PC1575 System Introduction

1.1 Specifications

Control Panel Specifications
PC1575 (standard option): one low current PGM output
and one low current PGM output/input.
PC1575 (2-wire smoke option): one low current PGM
output and one high current PGM output/input.
Flexible Zone Configuration:
• Six fully programmable zones
• Seven Access Codes: five User, one Master and a
second Master code
• Normally Closed, Single EOL, Double EOL
• 2-wire Smoke Zone or Auxiliary Zone
• 21 Zone Types, 6 Programmable Zone Options
Audible Alarm Output:
• Supervised Bell Output (current limited at 3 amps), 12V
• Steady or Pulsed Output
EEPROM Memory:
• Does not lose programming or system status on
complete AC and Battery failure
Programmable Outputs:
• One programmable voltage output and one
programmable voltage output/input; 30 programmable
options
• PC1575 (standard option):
PGM1 = one low current (50mA) PGM output
PGM2 = one low current (50mA) PGM output/input.
• PC1575 (2-wire smoke option):
PGM1 = one low current (50mA) PGM output
PGM2 = one high current (300mA) PGM output/input
with 2-wire smoke detector capability
Please read
Appendix D "PGM Output Options"
carefully for important information.
Powerful 1 Amp Regulated Power Supply:
• 550 mA Auxiliary Supply, 12 V
• Positive Temperature Coefficient (PTC) components
replace fuses
• Supervision for loss of AC Power, Low Battery
• Internal Clock Locked to AC Power Frequency
Power Requirements:
• Transformer = 16.5 V
• Battery = 12 volt 4 Ah minimum rechargeable sealed
lead acid
Remote Keypad Specifications:
• Three Different Keypads Available:
- PC5506 six zone LED keypad
- LCD5500 Alphanumeric keypad
- PC1575RK six zone LED keypad
- SL-75 six zone LED keypad
• The PC5506 and LCD5500 keypads have 5 Fully
Programmable Function Keys
• Connect up to 8 Keypads
• Four Wire (Quad) Connection to KEYBUS
• Built in Piezoelectric Buzzer
S
E
DC
, 40VA
AC
C
T
I
O
Digital Communicator Specifications:
• Supports Major Formats including SIA and Contact ID
• Event Initiated Personal Paging
• Three Programmable Phone Numbers
• Two Account numbers
• Supports LINKS 1000 Cellular Communication
• DTMF and Pulse Dialing
• DPDT Line Seizure
• Anti-jam Feature
• Split Reporting of Selected Transmissions to Each
Telephone Number
System Supervision Features:
The PC1575 continuously monitors a number of possible
trouble conditions including:
• AC Power Failure
DC
• Trouble by Zone
• Tamper by Zone
• Fire Trouble
• Telephone Line Trouble
• Failure to Communicate
• Low Battery Condition
• Bell Output Trouble
• Module Fault (Supervisory or Loss of Internal Clock
AUX Power Supply Fault Tamper)
False Alarm Prevention Features:
• Audible Exit Delay
• Audible Exit Fault
• Communication Delay
• Urgency on Entry Delay
• Quick Exit
Additional Features:
• Auto Arm at Specified Time
• Keypad Activated Alarm Output and Communicator
Test
• All modules connect to the system via a four wire
KEYBUS up to 1000'/300m from main panel
• Event Buffer can be printed using PC5400 RS232 Serial
Interface module
• Supports the ESCORT 5580 Voice Prompt Module with
Automation/Lighting Control
• An Event Buffer which records the past 100 events with
both the time and date at which they occurred
• Uploading and Downloading capability
• Local Downloading capability through the use of the
PC-LINK Adaptor
UL Installation
This equipment is UL Listed in accordance with UL1023
(Household Burglar Alarm System Units), UL985 (Household
Fire Warning System Units), UL1635 (Digital Alarm Annunciator
System Units), UL365 (Police Station Connected Burglar
Alarm Units and Systems), UL609 (Local Burglar Alarm Units
and Systems), UL1610 (Central Station Burglar Alarm Units).
This equipment has the capability of being programmed for
operational features that are not allowed for UL Listed Systems
or being connected to accessories not permitted.
Appendix E for summary of requirements.
Appendix E for summary of requirements.
Appendix E for summary of requirements.
Appendix E for summary of requirements.
Appendix E for summary of requirements.
1
N
1
Refer to
Refer to
Refer to
Refer to
Refer to
