Samsung T220HD Service Manual page 57

5. Exploded View & Part List
Level Location No.
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 T0568
....4 M0106
....4 T0077
...3 T0073
...3 T0066
...3 CN330
...3 JA333
...3 JA333
..2 M0251
..2 M0006
...3 T0073
...3 M0131
...3
...3
...3 M0114
...3
...3 M0107
...3
..2 T0562
..2 CCMM1
..2 CCMM1
..2 M0081
..2 M0081
0.1 M0045
..2 M0125
..2 M0254
...3 T0268
...3 T0524
...3
...3
...3 M0215
....4
....4
...3 T0128
...3
...3 M9889
5-22
Code No.
3301-001526 BEAD-SMD;10ohm,1.6x0.8x0.8mm,1000mA,TP,,
3301-001526 BEAD-SMD;10ohm,1.6x0.8x0.8mm,1000mA,TP,,
3301-001526 BEAD-SMD;10ohm,1.6x0.8x0.8mm,1000mA,TP,,
3301-001526 BEAD-SMD;10ohm,1.6x0.8x0.8mm,1000mA,TP,,
3301-001526 BEAD-SMD;10ohm,1.6x0.8x0.8mm,1000mA,TP,,
3301-001526 BEAD-SMD;10ohm,1.6x0.8x0.8mm,1000mA,TP,,
3301-001560 BEAD-SMD;80ohm,1.6X0.8X0.8mm,200mA,TP,,,
3301-001560 BEAD-SMD;80ohm,1.6X0.8X0.8mm,200mA,TP,,,
3301-001560 BEAD-SMD;80ohm,1.6X0.8X0.8mm,200mA,TP,,,
3301-001560 BEAD-SMD;80ohm,1.6X0.8X0.8mm,200mA,TP,,,
3301-001560 BEAD-SMD;80ohm,1.6X0.8X0.8mm,200mA,TP,,,
3301-001560 BEAD-SMD;80ohm,1.6X0.8X0.8mm,200mA,TP,,,
3301-001560 BEAD-SMD;80ohm,1.6X0.8X0.8mm,200mA,TP,,,
3301-001560 BEAD-SMD;80ohm,1.6X0.8X0.8mm,200mA,TP,,,
3708-001150 CONNECTOR-FPC/FFC/PIC;30P,1mm,SMD-A,SN,Y
BN41-01010B PCB MAIN;T-MFM,FR-4,4L,PCB1.1,1.6T,T200H
AA63-00929A GASKET-EMI;PS37S4A,Conductive Fabric,1.0
BP62-00047A HEAT SINK-ES;DLP,A6063S,T2.5,13,13,TAPE
3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN
3722-001903 JACK-PIN;2P,AU,WHT/RED,STRAIGHT
3722-001938 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT
BN96-07252D ASSY CABLE P;T-MFM,FFC,FC643130118012,70
BN96-08149B ASSY SHIELD P-COVER;LS22TD(MFM),USA_KOR,
BH63-00008A GASKET-EMI;IB10LO,CONDUCTIVE FABRIC,3MM,
BH63-00104A GASKET;POSEIDON,CONDUCTIVE FABRIC,2MM,10
BN61-02429D STUD-PEM;PNB,M2.8,D7,L20,ZPC(SIL),SUM24L
BN61-02429F STUD-PEM;PNB,M2.8,D7,L28,ZPC(SIL),SUM24L
BN61-02500A HOLDER-WIRE;NYLON6.6,NATURAL
BN61-03913A BRACKET-STAND FRAME;T(22W MFM),SECC,T 1.
BN63-04406B SHIELD-COVER;T220HD,SECC,T 0.8
BN61-03594A SPRING ETC-STAND;Mckinley,SUS304,T0.3,SI
6046-001014 STAND OFF;#4-40,L6,NI PLT,C3601,-
BN73-00192A SILICON/RUBBER;T-MFM,GAPPAD1500,20X20X8
BN73-00197A SILICON/RUBBER;T-MFM,SILICON,13X13X5
6003-001023 SCREW-TAPTITE;PWH,+,-,B,M3,L10,ZPC(WHT),
6003-001023 SCREW-TAPTITE;PWH,+,-,B,M3,L10,ZPC(WHT),
BN92-03411A ASSY ACCESSORY;LS22TDNSUV/ZA
BN39-00246K CBF SIGNAL-DVI(D);DVI-Cable,24P/24P,2027
ASSY ACCESSORY-CABLE&MANUAL;LS22TDDSUV/
BN96-07540A
3903-000085 CBF-POWER CORD;DT,US,BP3/YES,I(IEC C13/C
6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,-,9
BH68-00261F MARK RECYCLE-CARD WARRANTY-05;SyncMaster
BH68-00344C MARK RECYCLE-03,WARRANTY CARD;SECA W'TY
BN96-07406A ASSY MANUAL P-IB+QSG;T22M,NA,BN59-00720A
BN59-00720A S/W DRIVER-04,IB;T22M,Syncmaster,NA
BN68-01509A MANUAL FLYER-01,QSG;T22M,SyncMaster,NA,M
BN39-00061C CBF SIGNAL-STEREO;Mckinley,1,male,1.5m,B
BN68-01600A MANUAL FLYER-01, LEAFLET;COMM,SAMSUNG,En
BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC
Description & Specification
E
Q'ty SA/SNA Remark
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.A
1 S.N.A
1 S.A
1 S.N.A
1 S.N.A
1 S.A
1 S.A
1 S.A
1 S.N.A
1 S.N.A
4 S.N.A
2 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
4 S.N.A
1 S.N.A
1 S.N.A
3 S.N.A
4 S.N.A
1 S.N.A
1 S.A
1 S.A
1 S.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.N.A
1 S.A
1 S.N.A
1 S.N.A
