D
B
ual
rite
Sensing Diecast
Lantern
SL-4290 Series
Meets the ENERGY STAR
guidelines when D
function is off.
Questions or problems? Before returning
to your retailer, refer to the troubleshooting
guide in this manual or call our technical ser-
vice department at 1-800-858-8501 (English
speaking only), 7:30 am to 4:30 pm, CST,
Monday – Friday.
Features
• Light comes on when motion is detected.
• Automatically turns light off.
• Dusk Accent lighting.
• Photocell keeps the light off during daylight
hours.
Package Contents
• Lantern
• Universal Mounting Bracket
• Mounting Screws (Includes extra long screw
studs for recessed junction box mounting)
• Wire Connectors
Requirements
• The light control requires 120 volts AC.
• If you want to use Manual Mode, the control
must be wired through a switch.
• Some electrical codes require installa-
tion by a qualified electrician.
© 2010 HeathCo LLC
Motion
®
ual
Mode:
Test
Auto
Manual
Accent
* resets to Auto Mode at dawn.
Note: When first turned on wait about 1
minutes for the circuitry to calibrate.
®
Set the ON-TIME switch
B
®
rite
on the bottom of the cover
plate to TEST.
Set ON-TIME switch to
1, 5, or 10 minutes.
Manual mode only works at
night because daylight re-
turns the sensor to AUTO.
Flip the light switch off for
one second then back on to
toggle between AUTO and
MANUAL MODE.
Manual mode works only with
the ON-TIME switch in the 1,
5, or 10 position.
Before installation, record the model
number from back of fixture below.
Attach receipt in case of possible war-
ranty issues.
OPERATION
On-Time
Works: Day Night
5 Seconds
1, 5, or 10 Min
To Dawn*
3,6 Hr. to Dawn
TEST
TEST 1 5 10 MIN
AUTO
TEST 1 5 10 MIN
MANUAL MODE
x
x
x
x
x
/
1
2
ON-TIME
ON-TIME
1 Second
OFF then...
... back on.
598-1277-03
