Kia Sorento User's Manual & Installation Instructions

Instruction Symbols / Defi nitions
Denotes warnings that may lead to
!
serious physical injury or vehicle
damage.
Denotes cautions to be taken to avoid
physical injury or electronic component
damage.
Denotes cautions to be taken to avoid
vehicle and component damage.
Basic Required Hand Tools
1/4" Drive 10 mm
1/4" Drive Rachet Socket
Phillips
Screwdriver
Pliers
Trim Tool Wire Cutter
Center Fascia
1/4" Drive Torque
Removal Tool
Wrench
P/N: 09840-1E100
KIA Genuine Accessories
Vehicle Model Sorento (Push Button)
Model Year 2011~
KMA Part No. U8560 1U010
Note: Diffi culty stated above refl ects the minimum level of expertise required to install the accessory
( A ) Customer
Ensure vehicle is equipped with automatic transmission, power door locks
and power windows. If the vehicle is not equipped with these options, do
not proceed. Ensure vehicle DOES have SMART KEY.
Denotes quality processes to be
checked prior to moving to the
next step.
Denotes specifi c tools that are neces-
sary to complete the step.
N
O Denotes instructional steps
necessary to complete the
T
process.
E
1/4" Drive 3/8"
Deep Socket
1/4" Drive 6"
Extension
Alcohol Cleaner
Flat Screwdriver
Technical Support
For Authorized Dealers - (800) 667-5176
Hours: 9:00 a.m. - 6:00 p.m. EST Monday - Friday
9:00 a.m. - 3:00 p.m. EST Saturday
Revision Date
3/9/2012
Accessory
Diffi culty
( B ) Dealer Technician
Denotes safety equipment required to be used
such as a mask, goggles, rubber
gloves, and hearing protection.
Notes to the Installer:
Read the entire installation manual prior to beginning the
installation of the accessory.
Factory wire harness colors are subject to change, please use
the specifi ed pin # in the harness connector to identify the cor-
rect wire for T-Tap installation.
Ensure that the vehicle is properly protected in the area that
the accessory is to be installed.
To prevent vehicle damage, never place tools on top of painted
surfaces, seats, dash pad, console or fl oor carpet / mat.
Always wear appropriate safety gear to include gloves and eye
protection when required.
Prior to disconnecting the negative lead to the battery, note the
AM/FM and satellite set frequencies on the inspection page, if
applicable.
To prevent stress on the remote start wire harness, ensure the
tilt/telescopic steering column is fully extended, if equipped.
Ensure the transportation fuse is properly installed before
performing the function check on page 17.
Remote Engine Start
( B )
( C ) Master Technician
Mask Googles
Rubber Gloves Hearing Protection
P/N: 4280402, Rev. A
Page 1 of 27
