Samsung T220HD Service Manual page 50

Level Location No.
....4 RA204 2011-000881
....4 RA205 2011-000881
....4 RA206 2011-000881
....4 RA207 2011-000881
....4 RA300 2011-001262
....4 RA301 2011-001262
....4 RA302 2011-001262
....4 RA303 2011-001262
....4 RA304 2011-001262
....4 C702 2203-000041
....4 C708 2203-000125
....4 C753 2203-000125
....4 C754 2203-000125
....4 C755 2203-000125
....4 C756 2203-000125
....4 C105 2203-000189
....4 C109 2203-000189
....4 C111 2203-000189
....4 C119 2203-000189
....4 C130 2203-000189
....4 C132 2203-000189
....4 C133 2203-000189
....4 C138 2203-000189
....4 C162 2203-000189
....4 C163 2203-000189
....4 C164 2203-000189
....4 C165 2203-000189
....4 C166 2203-000189
....4 C167 2203-000189
....4 C168 2203-000189
....4 C169 2203-000189
....4 C170 2203-000189
....4 C171 2203-000189
....4 C172 2203-000189
....4 C173 2203-000189
....4 C174 2203-000189
....4 C176 2203-000189
....4 C177 2203-000189
....4 C183 2203-000189
....4 C184 2203-000189
....4 C185 2203-000189
....4 C188 2203-000189
....4 C189 2203-000189
....4 C190 2203-000189
....4 C191 2203-000189
....4 C192 2203-000189
....4 C193 2203-000189
....4 C194 2203-000189
....4 C195 2203-000189
....4 C196 2203-000189
....4 C200 2203-000189
Code No.
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3.
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3.
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3.
R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,3.
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2.
C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,-
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608
Description & Specification
5. Exploded View & Part List
Q'ty SA/SNA Remark
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.N.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
5-15
