Quick Start Guide

Quick Start Guide
To quickly start watching satellite TV:
Apply power to the TracVision 12V receiver.
2 1
2
2 Turn on your TV and select the satellite input (not VCR input) .
Wait 30-60 seconds for the antenna to acquire the satellite TV signal.
3
The TV shows the following messages:
Message 1
If your satellite dish is ready for DIRECTV
service, please wait until your
Advanced Program Guide ™ is prepared.
Installation
Signal not available...
If Message 1 does not appear after 30 seconds,
2 4
press the remote control's SAT button.* Then
press the remote's PWR button. The receiver
beeps twice and its Antenna light flashes green.
If Message 2 does not appear after Message 1, ensure the antenna
4 5
has a clear view of the satellite. The antenna requires an unobstructed
view of the southern sky to receive satellite TV signals.
* If the SAT button does not illuminate red, replace the batteries in the remote control.
** If your receiver is not activated, you will only be able to access the DIRECTV
Refer to the red Activation Card for details on activating the receiver for DIRECTV service.
Once the antenna finds the satellite, and the receiver downloads the
KVH Industries, Inc.
Program Guide, you can start watching TV!**
50 Enterprise Center • Middletown, RI 02842-5279 U.S.A.
Phone: 401.847.3327 • Fax: 401.849.0045
E-mail: info@kvh.com • Internet: www.kvh.com • © 2006 KVH Industries, Inc., All rights reserved.
Message 2
® If your satellite dish is ready for DIRECTV
service, please wait until your
Advanced Program Guide ™ is prepared.
then
Installation
Acquiring guide data...
DVD VCR
MENU
® Preview Channel (100).

Changing channels:

To change channels, select
Press the CHANNEL(CH) button to tune to the
A
next or previous channel.
Use the numeric keypad to enter the channel number.
B
Press the GUIDE button to bring up the Program
C
Guide. Once you're in the Program Guide, use the
®
joystick or CHANNEL(CH) button to scroll through
the list, and press the SELECT button to tune to a
channel.
PWR
AUX TV SAT
GUIDE
FAV
TURBO
Viewing a program description:
To view a description of the currently selected program,
press the INFO button.

Troubleshooting:

Please see the reverse side of this guide.
www.tracvision.com
A , B or C :
Program Guide
ÐÐ
PWR
DVD VCR AUX TV SAT
C
GUIDE
MENU FAV
TURBO
INFO CLEAR
C
VOL CH P
A
A
G
E
PREV
MUTE
CH
DIRECTOR
PROG VIDEO
AUDIO
SEARCH
1 2 3
4 5 6
B
7 8 9
0
INPUT
PLAY
REW FF
STOP
REC PAUSE
PWR
DVD VCR AUX TV SAT
GUIDE
MENU FAV
TURBO
INFO CLEAR
®
®
