Water tank lid Preground coffee Coffe container opening dispenser lid button Water tank Control panel Steam knob Cleaning Brew group key brush Service door ON/OFF switch Water hardness Preground Height and depth...
  • Page 5: Installation/Ventilate

    INSTALLATION / VENTILATE The messages displayed by the machine during operation are shown Important warning for using the “Aqua Prima Filter” can be found at on page 40. page 40. See rating plate Fill the coffee bean container The “Aqua Prima” fi lter can Fill the tank with fresh drin- Insert the plug into a sui- Move the ON/OFF switch to...
  • Page 6: Adjustments

    ADJUSTMENTS Adjustment may be made only while the coffee grinder is operating. Use coffee bean blends for espresso coffee makers. If you do not obtain the desired result, try using different coffee blends. Store coffee in a cool place, in a hermetically sealed container. You will note a change after dispensing 1 - 2 coffees.
  • Page 7: Dispensing Coffee / Hot Water

    DISPENSING COFFEE / HOT WATER Warning! Hot water and steam may cause burns! Direct the steam tube toward the drip tray. SELECT PRODUCT 1 SMALL COFFEE 2 SMALL COFFEES READY FOR USE Make sure that the ma- Position a warm coffee Press the button of the Twice for 2 coffees.
  • Page 8 STEAM / CAPPUCCINO Warning! Hot water and steam may cause burns! Direct the steam tube toward the drip tray. Fill a cup to 1/3 with cold Place a container beneath When only steam comes Position the cup containing Open the knob to release milk.
  • Page 9: Descaling

    You can use any commercially available non-toxic, non-harmful descaling product for coffee capacity. The machine must be on; it automatically controls the distribution of the descaling solution. machines. We recommend using a Saeco descaling agent. DESCALING MACHINE IS DESCALING READY FOR USE...
  • Page 10: Aqua Prima" Cartridge Filter

    It is possible to use the machine without fi lter, WATERFILTER Saeco suggests its use. If fi lter is not used, the machine must be descaled more frequently. Espresso Italia PTY LTD See “Programming”. Enable...
  • Page 11: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Do not dry the machine and/or its components in a microwave and/or Do not immerge the machine in water and do not place any of its conventional oven. components in a dishwasher. Turn the machine off. Wash the water tank. Remove the drip tray, em- Remove the dregs drawer, Unscrew and clean the...
  • Page 12: Programming Machine Functions

    PROGRAMMING MACHINE FUNCTIONS The user can change some machine operating parameters to suit his/her personal needs. ENERGY SAVING RINSING RINSING RINSING RINSING RINSING LANGUAGE LANGUAGE Press the “MENU” button Use the “∧” and “∨” Using the “OK” button you can Press ESC to exit without Use the “OK”...
  • Page 13 PROGRAMMING MACHINE FUNCTIONS This function allows you to change the display language. LANGUAGE LANGUAGE LANGUE WATER HARDNESS ENGLISH FRANCAIS You can choose among Italian, German, Portuguese, Spanish, English, French, Dutch, Polish and Swedish. The appliance is usually programmed on the language of the country in which it is sold.
  • Page 14 PROGRAMMING MACHINE FUNCTIONS CUP HEATER CUP HEATER CUP HEATER TEMPERATURE This function allows you to turn on the cup heater present in the machine cover. When the function ap- Choose whether you wish Press the “OK” button to pears, select it using the to turn the cup heater plate confi...
  • Page 15 PROGRAMMING MACHINE FUNCTIONS AROMA COFFEE AROMA COFFEE AROMA COFFEE NORMAL STRONG AROMA LARGE COFFEE For setting, when the machine is switched on, the quantity of coffee to be ground in order to brew the coffee. When the function ap- Select the desired quantity Press the “OK”...
  • Page 16 PROGRAMMING MACHINE FUNCTIONS TOTAL COFFEES TOTAL COFFEES TOTAL COFFEES TIMER This function enables the user to see how many coffees the machine has already dispensed. When the function ap- The display will show the Press “ESC” to exit the pears, select it using the number of coffees the menu.
  • Page 17 PROGRAMMING MACHINE FUNCTIONS This function may be activated and deactivated by the CLOCK CLOCK TIME CLOCK TIME user to: RINSING CYCLE ON/OFF TIME 0:00 - display the current time when the machine is in the “ENERGY SAVING” or “SELECT PRODUCT” mode - program the machine to switch on and off at a specifi...
  • Page 18 PROGRAMMING MACHINE FUNCTIONS FACTORY SETTINGS FACTORY SETTINGS FACTORY SETTINGS ENERGY SAVING With this function you can restore the machine operating parameters originally set by the manufacturer. If you restore all the factory settings, all customized settings will be lost. When the function ap- Choose whether to restore Press the “OK”...
  • Page 19 Fit the brew unit properly in place. BREWUNIT MISSING “Aqua prima” fi lter; 4 If the coffee machine is not used for more than 20 days, it is advisable to Fit the drip tray and dregs drawer properly in place. replace the fi lter.
  • Page 20: Problems - Causes - Remedies

    PROBLEMS - CAUSES - REMEDIES PROBLEMS CAUSES REMEDIES PROBLEMS CAUSES REMEDIES The machine does not machine Move the main switch to ON. Coffee fl ows out in Excessively fi ne grind Adjust to a coarser grind (turn turn on. connected to the power slow trickle or not the knob clockwise).
