Jobsite LSS-10 Installation & User Manual

10" & 12" powered subwoofers for powerful bass in home theater or music systems.
Hide thumbs

Advertisement

INSTALLATION & USER GUIDE
For Powerful Bass in Home
Theater or Music Systems
LSS-10 LSS-12
10" & 12" POWERED SUBWOOFERS
DS00490ACN-0 LSS-10_12.indd
1
5/23/06
2:12:53 PM

Advertisement

COMING SOON

   Also See for Jobsite LSS-10

   Related Manuals for Jobsite LSS-10

   Summary of Contents for Jobsite LSS-10

  • Page 1

    INSTALLATION & USER GUIDE For Powerful Bass in Home Theater or Music Systems LSS-10 LSS-12 10" & 12" POWERED SUBWOOFERS DS00490ACN-0 LSS-10_12.indd 5/23/06 2:12:53 PM...

  • Page 2: Table Of Contents

    LSS-10 LSS-12 10" & 12" POWERED SUBWOOFERS TABLE OF CONTENTS Important Safety Instructions ...1 Installation ...2 Controls and Connectors ...4 Finishing the Installation ...5 Applications ...7 Specifications ...10 FCC Instructions to the User ...10 Warranty ...11 Notes ...12 DS00490ACN-0 LSS-10_12.indd...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS CAUTION TO REDUCE THE CAUTION: RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE P A R T S I N S I D E . R E F E R SERVICING QUALIFIED SERVICE PERSONNEL. 1.

  • Page 4: Installation

    INSTALLATION Signal Connectors and Power Controls The LSS-10 and LSS-12’s signal connectors and power controls are located on the unit’s rear panel, as shown in Figure 1. They function as follows: NOTE: See Applications starting on page 7 for detailed wiring connections for your application.

  • Page 5

    AUDIO OUT jacks: Use these gold-plated, line-level RCA output jacks to connect line-level stereo or LFE audio signals to drive another LSS-10 or LSS-12 or loop your line level audio signal back to your surround sound processor or receiver. (The L/R output signals are routed through a fixed HIGH-PASS (80 Hz) filter).

  • Page 6: Controls And Connectors

    CONTROLS AND CONNECTORS Operation Controls The LSS-10 and LSS-12’s operation controls are located on the unit’s front panel, as shown in Figure 2. They function as follows: Figure 2. The LSS-10 and LSS-12’s front panel contains the subwoofer’s operation controls.

  • Page 7: Finishing The Installation

    FINISHING THE INSTALLATION Adjusting the Feet The LSS-10 and LSS-12 are equipped with four adjustable spiked feet, pre-installed with large, slip-on rubber covers. At the final placement location, adjust the feet/spikes as follows: On hard floors (e.g., wood, tile, etc.), ■...

  • Page 8

    To remove the grille, start with the bottom ■ grille posts and gently pull the grille frame away from the LSS-10 and LSS-12’s edge at each of the five recessed holes. Store the grille in a safe place for future use.

  • Page 9: Applications

    APPLICATIONS The JobSite LSS-10 and LSS-12 Subwoofers are very flexible and can be configured for use in various applications with associated external audio components, as shown in Figure 3 through 5. For other LSS-10 and LSS-12 applications, consult your local JobSite dealer for help in configuring your home theater system.

  • Page 10

    Two LSS-10 and LSS-12’s with Satellite Loudspeaker System NOTE: ADJUST SETTING ON BOTH LSS-10 AND LSS-12 SUBWOOFER TO BE THE SAME Speaker left out Trigger output LSS-12 Back DS00490ACN-0 LSS-10_12.indd Subwoofer line input LSS-12 Back Figure 4. Stereo/dual subwoofer application...

  • Page 11

    LSS-10 and LSS-12 and Speaker-Level Connection to Satellite Loudspeakers LSS-12 Back - LSS-10 similar Figure 5. DS00490ACN-0 LSS-10_12.indd DO not use these ports when using the SPEAKER ports Speaker level inputs JobSite A45-X2 Left satellite speaker Speaker level connections Right satellite...

  • Page 12: Specifications, Fcc Instructions To The User

    Power Requirements LSS-10 and LSS-12: 120 Vac; 230-240 Vac, 50/60Hz Overall Dimensions (with grille) LSS-10: 14.25" W x 15.25" H x 17.25" D LSS-12: 14.25" W x 19" H x 19" D Weight LSS-10: 47 lbs, (21.3 kg) shipping weight...

  • Page 13: Warranty

    LIMITED WARRANTY JobSite Systems (“JOBSITE”), a Niles Audio Corporation company, warrants its passive products (those not requiring AC or battery power) to the original purchaser to be free of manufacturing defects in material and workmanship for a period of ten years from date of purchase.

  • Page 14: Notes

    NOTES: DS00490ACN-0 LSS-10_12.indd 5/23/06 2:13:34 PM...

  • Page 15

    NOTES: DS00490ACN-0 LSS-10_12.indd 5/23/06 2:13:35 PM...

  • Page 16

    ©2006 JobSite Systems. All rights reserved. JobSite, Pure Custom and Niles are registered trademarks of Niles Audio Corporation and the JobSite Logo is a trademark of Niles Audio Corporation. All other trademarks are the property of their respective owners. Some JobSite prod- ucts (or components thereof) are manufactured under one or more U.S.
