WIRING AND HOOKUP INSTRUCTIONS

LED Descriptions

Proper wiring and performance can be verified by
checking the operation of the LED's located on the
circuit board.
LED #1: STATUS
Blinks to indicate that the system is functioning properly
LED #2: OPEN
Lit when the gate is in the fully open position and open
limit switch is depressed
LED #3: CLOSED
Lit when the gate is in the fully closed position and
closed limit switch is depressed
LED #4: MOTION
Blinks when gate is in motion
LED #5: OBSTRUCT
Blinks when gate has encountered an obstruction
LED #6: TIMER ON
Blinks when auto timer feature is enabled and gate is in
open position
LED #7: COMMAND
Lit when a command is received from an input device
(push button, transmitter, etc.)
LED #8: EXIT
Lit when an exit loop contact is made
LED #9: SAFETY
Lit when a safety loop contact is made
LED #10: BATT OK
Lit when battery is OK or charged
LED #11: CHARGING
Lit when battery is charging
LED #12: AC POWER
Lit when AC power is connected
