3. Nomenclature

• Global Model Name
3.1 Indoor unit s
A T N H 1 8
3.2 Decoration panel(For ceiling cassette models)
P T - H E A
3.3 Outdoor units
A U U H 1 8
Copyright ©2008 LG Electronics. Inc. All right reserved.
Only for training and service purposes
6 E L C A
6 A
- 8 -
Serial Number
Functions
A : Basic C : Plasma Air Purifier
Look : Basic
Chassis Name
Electrical Ratings
6:1 Ø ,220V-240V,50Hz
G: 1Ø 220V~240V, 50/60Hz
Capacity code
Model Type
C: Cooling Only H: Heat Pump
R410A Universal Indoor Unit
ATN : Universal Ceiling Cassette Type Indoor Unit
ABN : Universal Ceiling Concealed Duct Type Indoor Unit
AVN : Universal Ceiling & Floor Type Indoor Unit
Functions
A: Basic C:For Indoor Unit with Plasma Air Purifier.
Indoor Unit Chassis
Model Type
C : Cooling Only H : Heat Pump
Decoration Panel of Ceiling Cassette Type Indoor Unit
Serial Number
Electric Standard (Phase, Volts, Freq)
6:1 Ø ,220V-240V,50Hz
Capacity code
Model Type
C : Cooling Only H : Heat Pump
R410A Universal Outdoor Unit
E: Elevation grille
8:3 Ø,380V-415V,50Hz
U: Universal
8:3 Ø ,380V-415V,50Hz
W: Inverter Heat Pump
